- Page 1 ® Essence Technology EIP 7012/EIP 7012P Essence VoIP Phone User’s Manual Version 1.0D Essence Technology Solution, Inc. TEL： 886-2-8913-2070 5F, No. 205, Beisin Rd., Sec. 3, Sindian, Taipei County 231, Taiwan FAX： 886-2-8913-2539 http://www.essti.com E-mail：sales@essti.com...
-
Page 2: Table Of Contents
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D TABLE OF CONTENTS Introduction ............................1 Harware Overview......................1 Software Overview ......................1 Keypad Interface for IP Phone Demo System.................. 2 Keypad Description ....................... 2 Recording........................3 Keypad Function and Setting List ................. 3 2.3.1 Phone Book ...................... - Page 3 9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D 3.5.6 DMZ Setting......................23 3.5.7 Virtual Server......................23 3.5.8 PPTP Settings ....................24 SIP Settings ........................25 3.6.1 Service Domain ....................25 3.6.2 Port Settings .......................27 3.6.3 Codec Settings ....................27 3.6.4 Codec ID Settings ....................28 3.6.5 DTMF Settings ....................28 3.6.6 RPort Function ....................29 3.6.7...
-
Page 4: Introduction
1.1 Harware Overview EIP 7012 has the following interfaces for Networking, telephone interface, LED indication, and power connector. EIP 7012P supports POE that can connect to POE switch and use the power of POE switch. Two RJ-45 Networking interface, these two interfaces support 10/100Mps Fast Ethernet. You can connect one RJ-45 Fast Ethernet port to the ADSL or Switch, and connect the other one to your computer. - Page 5 9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D ․ Many other SIP protocols ․ Mimic second dial tone Voice Quality ․ Support 3 SIP accounts ․ Incoming call indicator ․ G.168 LEC (Line Echo ․ SIP server redundancy ․ MWI/VMWI Canceller) ․...
-
Page 6: Keypad Interface For Ip Phone Demo System
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D 2 Keypad Interface 2.1 Keypad Description Key Name Description “1”, “-“, “٫”, “!”, “?” “2”, “a”, “b”, “c”, “A”, “B”, “C” “3”, “d”, “e”, ”f”, “D”, “E”, “F” “4”, “g”, “h”, “I”, “G”, “H”, “I” “5”, “j”, “k”, “l”, “J”, “K”, “L”... -
Page 7: Recording
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D M10 / REC Press to record the conversation, please refer to section 2.2 for further details. VOICE MSG Press to listen to voice mail messages. SPEAKER Press to activate the speakerphone to allow handsfree conversations. VOLUMN Control Press to increase or decrease the volume of the ringer tone, handset, or the volume of the current call using the speakerphone. -
Page 8: Call History
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D 2.3.1.2 Modifying Contact Information To modify contact information, do the following: Press the Menu key and then select Phone Book -> Search, and press the Enter key to view the phone book entries. Scroll through the phone to select an entry, and press the Enter key to display the contact information. -
Page 9: Phone Setting
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D Erase Records Delete call history. All: Delete all call history. Incoming: Delete all incoming call. Dialed: Delete all dialed out call. 2.3.3 Phone Setting Name Description Call Forward All Fwd. Activation: To Enabled/Disabled this function. Number: Forward to a Speed Dial Number. -
Page 10: Network
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D hear. Handset Gain Set Handset Gain from 0~15 (max.) for the other site to hear. Speaker Gain Set Speaker phone Gain from 0~15 (max.) for the other site to hear. Ringer Ringer Volume Ringer volume setting from 1~15 (max.). -
Page 11: Sip Settings
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D Status Show WAN, LAN IP address and MAC address. 2.3.5 SIP Setting If you want to use keypad to set the SIP setting, you have to go to item 8 Sys. Authority to input the password, or you can not change the SIP setting. -
Page 12: Nat Traversal
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D 2.3.6 NAT Traversal If you want to use keypad to set the NAT Traversal settings, you have to go to item 8 Sys. Authority to input the password, or you can not change the NAT Traversal settings. Name Description STUN Setting... -
Page 13: Setup The Voip Phone By Web Browser
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D 3 Setup the VoIP Phone by Web Browser Default the IP Phone’s Bridge is enabled, WAN port is in DHCP Client Mode. LAN port is the same as WAN. Connect the VoIP Phone to DHCP server, and the server assign an IP address to the phone. Check the IP address and add the port number “:9999”... -
Page 14: Phone Book
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D Note: The information in this page is useful when you need technical support. You may screen capture this page and provide the information to technical support team so that they could easily track the issues you have. -
Page 15: Speed Dial List
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D If you need to add a phone number into the phone book, you need to type the position, the name, and the phone number and ringer type for the number. When you finished a new phone list, just click Add Phone. -
Page 16: Phone Setting
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D 3.4 Phone Setting Phone Setting contains Call Forward, SNTP Settings, Volume Settings, Ringer Settings, DND Settings, Dial Plan Settings, Call Waiting Settings, Soft-key Setting functions, Hot Line Settings, Alarm Settings and Daylight Settings. 3.4.1 Forward Settings You can setup the phone number you want to forward in this page. -
Page 17: Sntp Settings
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D reflect the changes. 3.4.2 SNTP Settings You can setup the primary and second SNTP Server IP Address, to get the date/time information. Also you can base on your location to set the Time Zone, and how long need to synchronize again. When you have finished the settings, click Submit. -
Page 18: Ringer Settings
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D When finished the settings, click Submit. Go to the Save Changes page and click Save to reflect the changes. 3.4.4 Ringer Settings You can select the melody for the incoming calls. When you have finished the settings, click Submit. Go to the Save Changes page and click Save to reflect the changes. -
Page 19: Dial Plan Setting
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D DND Always: All incoming call will be blocked until disable this feature. DND Period: Set a time period and the phone will be blocked during the time period. If the “From” time is large than the “To”... -
Page 20: Symbol Explain
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D 3.4.6.1 Symbol Explain x or X 0,1,2,3,4,5,6,7,8,9 Drop Prefix: The default is No for adding the prefix to the dial plan in Replace Rule. Click Yes to delete the prefix of the dial plan in Replace Rule. Replace Rule 1~4: Type rule for matching. -
Page 21: Call Waiting Settings
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D 3.4.7 Call Waiting Settings If the user doesn’t want to be informed there is a new incoming call, the user can set the function off. When you have finished the settings, click Submit. Go to the Save Changes page and click Save to reflect the changes. -
Page 22: Alarm Settings
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D Hot Line Number: Type a phone number as a special line. When you have finished the settings, click Submit. Go to the Save Changes page and click Save to reflect the changes. 3.4.10 Alarm Settings Alarm Settings is to inform user at a certain time. -
Page 23: Network
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D Click On, select Format 1 or Format 2, and configure the start/end time to enable daylight saving at the configured period of time. When you have finished the settings, click Submit. Go to the Save Changes page and click Save to reflect the changes. -
Page 24: Lan Settings
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D to the ADSL Router, or Broadband Router. Also, you can use PPPoE to get the WAN IP address from your ISP. The default setting is Bridge mode. If you don’t need to use the Bridge mode, you can change to NAT mode. -
Page 25: Ddns Settings
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D The LAN settings’ default does not effect as Bridge mode is enabled. To configure LAN settings, go to Network -> WAN Settings, and click NAT under LAN Mode. You can connect your PC to the LAN port, set your PC as DHCP Client mode, and then you can get IP address from the VoIP Phone. -
Page 26: Vlan Settings
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D 3.5.5 VLAN Settings You can set the VLAN setting in this page. There are two kind of destination packets coming from the VoIP Phone’s WAN port. One packet goes to the VoIP Phone, and the other goes through the LAN port to the PC. VLAN Packets: If you enable the first VLAN Packets and set the VID, User Priority, and CFI, all the incoming packets will be check with the IP Address and the VID. -
Page 27: Dmz Setting
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D When you enable the first VLAN Packets and set the VID, User Priority, and CFI, all the incoming packets with the VoIP Phone’s IP address and the same VID will be accept by the VoIP Phone. If the incoming packets with the VoIP Phone’s IP address but the different VID then the packets will be discard by the VoIP Phone. -
Page 28: Pptp Settings
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D If you need to add a virtual server into the Virtual Server list, you need to type the num, server IP, internal/external port, and select a protocol. When you finished a new phone list, just click Add Server. If you want to enable a virtual server, you can select the virtual server you want to enable, and then click Enable Selected. -
Page 29: Sip Settings
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D Note: You need to configure LAN Mode as NAT in WAN Settings page to enable this function. 3.6 SIP Settings In SIP Settings, you can setup the Service Domain, Port Settings, Codec Settings, Codec ID Settings, RTP Setting, RPort Setting and Other Settings. - Page 30 9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D First you need click On in Active to enable the Service Domain, and you can input the following items: Display Name: You can input the name you want to display. User Name: You need to input the User Name get from your ISP. Register Name: You need to input the Register Name get from your ISP.
-
Page 31: Port Settings
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D Example: 192.168.1.100 (Assume Domain server SIP port = 5060) 192.168.1.100:5678 (change the SIP port to 5678) Proxy Server: You need to input the Proxy Server get from your ISP. Outbound Proxy: You need to input the Outbound Proxy get from your ISP. If your ISP does not provide the information, then you can skip this item. -
Page 32: Codec Id Settings
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D 3.6.4 Codec ID Settings You can set the Codec ID to meet the other device’s requirement. When you have finished the settings, click Submit. Go to the Save Changes page and click Save to reflect the changes. 3.6.5 DTMF Settings You can setup the RFC2833 Out-Band DTMF, Inband DTMF and Send DTMF SIP Info in this page. -
Page 33: Rport Function
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D 3.6.6 RPort Function You can setup the RPort Enable/Disable in this page. To change this setting, please follow your ISP information. When you have finished the settings, click Submit. Go to the Save Changes page and click Save to reflect the changes. -
Page 34: Nat Trans
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D 3.7 NAT Trans In NAT Trans, you can setup STUN function. These functions can help your VoIP Phone working properly behind NAT. STUN Setting: You can setup the STUN Enable/Disable and STUN Server IP address in this page. This function can help your VoIP Phone working properly behind NAT. -
Page 35: Tones Settings
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D MAC Address: When click Manual, type an MAC address for WAN port. When you have finished the settings, click Submit. Go to the Save Changes page and click Save to reflect the changes. 3.8.2 Tones Settings Tones Settings function can let you to configure the tones of various sounds. -
Page 36: System Auth
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D ICMP Not Echo: Setup the ICMP echo Enable/Disable. This function can disable echo when someone pings this device, it can avoid hacker try to attack the device. Send Anonymous CID: click Yes for not sending the phones caller ID out. Send Flash Event: click DTMF EVENT or SIP INFO for the flash event. -
Page 37: Update
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D 3.11 Update In Update, you can update the VoIP Phone’s firmware to the new one or do the factory reset to let the VoIP Phone back to default setting. 3.11.1 Update Firmware In New Firmware function you can update new firmware via HTTP in this page. -
Page 38: Auto Update Settings
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D 3.11.2 Auto Update Settings The VoIP Phone provides automatic update function. Once enable the function, the phone will check the updates at the time in order to have the latest version of firmware. Note that the function must be in DHCP Client mode. - Page 39 9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D...
-
Page 40: Automatic Client Configuration With Essence Ip Pbx
9/28/2007 VoIP Phone Administration Guide MAG-07005-2 Rev. D 4 Automatic Client Configuration with Essence IP PBX Auto Client Configuration (ACC) function can be used to download the original configurations stored in the Essence IP-PBX. This is very useful for the administrator who needs to set large amount of VoIP phones.
