- Page 1 Drifton High Precision Liquid Dispenser Operation Manual (GB) 2004-DE 2004-DT 2004-DB Drifton A/S Avedoereholmen 84, 2650 Hvidovre, Denmark Tel: 0045-5372 8090, Fax: 0045-3677 3633 Web: www.drifton.eu / www.drifton.dk E-mail: info@drifton.dk...
-
Page 2: Introduction
Introduction You have selected a reliable, high quality, high precision dispenser from Drifton A/S. The dispenser will provide you with years of trouble-free, productive service. This operation manual will help you maximize the usefulness of your new dispenser. Please spend a few minutes to become familiar with the controls and features. Follow our recommended testing procedures. -
Page 3: Table Of Contents
Personal Safety .............................. 5 Started ................................6 Principles ................................6 Dispenser Hookup ............................. 7 Drifton 2004-DE - Digital & Circling Dispenser ....................8 Drifton 2004-DE - Specifications ........................8 Drifton 2004-DE - Connections drawing ...................... 8 Drifton 2004-DE - Controls Panel ......................... 9 Drifton 2004-DE - Setup for Testing ...................... - Page 4 Suggestions on Settings ........................... 21 Helpful Hints ..............................21 Troubleshooting Guide ............................ 22 Guarantee ................................. 23...
-
Page 5: Product Safety Statement
Test – Verify operation of features and performance of equipment using the ‘Testing and installation’ sections within this Operation manual. If necessary, refer to the ‘Trouble Shooting Guide’ elsewhere in this user guide. A faulty or defective unit should be returned to Drifton or representative for refurbishment. -
Page 6: Started
Principles Drifton high precision dispenser series quote air pressure control liquid, Fluid dispensing through high- precision timing of the pressure pulse control, which could ensure that the correct amount of fluid is applied at every time, on every part, to every item Time is more precise quantitative also will be prospective more. -
Page 7: Dispenser Hookup
8. Push the black male quick-connect on the syringe barrel adapter assembly into the front of the dispenser 9. Remove the tip cap, replace it with an appropriate Drifton tip cap. Place the syringe barrel in the barrel holder. 10. Initial setup is now complete. At this point you are now ready to set up your dispensing flow rate and time to suit your application needs. -
Page 8: Drifton 2004-De - Digital & Circling Dispenser
Drifton 2004-DE - Digital & Circling Dispenser Drifton 2004-DE - Specifications Dispensing time: 0.007S-9.999S Cycling (interval) time: 0.1S-9.9S Air Input: 7KgF/cm Air Output: 0.1–7KgF/cm Repeatability: 0.0005S Min depot: 0.005ml Work Frequency: >600 times/minute Input AC: 110V or 220V 50Hz Internal Voltage:... -
Page 9: Drifton 2004-De - Controls Panel
Drifton 2004-DE - Controls Panel ① Pressure gauge ② Pressure regulator ③Vacuum regulator ④ Barrel connector ⑤Time setting ⑥Interval setting ⑦ Power switch ① Power input receptacle ② Air input connect ③ Foot pedal switch/finger switch ④ Air exhaust port... -
Page 10: Drifton 2004-De - Setup For Testing
Drifton 2004-DE - Setup for Testing When you begin testing, the Power switch should be off. The amount of material dispensed in each cycle depends on the combination of air pressure, time of air pulse, viscosity of material and dispensing tip size. -
Page 11: Drifton 2004-Dt - High Precision Digital Display Dispenser
Drifton 2004-DT - High Precision Digital Display Dispenser Drifton 2004-DT - Specification Time display: Four Figures Led display Dispensing time: 0.001S-9.999S, 0.01S-99.99S Air Input: 7bar (1bar =1.01972kgF/cm² =14.5038psi) Air Output: 0.1bar–7bar Repeat tolerance: 0.00005S Min deposit: 0.001ml Speed: > 600 time/minute Input Voltage: 110V/220V±10% 50Hz... -
Page 12: Drifton 2004-Dt - Controls Panel
Drifton 2004-DT - Controls Panel ① Pressure gauge ② Pressure regulator ③Time display ④ Time setting ⑤ Vacuum regulator ⑥ barrel connector ⑦ power switch ① Power input receptacle ② Air input connect ③ Foot pedal switch/finger switch ④ Air exhaust port... -
Page 13: Drifton 2004-Dt - Setup For Testing
Drifton 2004-DT - Setup for Testing When you begin testing, please Power switch should be off. The amount of material dispensed each cycle depends on the combination of air pressure, time of air pulse, viscosity of material and dispensing tip size. -
Page 14: Drifton 2004-Db - High Precision Digital Display Cycling
Drifton 2004-DB - High Precision Digital Display Cycling Drifton 2004-DB - Specification Time listing: Four Led listing Dispensing Time: 0.001-9.999S, 0.01-99.99S Cycling (interval) time: 0.1-9.9S Air Input: 7bar (1bar =1.01972kg/cm² =14.5038psi) Air Output: 0.1 - 7bar Repeatability: 0.00005S Min deposit: 0.001ml... -
Page 15: Drifton 2004-Db - Controls Panel
Drifton 2004-DB - Controls Panel ① Pressure gauge ② Pressure regulator ③ Time display ④ Vacuum regulator ⑤ Barrel connector ⑥ Time setting ⑦ Interval setting ⑧ Power switch ① Power input receptacle ② Air input connect ③ Foot pedal switch/finger switch... -
Page 16: Drifton 2004-Db - Setup For Testing
Drifton 2004-DB - Setup for Testing When you begin testing, the Power switch should be off. The amount of material dispensed in each cycle depends on the combination of air pressure, time of air pulse, viscosity of material and dispensing tip size. -
Page 17: Application Art
Application Art 1. Making Timed Deposits of Medium to Thick Fluids You are now ready to test the prefilled, nontoxic test fluid. This material is representative of thick, non- leveling fluids like sealants, pastes or greases. Check your initial settings: a) Adjusting Air gauge b) Timer setting c) Tapered tip is on the test barrel... -
Page 18: Setting The Deposit Size
3. Setting the deposit size Test different time and air pressure, to get the wanted dispensing volumes. - For medium to high viscosity glue, use a tapered needle. - For low viscosity glue, use a metal needle with a smaller gauge. - For micro dispensing volumes, select low pressure (0~30psi). -
Page 19: Piston Function
Repeat tests as before, keeping the air pressure low and adjusting the time for different deposit sizes. Contact Drifton service if you have any questions. Two things to remember (if you do not use the piston. when dispensing thin fluid) 1. -
Page 20: Filling The Syringe Barrel
Caution: Do not completely fill syringe barrels. The optimum fill is a maximum 2/3 of the barrel capacity and 1/2 of the barrel capacity when using the Drifton blue LV Barrier piston. If the fluid you are dispensing is procurable, take the syringe barrel, twist on a tip cap and pour your fluid in. -
Page 21: Suggestions On Settings
1. Use Drifton pistons to make barrel loading, dispensing and handling cleaner, safer and more accurate. Caution: If you dispense watery fluids and choose not to use Drifton pistons, do not increase vacuum pressure rapidly and do not tip the barrel. Vacuum may pull fluid into the adapter hose, or if the syringe barrel is tipped, fluid may flow back into the dispenser. -
Page 22: Troubleshooting Guide
Troubleshooting Guide A Drifton Customer Service or Technical Services representative is always available to assist you with any question you may have about your Dispensing System. Please feel free to call or email us at the addresses on the fron cover of this manual book. -
Page 23: Guarantee
3. Sales agent should perform the obligations of warranty and maintenance. In no event shall any liability or obligation of Drifton arising from this warranty exceed the purchase price of the equipment. Before using, user shall determine the suitability of the product for its intended use, and user assumes all risk and liability whatsoever in connection therewith.
