Taking Measurements

When reading the current output from the unit, use the following formula to calculate the vibration level:
Measured mA
4.00
8.00
12.0
15.75
20
Measured mA
4.00
8.00
12.0
15.75
20
Measured mA
4.00
8.00
12.0
15.75
20

RV Option

The RV (raw vibration) option includes a 100 mV/g ±20% additional output. The accelerometer frequency range
is 1 Hz-10 kHz, maximum amplitude of 15 g pk. This vibration signal can be used by data collectors or analyzers
to acquire the acceleration signal for further analysis.
figure 3 – RV wiring
INDUSTRIAL MONITORING INSTRUMENTATION DIVISION
640AX0
0.0 ips, pk
0.125 ips, pk
0.25 ips, pk
0.37 ips, pk
0.5 ips, pk
641AX0
0.0 ips, rms
0.125 ips, rms
0.25 ips, rms
0.37 ips, rms
0.5 ips, rms
645
0.0 g rms
1.25 g rms
2.50 g rms
3.67 g rms
5.00 g rms
640AX1
0.0 ips, pk
0.25 ips, pk
0.5 ips, pk
0.73 ips, pk
1.0 ips, pk
641AX1
0.0 ips, rms 0.0 ips, rms
0.25 ips, rms 0.5 ips, rms
0.5 ips, rms 1.0 ips, rms
0.73 ips, rms 1.47 ips, rms
1.0 ips, rms 2.0 ips, rms
646
0.0 g rms
2.50 g rms
5.00 g rms
7.34 g rms
10.0 g rms
640AX2
0.0 ips, pk
0.5 ips, pk
1.0 ips, pk
1.47 ips, pk
2.0 ips, pk
641AX2
PAGE 4
