LindabFireSystemPro
Commissioning instructions
© 07.2022 Lindab Ventilation. Fire System Pro Version 1.1. All forms of reproduction without written permission are forbidden.
trademark of Lindab AB. Lindab's products, systems, product and product group designations are protected by intellectual property rights (IPR).
l inda b I fo r a b etter cli m ate
is the registered

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fire System Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lindab Fire System Pro

Summary of Contents for Lindab Fire System Pro

  • Page 1 LindabFireSystemPro Commissioning instructions © 07.2022 Lindab Ventilation. Fire System Pro Version 1.1. All forms of reproduction without written permission are forbidden. is the registered trademark of Lindab AB. Lindab's products, systems, product and product group designations are protected by intellectual property rights (IPR).

  • Page 2: Table Of Contents

    3.5 Access rights ...................... 24 Caution! Read and understand the instruction before using the Lindab Fire System Pro and ensure that the installation complies with local safety regulations. Installation and maintenance of the system should only be carried out by qualified personnel.

  • Page 3: Overview

    (PRO-PDT). 1.1 Introduction Lindab Fire System Pro is a complete fire protection The main function of the PRO-M is to continuously check steering system that allows to feed, monitor and test up to all damper position switches and all other components, 60 fire and/or smoke control dampers.

  • Page 4: System Setup

    | com mi s si oni ng g u i d e FireSystemPro 1.3 System setup Fire System Pro is a flexible steering system that gives full automatic fire and smoke protection, and can be customized and designed to handle various buildings and different scenarious. Cl ick o n the...

  • Page 5: Pro-M Push Buttons

    l i n da b | com mi s s io n in g g u i de FireSystemPro 1.4 PRO-M push buttons The Pro-M master unit has a pre-programmed controller with a backlit internal display. The different menus and settings are easily accessible and controlled by push buttons on the front of the unit.

  • Page 6: Pro-S Light Indications

    The button has been pressed Blinking on the unit and it’s waiting to be addressed Fast Communication Communication Yellow blinking in process Figure 4: Screenshots from Lindab ProLink application We reserve the right to make changes without prior notice 2022-07-19...

  • Page 7: Menu Structure

    | com mi s s io n in g g u i de FireSystemPro 1.8 Menu structure The programming functions and configurations of the Fire System Pro are made in the Pro-M controller. The interface menu is structured as followed: 1.1 Com alarm acknow.

  • Page 8: Quick Start Guide

    FireSystemPro 2.0 Quick start guide This section provides you with guidlines to common settings and configurations to get the Fire System Pro running. Note! Each guide starts from the main menu. To go back, press “back” button until you reach the main menu.

  • Page 9: Activate Local Fire Dampers

    l i n da b | com mi s s io n in g g u i de FireSystemPro 2.4 Activate local fire dampers 2.5 Add PRO-S damper units to PRO-M 1. Press ”down” to find 1. Press ”down” to find Status Overview Status Overview ”System Setup”...

  • Page 10: Add Pro-S Damper Units Via Prolink

    Add PRO-S damper units (cont.) 2.6 Add PRO-S damper units via ProLink 10. Start running by pressing the ”push-button” on all 1. Open Lindab ProLink application suitable damper units (PRO-S). LED lights up in color ”Magenta” meaning that the unit is still offline.
  • Page 11 l i n da b | com mi s s io n in g g u i de FireSystemPro 4. Access ”communication” and set modbus address 6. Confirm changes according to requirements. Note! Lowest modbus address for PRO-S is four (4) Attention! Repeat the steps for other PRO-S damper unit.

  • Page 12: Set Section Funcionality In Pro-M

    lin da b | com mi s si oni ng g u i d e FireSystemPro 12. Press ”OK” to edit 5. Press ”down” to find Fire Inspector Find addressed slave ”Section containment” ”Start” status (Yes/No) Section evacuation Start: No ->Section containment Status: Idle Section tools...

  • Page 13: Section Setup In Pro-M

    l i n da b | com mi s s io n in g g u i de FireSystemPro 2.8 Section setup in PRO-M 12. Press ”OK” to con- Set same section 1. Press ”down” to find firm ”Stop” number Status Overview Start: 4 Stop: 7...

  • Page 14: Activate Sef Mode

    lin da b | com mi s si oni ng g u i d e FireSystemPro Section setup in PRO-M (cont.) 5. Press ”OK” to start 11. Press ”OK” to con- Number: 14 Select Slave/damper edit ”Select slave firm setup for damper Damper: Smoke ctrl damper number”...

  • Page 15: Activate The Fire System Pro

    13. Press ”forward” ”Activate System” Pressure sensor to enter ”Pressure enabled: No sensor” Current pressure The Fire System Pro is now activated and running 14. Press ”OK” to edit Pressure sensor ”Pressure sensor ena- enabled: No_ Current pressure bled” 15. Press ”up” to Pressure sensor change status for ”Pres-...

  • Page 16: Complete List Of Menu Functions

    lin da b | com mi s si oni ng g u i d e FireSystemPro 3.0 Complete list of menu functions Following is a complete list of menu options, including a function description 3.1 Status Overview The status overview menu (1.0) shows status for different components of the system 3.1.1 Communication alarm acknowledge Shows status (running) and if all communication Status Overview (1.0)
  • Page 17 l i n da b | com mi s s io n in g g u i de FireSystemPro 3.1.4 Input/Output Status Overview (1.0) Com alarm acknow. (1.1) Digital Input (1.4.1) System Setup (2.0) Alarm log (1.2) Universal Input (1.4.2) Settings (3.0) Exercise log (1.3) Analog Input (1.4.3)
  • Page 18 lin da b | com mi s si oni ng g u i d e FireSystemPro 3.1.7 SEF Status Overview (1.0) Com alarm acknow. (1.1) System Setup (2.0) Alarm log (1.2) Settings (3.0) Exercise log (1.3) Manual/Auto (4.0) Input/Output (1.4) Access Rights (5.0) Dampers (1.5) Smoke detectors (1.6)

  • Page 19: System Setup

    l i n da b | com mi s s io n in g g u i de FireSystemPro 3.2 System Setup Configurations and custom compostitions are made in system setups 3.2.1 Adressing slaves Status Overview (1.0) Adressing slaves (2.1) Add slave (2.1.1) if using PRO-M System Setup (2.0)
  • Page 20 lin da b | com mi s si oni ng g u i d e FireSystemPro 3.2.4 De-/activate damper Status Overview (1.0) Adressing slaves (2.1) System Setup (2.0) SEF (2.2) Settings (3.0) Communication (2.3) Manual/Auto (4.0) De/-activate damper (2.4) Access Rights (5.0) Detector/Temp AI1 (2.5) Pressure sensor (2.6) Miscellaneous (2.7)
  • Page 21 l i n da b | com mi s s io n in g g u i de FireSystemPro 3.2.7 Miscellaneous Status Overview (1.0) Adressing slaves (2.1) System Setup (2.0) SEF (2.2) Settings (3.0) Communication (2.3) Digital Input (2.7.1.2) Input/Output NC/NO (2.7.1) Manual/Auto (4.0) De-Activate damper (2.4) Digial Output (2.7.1.2)

  • Page 22: Settings

    lin da b | com mi s si oni ng g u i d e FireSystemPro 3.3 Settings Exercise settings, delay AHU stop, date, time and language. 3.3.1 Exercise settings Status Overview (1.0) Exercise settings (3.1) Last/next func. test (3.1.1) System Setup (2.0) Delay AHU stop (3.2) Change time (3.1.2)

  • Page 23: Manual/Auto

    l i n da b | com mi s s io n in g g u i de FireSystemPro 3.4 Manual/Auto For customized setups 3.4.1 Function test Status Overview (1.0) Function test (4.1) Full scale test (4.1.1) System Setup (2.0) SEF (4.2) Individually damper (4.1.2) Settings (3.0)

  • Page 24: Access Rights

    lin da b | com mi s si oni ng g u i d e FireSystemPro 3.5 Access rights Log on/off to the system and change password for different levels. 3.5.1 Log on Status Overview (1.0) Log on (5.1) System Setup (2.0) Log off (5.2) Settings (3.0) Change password (5.3)
  • Page 25 We at Lindab have therefore made it our most important objective to contribute to an indoor climate that improves people’s lives. We do this by developing energy-efficient ventilation solutions and durable building products.
