Thetford Bravura 31113 Replace

Kit Contents: K1
New Ref Description
K1 A Water Module / Screws (2x)
NI B Water Supply Line
NI C Hairpin Clip
NI D Water Nozzle Tube
NI E Left Link
NI Not Included
Tools Needed:
■ Phillips Screwdriver
Wear protective gloves and eye wear when
! NOTICE AVISO CAUTION AVIS
you touch material that has been in contact
with human waste.
Disinfect your tools and work surface after you
complete this replacement procedure.
REDUCE HOLDING TANK ODOR: Rinse the
NOTICE
toilet with water, drain the holding tank, and
add Thetford Holding Tank Deodorant.
Replace Part
1. Turn off RV water supply per RV Owner's Manual.
2. Pull straight up to remove existing Seat & Cover Assembly.
3. Disconnect (Fig. A).
B
4. Slip off on right side of crank arm (Fig. B).
C
5. Remove two screws at top of
6. Slide back toward wall, out of cradle and off (Fig. D).
A
7. Slide (left) off - it will fall. (Fig. D).
E
8. Hold (Fig. D) and twist
D
9. Connect to (new part).
D K1
10. Attach .
E
11. Slide into cradle. Be sure tongue fi ts into slot, and screw
K1
slots line up.
12. Replace (2x). Tighten.
A1
13. Replace .
C
14. Reconnect .
B
15. Turn on RV water supply. Check for leaks at back of toilet.
16. Flush test toilet.
17. Replace Seat & Cover Assembly to toilet.
