Step 5:
Auto-Iris & Remote Zoom and Auto-Focus Control
Our latest IdentiLynx camera is the first equipped with auto-iris as well as remote-control lens which offers complete control over
the zoom and focus settings from within the FinishLynx software. It's as simple as clicking the icons in the remote-control panel
of the Hardware Control window.
a.
Auto-Iris:
always on and managed automatically by the camera (cannot be manually adjusted). To change exposure,
adjust the brightness value or lower the shutter speed.
b.
Zoom Steps:
4 step sizes are available. Use the mouse to click the
click, Ctrl-click or Ctrl-Shift-click (full range in two steps) for increasingly bigger steps.
Ctrl-Shift-click the Focus Near or Focus Far icon to activate the camera's Automatic focus function. The
c.
Auto Focus:
focus icons will change when in auto focus.
Normal Focus Mode
d.
Manual Focus Steps:
Far icons to manually change the focus in increasingly bigger steps.
Step 6:
Camera Settings
NOTE:
Only the Setup,
Parameters
grayed out as they do not apply to the IdentiLynx functions.
a. Click the
Camera Settings
b. Click the
Setup
tab and name the camera based on
location or function.
c. Click the
Parameters
tab and set the Frame Rate/Height
and shutter speed to your preference.
IdentiLynx SR & HRS Quick Start Guide
Auto Focus Mode
3 step sizes are available. Use a simple click, Shift-click or Ctrl-click on the Focus Near or Focus
and
Capture
tabs will apply to settings for the IdentiLynx camera. The other settings are
icon.
Zoom
icons for the smallest change. Try to Shift-
•
Click the
Capture
tab and make sure
preferred capture method.
d. In
File
|
Options
| Image, make sure that
is set to
All
Cameras.
IdentiLynx SR/HRS
Quick Start Guide
you select the
Time Tracking
Page 3 of 4
