SAPPHIRE ELECTRIC FIREPLACE
Model# :
FB-SPH40
FB-SPH50
FB-SPH60
OWNER'S MANUAL.
SAPPHIRE 40"/50"/60" Wall Mounted / Built-in Electric Fireplace
AC 120V 60Hz 1465W
Read and understand this entire owner's manual, including all safety information,
WARNING
before plugging in or using this product. Failure to do so could result in fire, electric
shock, or serious injury.
Keep this owner's manual for future reference. If you sell or give this product away,
CAUTION
make sure this manual accompanies this product.
Advertisement
Table of Contents
Related Manuals for FIRE BLAZE SAPPHIRE FB-SPH40
Summary of Contents for FIRE BLAZE SAPPHIRE FB-SPH40
- Page 1 SAPPHIRE ELECTRIC FIREPLACE Model# : FB-SPH40 FB-SPH50 FB-SPH60 OWNER'S MANUAL. SAPPHIRE 40"/50"/60" Wall Mounted / Built-in Electric Fireplace AC 120V 60Hz 1465W Read and understand this entire owner’s manual, including all safety information, WARNING before plugging in or using this product. Failure to do so could result in fire, electric shock, or serious injury.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safety Information! Preparing for Installation Parts and Hardware Product Dimensions Installation and Assembly Recessed Installation Wall Mounted Installation Metal Covers Assembly Crystals Installation Drift logs Installation Log-set Installation Operation Temperature Limiting Control Remote Control Battery Information Care and Maintenance Customer Support... -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION! WA R N I N G Read all instructions before using this heater! This heater is hot when in use. To avoid burns, DO NOT let bare skin touch hot surfaces. If provided, use handles when moving this heater. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9m) from the front of the heater, and keep them away from the sides and rear. -
Page 4: Preparing For Installation
WA R N I N G NEVER leave this heater unattended. ALWAYS unplug this heater when not in use. ALWAYS store this heater in a dry location. NEVER use the fireplace if it has become wet. NEVER plug this heater into an outlet that is old, cracked, or has any loose wires or connections. Plugging this heater into a faulty outlet could result in electric arcing within the outlet that could cause the outlet to overheat or catch fire. -
Page 5: Parts And Hardware
Parts and Hardware A – Fireplace B – Wood Screws C – Drywall anchors D - Wall Bracket E - Decorative F - Decorative Fixed on back of firebox Crystals - Large Crystals -Small J - Log-set G - Remote H - Screw I - Drift Control... -
Page 6: Installation And Assembly
Installation and Assembly Your appliance is a wall-mounted, recessed and/or mantel installed appliance. Select a suitable location that is not susceptible to moisture and is away from drapes, furniture and hig h traffic areas. NOTE: Follow all National and local electrical codes. MINIMUM CLEARANCE TO COMBUSTIBLES Measurements are taken from the glass front Bottom... -
Page 7: Recessed Installation
Recessed Installation 1-3/16``[30 mm] 1/2``[12,5 mm] Hole Size Step A. Step B. Create an opening in the wall for fireplace box. Install the wall anchors according to the dimensions Size of the hole as below chart. shown in the drawing. Framing Hole Size Model Number F B- SPH40... - Page 8 Recessed Installation Step E. Step F. Remove screws holding brackets inside the Take off 2 metal brackets. Keep the screws and fireplace box on both sides. brackets as you will need to screw them back. Step G. Step H. Insert fireplace box in the wall opening. Use 4 wood Reinstall metal brackets previously removed in screws (included) to fix the appliance.
-
Page 9: Wall Mounted Installation
Wall Mounted Installation Due to the many different materials used on different walls, it is hig hly recommended that you consult your local builder before you install this appliance on the wall. A. Select a location that is not prone to moisture and is located at least 36" (914mm) away from combustible materials such as curtain drapes, furniture, bedding, paper, etc. -
Page 10: Metal Covers Assembly
Metal Covers Assembly Install two metal screw covers. Magnets are pre-installed in the fireplace for holding the covers. Screw Cover Crystals Installation Front glass must be removed and the appliance must be mounted in its final location before the crystal embers are installed. Carefully place the ember bed stri p to the slot above LED lig hts. -
Page 11: Drift Logs Installation
Drift logs Installation Front glass must be removed and the appliance must be mounted in its final location before the crystal embers and drift logs are installed. Carefully place the ember bed stri p to the slot above LED lig hts. Fugure 1. Place small crystal embers along the media tray. -
Page 12: Operation
Operation Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure to do so could result in electric shock, fire or serious injury. Power Plug the power cord into a AC 120 Volt outlet (see IMPORTANT SAFETY INFORMATION on Pages 2 and 3). - Page 13 Operation BUTTON FUNCTION ACTION & INDICATION Flame Color button: Changes the color flame 1. Press once to change the flame color. effect. NOTE: Color effect stays on until power button 2. Press again until desired setting is reached. is turned off. Total 6 flame colors.
-
Page 14: Temperature Limiting Control
When the heater is first turned on, a slig ht odor may be present. NOTICE This is normal and should not occur again unless the heater is not used for a long period of time. To improve operation, aim the remote control at the front of the fireplace. NOTICE DO NOT press the buttons too quickly. -
Page 15: Care And Maintenance
Care and Maintenance Cleaning ALWAYS turn the heater OFF and unplug the power cord from the outlet before cleaning, performing maintenance, or moving this fireplace. Failure to do so could result in electric shock, fire, or personal injury. NEVER immerse in water or spray with water. Doing so could result in electric shock, fire, or personal injury. -
Page 16: Customer Support
Customer Support THANK YOU FOR CHOOSING FIREBLAZE! STOP! If you have any questions about assembly or operation of electric fireplace Please DO NOT RETURN Contact our customer service team first SUPPORT@FIRE-BLAZE.COM...
