Edison Series
Flip Board
Tools required:
•
Hex Key (Supplied)
•
Phillips Screwdriver (4x6 & 4x8 only)
Two person assembly recommended
Standard Parts:
A
Board
F
Knob
x2
Optional Parts:
K
Gusset
x2
Gusset and Pan Head Screw used
on 4x6 and 4x8 ft. boards only.
www.everwhiteboards.com
B
C
Upright
x2
G
H
Spring Washer
Socket Head Screw
x2
L
Pan Head Screw
x4
D
Tray
Crossbeam
I
Oval Cap
x12
x6
Note:
After assembly, remove protective film from
both sides of board.
Clean with a mild soap or glass cleaner.
800-335-7319
E
Leg Assembly
x2
J
Round Cap
x8
Advertisement
Related Manuals for EVERWhite Edison Series
Summary of Contents for EVERWhite Edison Series
- Page 1 Edison Series Flip Board Tools required: • Hex Key (Supplied) • Phillips Screwdriver (4x6 & 4x8 only) Two person assembly recommended Standard Parts: Board Upright Tray Crossbeam Leg Assembly Knob Spring Washer Socket Head Screw Oval Cap Round Cap Optional Parts:...
- Page 2 1. Assemble Base(E) to Upright(B) using using Socket Head Screws(H). Tighten screws and repeat for opposite side. 2. Attach Crossbeam(D) to Base Assembly from Step 1 using Socket Head Screws(H). Locking plates on Uprights should face the center. Tighten screws and repeat on other side. 3.
