Edison Series
Flip Board
Tools required:
•
Hex Key (Supplied)
•
Phillips Screwdriver (4x6 & 4x8 only)
Two person assembly recommended
Standard Parts:
A
Board
F
Knob
x2
Optional Parts For: 4'x6' and 4'x8' boards only.
K
Gusset
x2
Using Self Tapping Screws(L) and pilot holes to
attach Gussets(K) to frame
www.everwhiteboards.com
B
C
Upright
x2
G
H
Spring Washer
Socket Head Screw
x2
L
Self Tapping Screw
x4
D
Tray
Crossbeam
I
Oval Cap
x12
x6
Note:
both sides of board.
Clean with a mild soap or glass cleaner.
800-335-7319
E
Leg Assembly
x2
J
Round Cap
x8
