BBQ GO BG-HH2P Manual

Digital food thermometer with dual external probes
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
BG-HH2P
Digital Food Thermometer
With Dual External Probes

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BG-HH2P and is the answer not in the manual?

Questions and answers

Related Manuals for BBQ GO BG-HH2P

Summary of Contents for BBQ GO BG-HH2P

  • Page 1 BG-HH2P Digital Food Thermometer With Dual External Probes...

  • Page 3: Table Of Contents

    Contents Product Layout How to Replace Batteries 3. Feature Buttons 5. Menu Instructions 04-13 Menu Description Temperature Unit Setting Button Sound Setting Backlight ON Time Setting Alarm Setting of the Foldable Probe Target Temperature Setting of the Foldable Probe Temperature Calibration Setting of the Foldable Probe Alarm Setting of the External Probe1 Target Temperature Setting of the External Probe1 Temperature Calibration Setting of the External Probe1...

  • Page 4: Product Layout

    Product Layout Set temperature Alarm Icon Hold Icon Current Temperature External Power & Increase Button Probe Icon Set Button Foldable probe Hold & Decrease Button Built-in Magnet Battery Cover Dual Extemal Probes - 01 -...

  • Page 5: How To Replace Batteries

    How to Change Replacement Batteries 1. Unscrew the cover of the battery cartridge with the supplied screwdriver. 2. Put 2 AAA batteries into the battery compart- ment and make sure that the positive and negative poles are in the correct position. 3.

  • Page 6: Feature

    Feature Product Name: Digital Food Thermometer with Dual External Probes Product Model: BG-HH2P Three Channel Temperature Measurement Function Measurement Range: -50.0℃~300℃/-58.0℉~572℉ Measurement Accuracy: ±0.5℃/±1.0℉ Response Time of the Foldable Probe: 2S Temperature Unit: ℃/℉ Waterproof Level: IPX5 Independent Temperature Calibration for Each...

  • Page 7: Menu Instructions

    Menu Instructions Menu Description Menu Dis- Setting Factory Function Icons play Range Setting Temperature Unit ℃ or ℉ ℉ Alarm Sound ON or OFF Lighting Time 5~60 Seconds Alarm of the ON or OFF Foldable Probe -50.0℃~300℃ 77.0℃ Alarm Value of the Foldable Probe -58.0℉~572℉...
  • Page 8 -50.0℃~300℃ 77.0℃ Alarm Value of the External Probe1 -58.0℉~572℉ 170℉ -4.9℃~4.9℃ 0.0℃ Calibration Value of the External Probe1 -9.9℉~9.9℉ 0.0℉ Alarm of the ALM2 ON or OFF External Probe2 -50.0℃~300℃ 77.0℃ Alarm Value of the External Probe2 -58.0℉~572℉ 170℉ -4.9℃~4.9℃ 0.0℃...

  • Page 9: Temperature Unit Setting

    Temperature Unit Setting Hold for 2 seconds to enter into setup state, then press the button to select BLT. Press to choose a temperature unit between ℃ and ℉. Note: All parameters will be restored to the default data if the temperature unit is Changed. The thermometer will save the settings and exit setup 30 seconds later if no operation is performed on the device, or you can hold...

  • Page 10: Backlight On Time Setting

    Press to select between ON and OFF. The thermometer will save the settings and exit setup 30 seconds later if no operation is performed on the device, or you can hold for 2 seconds to exit setup manually. BackLight ON Time Setting Hold for 2 seconds to enter into setup state, the parameter of bLt will flash on the screen.

  • Page 11: Alarm Setting Of The Foldable Probe

    Alarm Setting of the Foldable Probe Hold for 2 seconds to enter into setup state, then press the button to select ALM. Press to select between ON and OFF. The thermometer will save the settings and exit setup 30 seconds later if no operation is performed on the device, or you can hold for 2 seconds to exit setup manually.

  • Page 12: Temperature Calibration Setting Of The Foldable Probe

    Press to adjust the setting value, hold to adjust the setting value quickly. The thermometer will save the settings and exit setup 30 seconds later if no operation is performed on the device, or you can hold for 2 seconds to exit setup manually.

  • Page 13: Alarm Setting Of The External Probe1

    Alarm Setting of the External Probe1 Hold for 2 seconds to enter into setup state, then press the button to select ALM1. Press to select between ON and OFF. The thermometer will save the settings and exit setup 30 seconds later if no operation is performed on the device, or you can hold for 2 seconds to exit setup manually.

  • Page 14: Temperature Calibration Setting Of The External Probe1

    Press to adjust the setting value, hold to adjust the setting value quickly. The thermometer will save the settings and exit setup 30 seconds later if no operation is performed on the device, or you can hold for 2 seconds to exit setup manually.

  • Page 15: Alarm Setting Of The External Probe2

    Alarm Setting of the External Probe2 Hold for 2 seconds to enter into setup state, then press the button for to select ALM2. Press to select between ON and OFF. The thermometer will save the settings and exit setup 30 seconds later if no operation is performed on the device, or you can hold for 2 seconds to exit setup manually.

  • Page 16: Temperature Calibration Setting Of The External Probe2

    Press to adjust the setting value, hold to adjust the setting value quickly. The thermometer will save the settings and exit setup 30 seconds later if no operation is performed on the device, or you can hold for 2 seconds to exit setup manually.

  • Page 17: Operation Instructions

    Operation Instructions Operations of the Foldable Probe (without external probes) Display Operation The measured temperature of the foldable probe will be displayed on the screen as CURRENT TEMP if no external probe is inserted. When ALM is set to ON, the SET TEMP area will display the alarm value of the foldable probe.
  • Page 18 the probe back. Manual Operation Whether the probe is pulled out or folded, hold 2 seconds to turn off the thermometer. Press turn on the thermometer when the device is shutdown. If no operation is performed on the thermometer, it will turn off 3 minutes later automatically.

  • Page 19: Operations Of The Bbq Mode

    The alarm sound will stop if the temperature returns to the set range, or you can press any button to cancel the alarm sound. Backlight The backlight makes it convenient to read the screen in dark environments. Without any operation, the backlight will keep activated for the time of BLT parameter, then be off automatically(active time is adjustable).
  • Page 20 When ALM1 is set to OFF, the screen will display SET TEMP and “ ”. The thermometer will display P2 and the data of port2 by default when port2 is inserted with a probe. When ALM2 is set to ON, the screen will display SET TEMP and the alarm value of external probe2.
  • Page 21 Alarm Operation If ALM1 is set to OFF, the alarm of the external probe1 will be turned off, and the current temperature will be displayed on the screen only. If ALM1 is set to ON, the screen will display when the current temperature is higher than or equal to TS1(the alarm value of external probe1), the buzzer will sound “BiBiBi”...
  • Page 22 The alarm sound will stop if the temperature returns to the set range, or you can press any button to cancel the alarm sound manually. Note: 1. Please insert the external Probe 1 and the external Probe 2 into the center of the thickest part of the meat, or insert 2 probes into different meat parts.

  • Page 23: Trouble Shooting

    Channel Switch Hold for 2 seconds to switch the temperature display of the foldable probe. The screen will restore to the default display 20 seconds later automatically if no operation is performed on the thermometer. Trouble Shooting When the foldable probe fails to work properly, the character“---”, Er will be displayed on the screen, please contact our customer service.

  • Page 24: Cautions

    Cautions The probe and wire must not touch the flame. Insert the probes into the thickest part of the meat, while avoiding bones and fat. If the temperature readings of the probes are too high or rise too fast, remove the probes from the meat. Clean and dry the probe after each use.

  • Page 25: Appendix

    Appendix Meat Temperature & Doneness Chart MEAT Rare M.Rare Medium M.Well Done 49℃/ 54℃/ 60℃/ 66℃/ Beef 77℃/170℉ 120℉ 130℉ 140℉ 150℉ 49℃/ 54℃/ 60℃/ 66℃/ 77℃/170℉ Veal 120℉ 130℉ 140℉ 150℉ 49℃/ 54℃/ 60℃/ 66℃/ 77℃/170℉ Lamb 120℉ 130℉ 140℉...
  • Page 28 INKBIRD TECH.C.L. Support@inkbird.com Factory address: 6th Floor, Building 713, Pengji Liantang Industrial Area, NO.2 Pengxing Rd, Luohu Disctrict, Shenzhen, China Office address: Room 1803, Guowei Building, NO.68 Guowei Rd, Xianhu Community, Liantang, Luohu District,Shenzhen, China V2.0...
  • Page 29 骑马钉 尺寸：80*160mm 2022.04.02修改内容： 1. 公司信息更改（去掉官网二维码， 去掉网址，增加办公地址） 2. 添加版本号；...
