VENETA 37103-64500-B How To Install

How to install your
Shutters with Reveal Frame
#37103-64500-B
measuring

Required Tools

tape
1

Included Hardware

Getting Started

The hardware can be found in Make sure ITEM# (Highlighted in the circle) matches on both panel boxes.
the small hardware box included
with your blind.
Dovetail Key
Do not dispose of packaging until the shutters are operating appropriately.
Hinge
Use of a moving blanket or drop cloth is recommended.
Pins
Find ample working space to assemble your frame (preferably in front of the window).
Check the diagram to make sure you have all the parts indicated for an appropriate
installation.
Long
2
Screws

Assemble the Frame

(For Frame
Installation)
1 Carefully remove panels and frames
from the packaging.
Do not mix panels or frames from other
Medium
windows. All frame pieces are labeled
Screws
(top, bottom, right, left).
(For T-post
Installation)
2 Set all frames on a soft, level surface (moving blankets or some type of pad works best).
Short
Position each side of the frame and line up the Dovetail Key slot.
Screws
(For Hinge
※ If not installing with T-POST, skip to #4.
Installation)
3 The top and bottom of the T-post are labeled. Locate and identify. Line up the pre-drilled
holes with the top and bottom frame and secure with screws provided. Fasten the T-post
with additional nails if necessary.
Plug
The T-post connector provides
some wiggle room, make sure the
T-post is at the center position at
each end and secure with two
screws. The T-post can also be
adjusted when gaps between
Hinge Spacer
panels are not even.
Difficulty:
drill with phillips bit or pencil
2mm bit screwdriver
How to install your
Shutters with Reveal Frame
#37103-64500-B
knife
4 Insert the Dovetail Key into each slot at the back of the frame. Use a rubber mallet if necessary.
1
The Dovetail Key has a rounded side and a flat side.
!
The rounded side should be inserted in slot first.
The frame is pre-drilled well in the top left and right frame, bottom
5
left and right frame, and in the middle of the top and bottom
frame. Double check that all the holes are pre-drilled before
placing the frame on the window.
Position the assembled frame evenly along the window opening against the window. by using a tape measure and shims.
6
Measure left & top frame for spacing
7 Once you have evenly spaced the frame into the window
opening, secure with a screw (pre-drill) into the upper left frame
ONLY. Shutter will be fully secured in later steps.
Once done, level the frame on the window.
8 Once the left side is secured, to keep the frame level and secure with a screw (pre-drill) into upper right frame. Shutter will be
fully secured in later steps.
1 1
2 3
With the rounded side of the Dovetail Key facing up,
push the top frame down onto the Dovetail Key.
Measure right & top frame for spacing
Only secure one screw into the top left frame.
Level the top frame. Only secure one screw into the top right frame.
Difficulty:
4
2
