Mora VDP645GB3 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Introduction
Note: Do not use the hob
until you have read the
instruction manual!
Your hob
2
Thank you for purchasing a new Gas Hob
Semirapid
gas burner
1750W
Rapid gas
burner
3000W
Even if you have used a gas hob before, it is important that you
read these instructions thoroughly before starting to cook, paying
particular attention to the installation and safety instructions. If you
have any problems with installing, operating, or cooking with your
hob, please check through these instructions thoroughly to make
sure that you have not missed anything.
WARNING! For your own safety, make sure that these instructions
on Installation, use and maintenance are followed.
We advise you to keep these instructions in a safe place for future
reference. If you sell or transfer ownership of this product, please
pass on these instructions to the new owner.
Applicable For gas
Type
Rapid gas burner
Semirapid gas burner
Auxiliary gas burner
Material
Flame failure device
Power Supply
Size (mm)
Built-in (mm)
Semirapid
gas burner
1750W
Auxiliary gas
burner
1000W
VDP645GB3
3000W
1750W
1000W
Glass
Yes
220V~50Hz
500x580x95
477x557

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VDP645GB3 and is the answer not in the manual?

Questions and answers

Related Manuals for Mora VDP645GB3

Summary of Contents for Mora VDP645GB3

  • Page 1 We advise you to keep these instructions in a safe place for future reference. If you sell or transfer ownership of this product, please pass on these instructions to the new owner. Your hob Applicable For gas Type VDP645GB3 Rapid gas burner 3000W Semirapid gas burner 1750W Auxiliary gas burner...

  • Page 2: Safety Instructions

    Cleaning VITREOUS ENAMEL Hotplate, burner caps, pan supports. Cloth wrung out in hot soapy water. Stubborn stains.can be removed with a cream paste approved by the Vitreous Enamel Development Council, liquid cleaner or by rubbing with fine steel wool soap pads. NOTE: The pan supports can also be cleaned in the dishwasher.

  • Page 3: Technical Information

    6. Do not use unstable pans and position handle away from the edge of the hob.The use of a suitable hob. 7. In the interests of safety and hygiene, ensure the hob is kept clean as a build up of grease could cause 8.

  • Page 4: Provision For Ventilation

    WARNING! The appliance must not be connected to a combustion products evacuation device. It shall be installed and connected in accordance with current installation regulations. Particular attention shall be given to the relevant instructions regarding ventilation. LOCATION The cooker may be located in a kitchen, kitchen/diner or a bed- sitting room, but not in a room containing a bath or shower.

  • Page 5: Unpacking The Appliance

    UNPACKING THE Remove all packaging before use and check to make sure that the APPLIANCE appliance is In perfect condition. If you have any doubts do not use the appliance and call your supplier. Some parts on the appliance are protected by a plastic film. This protective film must be removed before the appliance is used.

  • Page 6: Installation Options

    INSTALLATION OPTIONS OPTION: When fitting a gas hob above a drawer or standard housing unit, suitable precautions must be taken to prevent contact. with the casing of the hob, which becomes very hot during operation. The recommended method for overcoming this problem is to fix a wooden panel within the cabinet at a distance of 15mm below the underside of the hob (see fig 1).

  • Page 7: Gas Connection

    GAS CONNECTION The appliance's gas inlet fitting is a 1/2« male threaded conic gas type in accordance with the ISO 7-1 standards. Make the connection using rigid pipe. When making the gas connection, it is important to place the gasket (A) in between the inlet pipe (C) and the elbow (B), toensure a gas tight seal.
  • Page 8 Replace the injectors with the corresponding injector from the table on page below. (see fig. 6). First remove the burner caps and rings and with a socket spanner »B«, unscrew Injector »A« (see fig. 6). The adjustment of the reduced rate position is as follows (fig. 7): Light the burner and turn the knob to reduced rate position.
  • Page 9 User instructions 1. To light the hotplate push In the appropriate control knob and turn anti-clockwise to the large flame symbol (fig. 8). 2. Keep the knob depressed until the burner lights. 3. Turn the tap to the required setting. 4.

  • Page 10: Correct Disposal Of This Product

    CORRECT DISPOSAL OF This marking indicates that this product should not be disposed THIS PRODUCT with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled the sustainable reuse of material resources. waste disposal, recycle it responsibly to promote To return your used device, please use the return and collection systems or contact the retailer where the product was purchased.
  • Page 11 About ErP A) Measurement and calculation methods ● The gas hob was CE approval according to the Gas Appliance Directives 2009/142/EC. ● The energy efficiency of this gas hob was tested and measured according to EN 30-2-1-1998+A1-2003+A2-2005. ● The semi-rapid burner and rapid burner were tested separately;...
  • Page 12 ATTENTION!!!!! This appliance must be installed in compliance with the current provisions in force and only used in rooms equipped with adequate ventilation. Consult the instruction manual before proceeding with installation or use of the appliance...
