- Page 1 User Manual V1.0...
-
Page 2: Table Of Contents
CONTENT 1.SAFETY INSTRUCTIONS 2.SPECIFICATIONS 3.GETTING STARTED 4.OPERATION 5.ERROR CODES 6.WARRANTY... -
Page 3: Safety Instructions
1.SAFETY INSTRUCTIONS Please read the user manual and safety instructions carefully before using the appliance. 1 Disclaimer The manufacturer cannot be held responsible for the damage resulting from improper usage or incorrect operation. The use of accessories that are not recommended by manufacturer can cause injuries and will invalidate any warranty that you may have. - Page 4 Please use non-abrasive detergent to cleaning the interior/exterior of the fridge. Please don't scrap the interior of the fridge to defrost/de-ice the fridge. Please don't pressure-wash/spray the fridge with a running water hose. 4 Dos and Don’ts Do not expose the unit to moderate/heavy rain. Do not use this appliance near direct heat sources, such as flame or radiator.
- Page 5 5 INTENDED TO USE This appliance is intended to be used in household and similar applications such as: Staff kitchen areas in shops, offices and other working environments; Farm houses and hotels, motels and other residential type environments; Bed and meal environments; Catering and similar non-retail applications.
-
Page 6: Specifications
2.SPECIFICATIONS MODEL X50 616×351×560 mm External dimensions(LxWxH) (24.3x13.8x22.0 inch) Net weight 16.0 kg (35.3 lbs) Storage volume 50 liters (52.8 quarts) Supply voltage DC 12V/24V Rated current 7.8A/3.9A Temperature setting 20°C to + 20°C (-4°F to 68°F) 5V/2A(Output) 52.8Qt (50L) FRIDGE 250.4mm... -
Page 7: Getting Started
3.GETTING STARTE Some Reminders 1. If the device was not placed in the upright position after transit and delivery, please keep it upright for 24 hours to make sure that the compressor can work properly. 2. If the device can’t turn on or you encounter other problems for first time use, please contact us for help. -
Page 8: Operation
4.OPERATION The Power Button The Setting Button MAX ECO H M L °C °F 88.8 Temperature Adjustment Buttons 1 Switched-on/off With the unit plugged in, long press the Power Button “ ” to switch on/off the unit. 2. Temperature Adjustment Press corresponding “+”... - Page 9 3 Settings Menu With the unit turned on, press and hold the setting Button “ ” for 3 seconds to enter into the Settings Menu, which contains three functions, Battery Protection Settings(H/M/L), °C / °F Settings and MAX/ECO Settings. The target setting will flash on the gauge when press and hold the setting Button “...
- Page 10 4. Built-in Battery Operation How to charge the battery There are two ways to charge the battery: 1) Use the specific cord from us to charge the battery. When the battery is in the charging state, the light will flash. 2) When the battery is running out, the light of the battery will not be light up even though you long press the button.
- Page 11 Operating Mode and Battery Protection in different power supply (Battery or External Power Supply) Current Power Supply Battery Current Power Performed Operating Protection Supply Operation Mode Mode Plugged into Restore to the state before External Power the power is disconnected. Supply(AC/DC) No Power Supply...
- Page 12 Wireless Charging 1. Make sure that the device you used could support wireless charging and be placed in the charging area. Note: We suggest you can move up a bit if your phone could not be charging that was placed in the charging area, showing in Figure 3.
-
Page 13: Error Codes
5.ERROR CODES The fridge will get error codes when the fridge does not work properly. Error Codes E1 Low Input-Voltage Error The Input DC voltage is below the protection setting and the battery protection is activated. E2 Fan Error The cooling fan overloads with more than 1A Current. E3 Motor Start Error The motor of compressor is blocked or the pressure difference in the refrigeration system is too high. -
Page 14: Warranty
6.WARRANTY & RETURN 1 Warranty 3-year Warranty for The Compressor 1-year General Warranty For Warranty Registration, please contact us for more information. 2 Customer Service If the product is received damaged or defective, you can contact us via these ways: Customer Support Email: support@setpowerusa.com Amazon Message Service If you email us, these information needs to be included:... - Page 15 3 Return Policy Amazon-Fulfilled Order The postage is afforded by Amazon in Amazon return window. If the return window is expired but still in warranty, the return policy will be same as seller-fulfilled order. Seller-Fulfilled Order If the warranty is not expired, the postage is afforded when the return is confirmed to be caused by QUALITY ISSUE of our products.
- Page 16 OUR GUARANTEE SetPower product comes with a 3-year warranty on the compressor and 1 year warranty on all other parts for your peace of mind. In the unlikely event this product fails when used according to our user guide, we will either repair or replace it. For full warranty terms and conditions on this product, please see the user guide.
