Introduction

Used daily, Zephyr removes damaging moisture accumulation, dries earwax and removes
odors. Zephyr can make hearing instruments sound better, and it can extend zinc-air battery
life in high humidity locations.

Preparation for Use

1. Activate the desiccant: A disposable Dry-Brik
replaced every two months, is included. The Dry-Brik performs
two important functions: (1) to permanently remove the moisture
molecules that are released from the devices during the drying cycle,
and (2) to drive the relative humidity inside the box to a much lower
level than is possible with just a heater, thus maximizing the drying
capability.
To activate the Dry-Brik, remove the foil cover (Figure 1). Do not
remove the foil until you are ready to use the Dry-Brik, because
once it is removed the Dry-Brik will begin adsorbing moisture.
2. Record the activation date: To alert you when it is time for
replacement, a card is attached to each Dry-Brik. Write the date that
the Dry-Brik was placed in service on this card (Figure 2).
3. Place the activated Dry-Brik in Zephyr (Figure 3).
4. Connect the AC adapter: Plug the AC adapter into an electrical
outlet, then fit the small circular plug into the rear of the unit.
NOTE: Instructions for the optional rechargeable metal canister desiccant can be found on
page 18.

Operating Your Zephyr

1. Wipe excess moisture and earwax from your hearing aids before placing them in the drying
tray. You may leave the batteries in, but open the battery cover to allow for air circulation.
2. Close the lid and press the
above the /
on off
the unit will turn off automatically. Zephyr can also be turned off by pressing the
(Important)
/ button on the right side of the unit. The green indicator
on off
button will illuminate for the duration of the eight-hour cycle, after which
, which must be
®
4
1
2
3
/
on off
Group 4, Rev F
