It’s Exciting Lighting IEL-4402 Quick Start Manual

IEL-4402
Battery Powered White and Amber Flicker
Vertical Wall Sconce with Remote
Mounting Holes
Front of LED Back Plate
A

INSTALLATION

1. Remove rear battery cover and place 6 AA alkaline batteries (not included) with the polarity
as shown in the battery door. Replace battery cover.
IMPORTANT: pay careful attention to the polarity of the batteries and ensure they are inserted
in the correct direction as shown on the battery cover illustration. Failure to install batteries in
the correct direction may cause damage to the product.
2. Determine where the product is to be mounted and insert nail or screw (not provided) in the wall.
Mount LED Back Plate (B) on the wall by sliding it onto the nail or screw head like hanging a picture frame.
3. Slide the Sconce Cover (A) onto the LED Back Plate (B) by fitting the holes in the top of the Sconce Cover
(A) onto the Mounting Posts to hold it in place.
4. Push the Power Button located on the bottom of the unit to power the unit on.
To enter amber flicker LED mode, press again to switch from white LED to amber flicker LED.
Push the Power Button again to power the unit off.
5. Remote control instructions: Remove pull tab between the battery and the connector. To activate
light press either the white or the amber flicker button, To turn the light OFF at any time, press the
power button.
B
Mounting Posts
Power Button
Back of LED Back Plate
Battery Cover
C
REQUIRED
• AA Batteries
(Not Included)

CONTENTS

x2
• A - Sconce Cover* x1
x2
• B - LED Back Plate x1
x2
• C - Remote Control x1
*Sconce Cover may vary in style/shape
