8.5.4. Installation of the set
I-
Install the set in thrust between the floor and ceiling by means of unscrewing bolts item No. 67. After the upper supports touch
the ceiling make 1-3 rotations of bolt item No. 67 and fix it by nut item No. 77.
II-
Move the caps No. 14 down. Insert plugs item No. 87(Pic.6).
07.11.2017
II II
87 87
162 162
I I
77 77
67 67
Pic.6
12
84 84
8 8
