- Page 1 OPERATION MANUAL YZ15W/YZ25W series GREATERFLOW //Thank you for choosing NEXT peristaltic pump, please read this manual carefully before use to ensure correct operation, use effect and product maintenance.//...
- Page 2 Important information Please read the operating instruction manual carefully before operating this equipment. The content of this operation manual is for reference only. Chuangrui Pump Industry reserves the right to change the product (design or specification) without prior notice. 2021.08.12.0 version Safety warning Do not reach out and touch the roller when it is running! Before any cleaning or maintenance work, be sure to cut off the power supply.
-
Page 3: Table Of Contents
CONTENTS Precautions Tube precautions Roller recautions Knob adjustment Product storage Product description Product introduction Model comparison table Structure display Size(mm) Tube selection and flow reference Flow curve Operation Pump head installation and installation Tube installation Product maintenance Fault diagnosis and after sales Maintenance Warranty information Repair information... - Page 4 >>> INTRODUCTION YZ -w SERIES Precautions >> Precautions Please read the operating instruction manual carefully before operating this equipment. The staff responsible for the installation or maintenance of this equipment should have the experience and ability to carry out related work. When pumping dangerous liquids, please follow safety precautions.
-
Page 5: Product Description
Product description >> Product description Product introduction YZw series pump heads provide two options of a single channel or dual channel, and can also be used in series according to the customer's support requirements, Pump head maximum liquid volume can reach 3L/min per channel. The operation is simple, and the tube installation is convenient. - Page 6 Structure display Adjustable knob (Optional) Lever Pump head body Compression block Roller assembly Tube clamp Mounting hole- Pump head bolt Support block Size(mm) （Unit： mm）...
- Page 7 Tube selection and flow reference Model/Specification Flow range Pressure Pump head Tube （ml/min） （mpa） (ID*Wall thickness) mm 13# / 0.8X1.6 0.007-42 14# / 1.6X1.6 0.027-162 19# / 2.4X1.6 0.051-306 Silicone tube rubber tube YZ15w Viton tube 16# / 3.1X1.6 0.082-492 0.17 （Single channel）...
-
Page 8: Flow Curve
Flow curve YZ15m流量统计表 YZ15w-Single channel flow curve 2500 2280ml 2000 1740ml 1500 1020ml 1000 492ml 306ml 162ml 42ml Speed （rpm） YZ15w-Flow curve 3500 YZ25m流量统计表 YZ25w-Flow curve 3000 3000ml 2500 2280ml 2000 1740ml 1500 1020ml 1000 Speed （rpm） YZ25w-Flow curve... -
Page 9: Pump Head Installation
Operation and installation >> Operation and installation Pump head installation Positioning column Pump head bolt Coupling ①Insert the pump head shaft into the groove of the coupling; (The other end of the coupling connected with the output shaft of the motor) ②Align the Positioning hole with the positioning column of the pump head bracket, and insert the Pump head bolt;... -
Page 10: Tube Installation
Tube installation ①Turn the Lever 180°counterclockwise to open the compression block; ②Lift up the tube clamp on both sides respectively, and put the tube between the rollers and compression block; ③Turn the Lever 180°clockwise to close the compression block; ④Check the compression block reset and the tube clamp installation tube in place. Note: The pump head must use a tube with a standard wall thickness-P4. -
Page 11: Fault Diagnosis
Product maintenance and after sales >> Product maintenance and after sales Warning: Before attempting any maintenance work, be sure to cut off the power to the pump. Fault diagnosis >>Check if the coupling is damaged *The pump is turned on and the >>After cutting off the power, manually check pump head cannot run whether the pump head is rotating normally... -
Page 12: Warranty Information
Warranty information ·Warranty commitment ①The product has a one-year warranty period. If there is a failure during the warranty period, you can enjoy free maintenance and replacement of parts; if it is damaged by humans, it will not be included in the warranty scope. ②If the warranty period is exceeded, only cost will be charged for repairs. -
Page 13: Repair Information
⑤Damage caused by chemical erosion or long-term improper maintenance. ⑥Product failure caused by force majeure factors such as natural disasters. ⑦The operator fails to follow the corresponding operation suggestions and requirements, improper loading and unloading, improper maintenance, and improper operation. ⑧... - Page 14 ·We formulate the information in this document from a correct perspective, but We will not be responsible for any errors. ·If you need the latest version of the operation manual, please contact NEXT PUMPofficial. ·We will not be responsible for any loss caused by non-product quality problems or human errors.
