Summary of Contents for Backfire HALO NEW
- Page 1 HALO Remote User Guide...
- Page 2 A single button to power on/off your board and remote. Power Button: ON/OFF/Menu/Select Backfire boards can stay in standby mode for up to a day, within which the remote Turbo Button: Turbo Mode/Tank Turn can be used to power the board on or off.
- Page 3 User Guide BACKFIRE Dashboard Layout TRIP: 14 KM ODO: 1142 KM Enable Bluetooth Enabled Connect to the Backfire APP for Firmware Updates Enable Cruise Control Enabled Enable Unlocked Fingerprint Unlock Enabled Remote automatically locks itself after 6 seconds of inactivity to prevent accidental inputs...
-
Page 4: Auto-Pairing
BACKFIRE Pairing Instructions Hold the Power Button for 3 seconds to power ON/OFF the board. When both the remote and board are in the OFF state, hold the Power Button on both the board and remote at the same time for 3 seconds to pair. -
Page 5: Cruise Control Mode
In the event one or more of the cells are unbalanced, contact Remaining Capacity, Temperature, and Battery Health. the Backfire Support Team or use the [Blue: Healthy, Red: Unbalanced] Backfire Balance Charger to restore the pack to a healthy state... -
Page 6: Advanced Settings
BACKFIRE Advanced Settings Remote Power Board Power ECO SETTING Board Power Speed Motor & ESC TEMPERATURE : 80℃ Motor & ESC ECO Setting Acceleration MOTOR Acceleration 76℃ TEMPERATURE : Brake Braking Turbo Setting Select Motor & ESC to display their temperatures. -
Page 7: Charging Status
Delete Fingerprints The Safety Switch option enables/disables To remove all stored fingerprints, select the fingerprint unlock. Delete Fingerprints option. Single fingerprint delete is currently not supported. BACKFIRE Restore Factory Settings and Updating Firmware Turbo Setting Fingerprint Setting FIRMWARE Fingerprint Setting... - Page 8 BACKFIRE Tank Turn Mode TANK Press the Turbo Button twice to engage Tank Turn Mode. Press the Power Button once to disengage. Warning: Keep clear of the board when Tank Turn Mode is engaged. Standing on it may lead to serious injury.
- Page 9 产品使用指南 BACKFIRE Malfunctions Motor Stalled BOARD OVER CURRENT DISCONNECTED Board and Remote are Over-Current Protection Motor Stalled Disconnected Active Board Over Voltage ! Abnormal Voltage Throttle Failure ! Throttle Wheel Requires Calibration Board Over-Voltage Battery Cells out of Balance In the event you encounter any of these errors, please reach out to the Backfire Support Team for assistance.
- Page 10 Remote Low Power Remote Power Under 10% Board Power Under 5% Board Power Under 10% ESC High Temperature High Temperature Warning: ESC BACKFIRE Gear Ratio and Pole Pair Configurations Model Drive Type Gear Ratio Pole Pairs G2 Black Ranger X3...
- Page 11 CONTACT US Official Website：https://www.backfireboards.com/ Instagram You Tube...
- Page 12 Halo Remote User Guide...
