BGS technic 3260-1 Instruction Manual

TECHNICAL DATA

Strokes per min.:
Sawing depth:
Working Pressure:
Air Inlet:
Recommended air hose:
Length with blade:
Air Consuption:
Air exhaust:
Noise Level:
Vibration Level:
Weight:
CAUTION
Read and understand all rights and information in this manual.
Failure to comply with unconscious rights and information may include control and oversight.
Keep the operating instructions in a certain and controlled place for future reference.

SAFETY INSTRUCTIONS

•
Ensure that the tool is in the OFF position when it is connected to the compressed air
system.
•
Always wear approved safety glasses when using compressed air tools. Wear a suitable
respirator when dust is whirled up.
•
Only use accessories suitable for compressed air. Risk of injury.
•
Disconnect the tool from the compressed air supply before installing accessories or
performing maintenance or before the device is not in use.
•
Always use the tool with common sense. Do not wear loose clothing or jewelry that can be
caught by moving parts as it can cause injury. Only operate the tool at a safe distance from
yourself and others.
•
Observe the manufacturer's instructions for the compressed air system when installing
regulators, filters and other accessories.
•
Keep children and other unauthorized persons away from the work area.
•
Do not let children play with the tool or its packaging.

AIR SOURCE

Clean and dry air and a correct air pressure is recommended as air supply for this air tool.
Maximum of 90 PSI at the air tool is recommended for most air tools of this class. Check specifications
section for recommended pressure. (Depending on length of air hose and other circumstances, air
pressure at compressor may need to be increased to 100 PSI to ensure 90 PSI at the tool. Water in the air
hose and compressor tank contributes to reduced performance and damage of the air tool. Drain the air
tank and filters before each use and as necessary to keep the air supply dry. Hose length over 25" causes
loss in line pressure. Increase hose ID or increase compressor pressure to compensate the pressure
Use an in-line pressure regulator with gauge if air inlet pressure is critical.
BGS technic KG
Bandwirkerstr. 3
D-42929 Wermelskirchen
Air Body Saw
max. 9000
10 mm
90 PSI (6.3 Bar)
1/4" (6.3 mm)
3/8" (10 mm)
270 mm
1.8 CFM (51.6 l/min)
Front
LpA = 88.15 dB (A)
LwA = 99.15 dB (A)
ahd = 15.06 m/s²
K = 1.99 m/s²
0.65 Kg
Tel.: 02196 720480
Fax.: 02196 7204820
mail@bgs-technic.de
BGS 3260-1
www.bgstechnic.com
© BGS technic KG, Copying and further use not allowed
loss.
