Seabreeze 12H43ZGX Installation Instructions Manual

Mini-split heat pump

Advertisement

Quick Links

INSTALLATION
INSTRUCTIONS
MINI-SPLIT
HEAT PUMP
FOR MODELS:
12H43ZGX
18H43ZGX
950-0032-REV-E
12-14-06

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 12H43ZGX and is the answer not in the manual?

Questions and answers

Summary of Contents for Seabreeze 12H43ZGX

  • Page 1 INSTALLATION INSTRUCTIONS MINI-SPLIT HEAT PUMP FOR MODELS: 12H43ZGX 18H43ZGX 950-0032-REV-E 12-14-06...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS MODEL NUMBERS……………………………………………………………………………2 UNIT PARTS & FEATURES……………………………………………………………………3 INSTALLATION DIMENSION DIAGRAM……………………………………………………4 SAFETY WARNINGS……………………………………………………………………………5 SELECTION OF INSTALLATION LOCATIONS………………………………………………6 INDOOR UNIT INSTALLATION………………………………………………………………8 OUTDOOR UNIT INSTALLATION……………………………………………………………11 TESTING………………………………………………………………………………………13 PRINCIPLE……………………………………………………………………………………15 SPECIFICATIONS………………………………………………………………………………17 WARRANTY……………………………………………………………………………………18 TECHNICAL SUPPORT IF YOU NEED TECHNICAL SUPPORT PLEASE CALL 1-(704)504-8590 SEA BREEZE Installation Kit is recommended. Catalog number can be located on page 17.
  • Page 3: Model Numbers

    MODEL NUMBERS Heat Pump SYSTEM MODEL Indoor Unit 12H43ZIGX 12H43ZGX Outdoor Unit 12H43ZOGX 12,000 BTU 208-230 VAC 13 SEER SYSTEM MODEL Indoor Unit 18H43ZIGX 18H43ZGX Outdoor Unit 18H43ZOGX 18,000 BTU 208-230 VAC 13 SEER...
  • Page 4: Unit Parts & Features

    UNIT PARTS & FEATURES...
  • Page 5: Installation Dimension Diagram

    INSTALLATION DIMENSION DIAGRAM...
  • Page 6: Safety Warnings

    SAFETY WARNINGS Use Copper Wires only for Power Supply. Risk of electric shock can cause injury or death. Disconnect all electric power supplies before servicing or installation Do not use excessive torque on flare nuts during connection of the refrigeration tubes, or service valve on discharge line may be damaged. Do not install indoor unit in damp or wet locations.
  • Page 7: Selection Of Installation Locations

    SELECT INSTALLATION LOCATION : CAUTION The air conditioning unit must be installed by professional technicians. BASIC REQUIREMENTS FOR INSTALLATION POSITION Installation of Either unit in the following locations may cause malfunction. Locations exposed to: Machine oil Flammable or corrosive gasses High frequency waves (i.e.
  • Page 8 SELECT INSTALLATION LOCATION (Cont) ELECTRICAL SAFETY REQUIREMENTS The power supply must be of rated voltage via special circuit for air-conditioner. The power supply wire gauge is specified in page 9. Applicable voltage range: the normal operation range of voltage is 90%~110% of rated voltage. Do not pull the power cable with excessive force.
  • Page 9: Indoor Unit Installation

    INDOOR UNIT INSTALLATION INSTALL THE REAR PANEL-MOUNTING PLATE Always mount rear panel horizontally. Hold the rear panel on the wall where you want the unit to be located and ensure that it is level using a plumb line or level. Once leveled, mark the screw locations on the wall. Fasten the rear panel to the wall at the location marked using the screws supplied with the unit.
  • Page 10 INDOOR UNIT INSTALLATION (Cont) MODEL INTERCONNECTING POWER CIRCUIT WIRE GAUGE SUPPLY WIRE BREAKER GAUGE 12H43ZGX 16 AWG 14 AWG 15 AMP 18H43ZGX 16 AWG 14 AWG 20 AMP -Table 1- Terminal board diagram covering plate MODEL 12H43ZGX 18H43ZGX terminal board...
  • Page 11 INDOOR UNIT INSTALLATION (Cont) PREPARE REFRIGERATION LINES Refrigeration lines and wiring can be routed from the indoor unit several different ways using the cut-out access pieces on the back of the unit. Bend the refrigeration lines carefully to the position needed to align with the drilled piping hole. HANG INDOOR UNIT Bundle the refrigeration lines, drainage hose, and wiring conduit attached to the indoor unit and wrap them securely for enough length to extend through...
  • Page 12: Outdoor Unit Installation

    For longer line set lengths additional charge must be WEIGHED in per Table 2. Model Designed Length ft Refrigerants Charge oz/ft 12H43ZGX 18H43ZGX -Table 2- INSULATE/BUNDLE REFRIGERATION LINES AND WIRING Individually insulate all refrigeration lines and condensation drainage hose to ensure that they do not sweat.
  • Page 13 OUTDOOR UNIT INSTALLATION (Cont) CAUTION: DO NOT CROSS WIRE...
  • Page 14: Testing

    TESTING NOTE:   Installation MUST be complete prior to testing.   System MUST be tested prior to operation. LEAKAGE TEST Use standard A/C practices to properly check refrigeration tubes and connections for any leaks prior to system start up. AIR PURGING AND PRESSURE TEST Remove bonnet (cover) of gas valve on outdoor unit.
  • Page 15 TESTING (Cont) INSTALLATION VERIFICATION   Have both units been securely and firmly installed?   Are all piping connections secure?   Have the refrigeration lines been sufficiently insulated?   Have you verified the length of the connection pipes and the refrigerant capacity?  ...
  • Page 16: Principle

    PRINCIPLE COOLING MODE Principle: The air conditioner absorbs heat from indoor air and transmits it outdoors for discharge, hence to decrease the indoor ambient temperature. The cooling capacity decreases with the rise of outdoor ambient temperature. Anti-freeze Function: If the air conditioner is running under low-temperature cooling mode, frost will appear on the surface of indoor heat exchanger.
  • Page 17 PRINCIPLE (Cont) Air Conditioner is Unable to Run Normally Protection device might be activated within such temperature range as Table 3, so that the unit might be stopped. Heating Mode Cooling Mode Dehumidify Mode ≥75°F or ≤20°F ≥109°F Outdoor Temperature ≥80°F ≤70°F ≤64°F...
  • Page 18: Specifications

    MINI-SPLIT SPECIFICATIONS 12H43ZGX 18H43ZGX Model COOLING/HEATING COOLING/HEATING Function Rated Voltage 208~230 VAC 208~230 VAC Rated Frequency 60Hz 60Hz Cooling/Heating Capacity (BTU/h) 12000/13000 18000/20000 SEER Cooling/Heating Power Input (W) 1150/1250 1720/1750 Cooling/Heating Rated Input (W) 1100/1200 1350/1800 Cooling/Heating Rated Current (A) 5.5/6.5...
  • Page 19: Warranty

    WARRANTY SEA BREEZE AIR warrants the accompanying split air conditioner or heat pump system to be free of defects in material and workmanship for the applications specified in the operation manual and installation manual for a period of one (1) year on parts and five (5) years on compressor, valid from the date of original retail purchase in the United States or Canada.
