- 1 Part List
- 2 Hardware List
- 3 Step 1. Lay Right Arm Panel (Part A) Upside down on a Soft Flat Surface
- 4 Step 2. Attach Seat Panel (Part D) and Stretcher (Part E) to Right Arm Panel (Part A)
- 5 Step 3. Attach Left Arm Panel (Part B) to Assembled Unit (Parts A, C, D, & E)
- 6 Step 4. Carefully Turn Unit Upright on a Flat Surface
- Download this manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Crosley Furniture CO7166
Summary of Contents for Crosley Furniture CO7166
- Page 1 Outdoor Wicker Rocking Chair CO7166...
- Page 2 PART LIST Right Arm Panel Left Arm Panel Back Panel Seat Panel Stretcher 1 PC 1 PC 1 PC 1 PC 1 PC HARDWARE LIST M6*40mm M6mm M6*15mm M6mm M6mm Short Bolt Long Bolt Flat Washer Allen Wrench 1 PC 8 PCS (Extra 1) 6 PCS (Extra 1) 2 PCS (Extra 1)
- Page 3 Step 1. Lay right arm panel (part A) upside down on a soft flat surface, such as carpet, as shown below. Attach back panel (part C) to right arm panel (part A) using short bolts (part #1), flat washers (part #3) and allen wrench (part #4). NOTE: Please do not fully tighten bolts until unit is fully assembled.
- Page 4 Step 3. Attach left arm panel (part B) to assembled unit (parts A, C, D, & E) using short bolts (part #1), long bolt (part #2), flat washers (part #3) and allen wrench (part #4). NOTE: Please fully tighten all bolts at this time. Step 4.
