WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED
EXACTLY, A FIRE MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL
INJURY, OR LOSS OF LIFE.
-- Do not store or use gasoline or other flammable vapors and liquids in vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do not use any phone in your building.
Immediately call your gas supplier from a neighbor's phone. Follow the
gas supplier's instructions.
If you cannot reach your gas supplier, call the fire department.
-- Installation and service must be performed by a qualified installer, service
agency or the gas supplier.
This is an unvented gas-fired heater. It uses air (oxygen) from the room in which
it is installed. Provisions for adequate combustion and ventilation air must be
provided. Refer to Air For Combustion and Ventilation section on page 5 of this
manual.
INSTALLER: DO NOT DISCARD THIS MANUAL – LEAVE FOR HOMEOWNER'S
FUTURE REFERENCE.
This appliance may be installed in an aftermarket, permanently located, manufactured
(mobile) home, where not prohibited by local codes.This appliance is only for use
with the type of gas indicated on the rating plate. This appliance is not convertible
for use with other gases.
Questions about installation, operation, or troubleshooting? Before returning to your retailer, call
customer service department toll-free at 800-845-5301.
CAUTION - FOR YOUR SAFETY
1
Yellow Flame Dual
Burner Chassis
MODEL: EW18NM
EW18PM
EW18PV
EW24NM
EW24NV
EW24PM
EW24PV
EW18NV
EWL030-01
Advertisement
Table of Contents
Related Manuals for Everwarm EW18NM
Summary of Contents for Everwarm EW18NM
- Page 1 Yellow Flame Dual Burner Chassis MODEL: EW18NM EW18NV EW18PM EW18PV EW24NM EW24NV EW24PM EW24PV CAUTION - FOR YOUR SAFETY WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY, OR LOSS OF LIFE.
-
Page 2: Table Of Contents
BEFORE USING THIS APPLIANCE IMPORTANT: Read instructions and warnings carefully before starting installation. Failure to fol- low these instructions may result in a possible fire hazard and will void the warranty. PRODUCT SPECIFICATIONS MODEL # EW18NM EW18PM EW24NM EW24PM Gas Type... -
Page 3: Important Safety Information
WARNING: Keep the appliance area clear and free from combustible materials, gasoline, and other flam- mable vapors and liquids. WARNING: Model EW18NM, EW24NM, EW18NV, EW24NV are equipped for natural gas. Field conversion is not permitted. Model EW18PM, EW24PM, EW18PV, EW24PV are equipped for propane gas. Field conver- sion is not permitted. - Page 4 Do not place propane/LP supply tank(s) inside any structure. Store propane/LP supply tank(s) outdoors. 2.. If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. •...
-
Page 5: Air For Combustion And Ventilation
AIR FOR COMBUSTION AND VENTILATION WARNING: If the area in which the heater may be operated does not meet the required volume for indoor combustion air, combustion and ventilation air shall be provided by one of the methods described in the National Fuel Gas Code, ANSI Z223.1/NFPA 54, the International Fuel Gas Code, or applicable local codes. - Page 6 DETERMINING FRESH-AIR FLOW FOR HEATER LOCATION Determining if You Have a Confined or Unconfined Space Use this worksheet to determine if you have a confined or unconfined space. Space: Includes the room in which you will install heater plus any adjoining rooms with doorless passageways or ventilation grills between the rooms.
-
Page 7: Product Features
Ventilation Air From Inside Building 12 in. This fresh air would come from adjoining unconfined space. When ventilating to an adjoining unconfined space, you Ventilation Grills Ventilation must provide two permanent openings: one within 12 inches Or Remove Into adjoining Room, Grills of the wall connecting the two spaces (see options 1 and Door Into... -
Page 8: Preparing For Installation
PREPARING FOR INSTALLATION Before beginning assembly or operation of the product, make sure all parts are present. Compare parts with package contents list. If any part is missing or damaged, do not attempt to assemble, install or operate the product. Contact customer service for replacement parts. - Page 9 WARNING: Before installing in a solid flue burning firebox, the chimney flue and firebox must be cleaned of soot, creosote, ashes and loose paint by a qualified chimney cleaner. Creosote will ignite if highly heated. A dirty chimney flue may create and distribute soot within the house. Inspect chimney flue for damage. Minimum Fireplace Clearance to Combustible Materials WARNING: Maintain the minimum clearances.
- Page 10 If Using Mantel You must have noncombustible material(s) (such as slate, marble, tile, etc). at least 1/2 in. thick. With sheet metal, you must have noncombustible material behind it. Noncombustible material must extend at least 8 inches up. If noncombustible material is less than 12 in., you must install the fireplace hood accessory. Even if noncombustible material is more than 12 in., you may need the hood accessory to deflect heat away from mantel shelf.
- Page 11 Mantel Shelf INSTALLING DAMPER CLAMP ACCESSORY Underside of FOR VENTED OPERATION Mantel Shelf A l l m i n i m u m distances are in NOTE: When used as a vented heater, appliance must be inches installed only in a solid-fuel burning fireplace with a working flue constructed of noncombustible material.
-
Page 12: Installation
INSTALLING HEATER BASE ASSEMBLY CAUTION: Do not remove the metal data plates attached to the heater base assembly. The data plates contain important warranty Information. WARNING: You must secure this heater to fireplace floor. If not, heater will move when you adjust controls. Mov- ing heater may cause a gas leak. - Page 13 A CSA/AGA design-certified equipment shutoff valve with Fitting 1/8-inch NPT tap is an acceptable alternative to test gauge connec- Heater Gas tion. Purchase the optional CSA/AGA design-certified equipment Regulator shutoff valve from your dealer. The installer must supply an external regulator. The external regula- tor will reduce incoming gas pressure.
-
Page 14: Checking Gas Connections
CHECKING GAS CONNECTIONS WARNING: Test all gas piping and connections for leaks after installing or servicing. Correct all leaks at once. WARNING: Never use an open flame to check for leaks. Apply a mixture of liquid soap and water to all joints. - Page 15 ELECTRICAL WIRING (MILLIVOLT) CAUTION: Label all wires prior to disconnection when servicing controls. wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. The millivolt valve is a self-powered combination gas control that does not require 110 VAC to OPERATE. Figure 16 Wiring Diagram...
-
Page 16: Operation
OPERATION Avoid any drafts that alter burner flame patterns. Do not allow fans to blow directly into the fireplace. Do not place a blower inside the burn area of the firebox. Ceiling fans may create drafts that alter flame patterns. Sooting and improper burning will result. - Page 17 LIGHTING INSTRUCTIONS 1. STOP! Read “ FOR YOUR SAFETY ” on page 16. 2. Unscrew ignitor cap and install a AAA type battery with the anode (+) pointing out. Replace cap. 3. Make sure manual shutoff valve is fully open. 4.
- Page 18 INSPECTING BURNERS Check pilot flame pattern and burner flame patterns often. PILOT FLAME PATTERN Figure 19 shows a correct pilot flame pattern. Figure 20 shows an incorrect pilot flame pattern. The incorrect pilot flame is not touching the thermocouple. This will cause he thermocouple to cool. When the thermocouple cools, the heater will shut down.
-
Page 19: Care And Maintenance
CARE AND MAINTENANCE WARNING: Turn off heater and let cool before cleaning. CAUTION: You must keep control areas, burner, and circulating air passageways of heater clean. Inspect these areas of heater before each use. Have heater inspected yearly by a qualified service technician. Heater may need more frequent cleaning due to excessive lint from carpeting, bedding material, pet hair, etc. -
Page 20: Troubleshooting
TROUBLESHOOTING WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions. •... - Page 21 PROBLEM POSSIBLE CAUSE REMEDY Control knob not fully pressed in. Pressed in control knob fully. When ignitor button is pressed in, After ODS/pilot lights, keep control Control knob not pressed in long there is a spark at ODS/pilot but no enough.
- Page 22 PROBLEM POSSIBLE CAUSE REMEDY White powder residue forming within When heated, vapors from furniture 1. Turn heater off when using furniture burner box or on adjacent walls or polish, wax, carpet cleaners, etc., turn polish, wax, carpet cleaner or similar furniture.
-
Page 23: Replacement Parts
REPLACEMENT PARTS NOTE: Use only original replacement parts. This will protect your warranty coverage for parts replaced under warranty. PARTS UNDER WARRANTY Contact authorized dealers of this product. If they can’t supply original replacement parts, call Customer Service toll free at 800-845-5301 for referral information. When calling Customer Service or your dealer, have ready: •... - Page 24 PARTS LIST (EW18NM, EW18PM, EW24NM, EW24PM) This list contains replaceable parts for your heater. When ordering replacement parts, follow the instructions listed under Replacement Parts on page 23 of this manual. Part Number Description EW18NM EW18PM EW24NM EW24PM WYL005-01F WYL005-01F...
- Page 25 PARTS LIST (EW18NV, EW18PV, EW24NV, EW24PV) This list contains replaceable parts for your heater. When ordering replacement parts, follow the instructions listed under Replacement Parts on page 23 of this manual. Part Number Description EW18NV EW18PV EW24NV EW24PV WYL005-01F WYL005-01F WYL005-01F WYL005-01F Front Log Bracket...
