- Page 1 User Manual User Manual Panini Grills Models: 177P78, 177P84, 177P70S, 177P75SG, 177P85S, 177P88SG 10/2013 Please read and keep these instructions. Indoor use only. www.AvantcoEquipment.com...
- Page 2 User Manual Thank you for purchasing and using our Panini/Sandwich Grill. To make best use of this product and avoid damage and injury, please read this manual carefully before using the machine, and keep it handy for future reference. The Sandwich Grill design combines the advantages of stylish design, efficient construction, ease of operation and simple maintenance.
-
Page 3: Important Features
User Manual Notes 1. This product is intended for commercial use only. 2. Do not disassemble or modify the machine. 3. Lift the upper grill assembly smoothly; jerking it up may cause damage or injury. 4. Before cleaning, disconnect power and allow machine to cool. 5. -
Page 4: Specifications
User Manual Specifications Single Panini Grill Double Sandwich Grill Model Number P78, P70S, P75SG P84, P85S, P88SG Voltage 120V, 60 Hz 120V, 60 Hz Power 1.75 Kw 2x1.75 Kw Temp. Controls Temp. Range 120 F - 570 F 120 F- 570 F Upper Grill (overall) 13"x 8 3/4"... -
Page 5: Cleaning And Maintenance
User Manual Cleaning and Maintenance 1. Disconnect machine before cleaning and allow to cool. 2. Use only a damp towel with non-corrosive cleaner. Do not immerse or flush with water. 3. Wipe down outside surface to remove any soil. 4. Store in a dry clean area when not in use. Attack tough grease, oil, and carbon with this ready to use decarbonizer and degreaser. - Page 6 User Manual Single Grill Parts List Parts List Single Grill 1. Power Light 26. Upper Platen 2. Temperature Control with Switch 27. Upper Heater 1. Power Light 26. Upper Platen 3. Screw M4x6 28. Wiring Guide Tube 2. Temperature Control with Switch 27.
- Page 7 User Manual Double Grill Parts List Parts List Double Grill 1. Power Light 26. Upper Platen 2. Temperature Control with Switch 27. Upper Heater 3. Screw M4x6 28. Wiring Guide Tube 1. Power Light 26. Upper Platen 4. Heating Cycle Indicator 29.
- Page 8 User Manual www.AvantcoEquipment.com...
- Page 9 User Manual www.AvantcoEquipment.com...
