ALTRAN RM09-43L Instructions Manual

TECHNICAL DATA
SHEET
MOTORIZED
RM0943-L BATTERY
PRODUCT INFORMATION:
• System: tecnical motorized rail, highly efficient for
medium duty curtains.
• Preferences: complex installations where a resistant
rail is required and with no access to light points.
• Material: aluminium profile alloy 6063/T5. Plastic
accessories: acetyl resin. Metal accessories:
calibrated iron plate for cold stamping. Stainless
steel.
• Brackets: multiple choice including special swivel
and/or extrastrong brackets.
• Sliding: multiple choice including wheeled runners
(w/metallic ring to increase resistance), and perfect
wave corded runners in spaces 6 and 8mm.
• Installation: safe and reliable with multiple ceiling
brackets. Wall white metal brackets available.
• Bendable: by machine in continuous arch or angle.
Minimum radius 35 cm.
• Opening: lateral and central modes.
• Maximum lenght w/o splice: 6 m.
• Loading capacity: refer to table on pg 3
• Colour: lacquered white. Other colour options
available on request (MOQ).
• Coating: lacquered polyester with a minimum of 60
micras. Electrostatic paint. Track with patented self-
lubricating design to minimize runners friction.
• Accessories/control devices/sizes: refer to our
catalogue (motorized section).
Ctra. Valencia-Ademuz Km 21,9
46181 · Benissanó · Valencia · España (Spain)
Tel.: (+34) 96 113 61 53 · Fax: (+34) 96 113 61 27
www.altransolutions.es · info@altransolutions.es
Contract - Theaters - Concert Halls - Hotels -
Heavy duty installations or motorized/home automation
OPTIONS:
Available for traditional fabric curtains, perfect wave
curtains, and pleated curtains.
MOTOR OVERVIEW:
• Motor DC silencioso.
• Tecnología de Toque Automático, tirando suavemente
de la cortina para abrir o cerrar.
• Sistema especial patentado de embrague con opción
manual en caso de falta de energía.
• Búsqueda automática de los límites.
• La función de Toque Automático puede activarse y
desactivarse.
• Función disponible de arranque y parado lento.
• Receptor integrado en el mecanismo.
• Fácil de instalar y de emplear.
• Riel de Aluminio RM09 con phoresis electrónico
altamente resistente disponible para este motor. El
Riel se puede curvar.
• Correa dentada resistente para cortinas pesadas y/o
uso frecuente de la motorización.
• Con la interfaz de contacto seco, proporcionando el
punto de acción, o incluso el patrón de movimiento del
interruptor de control remoto, facilita el logro de una
gran variedad de modos de control.
PREFERENTIAL USE:
Residences
needs
VA-24/11/2020
