  • Page 1 Owner’s guide: HD1224 / HD1824 / HD2524 HDI1824 / HDI3024 Install using Tundra CM Series installation kit Ask your retailer ! (See page 4 for details) www.tundrainternational.com...
  • Page 2: Table Of Contents

    Table of contents INTRODUCTION ............................. 3 Disclaimer ................................3 Output waveform ..............................3 FRONT , REAR PANEL & REMOTE CONTROL ................3 PERMANENT INSTALLATION ......................4 Recommended material ............................. 4 Recommended tools ............................5 Where to install ..............................5 Mounting the inverter ............................5 Ground ................................
  • Page 3: Introduction

    1 Introduction Congratulations! You have purchased one of the most sophisticated and reliable power inverters on the market today. Incorporating some of the latest technological developments, it will give years of trouble free operation for your truck, boat, R.V. or other. In order to get the most out of your inverter, the installation procedure must be followed carefully and it must also be properly used.
  • Page 4: Permanent Installation

    3 Permanent Installation The use of the Tundra International installation kits is strongly recommended. These complete installation kits are custom designed to maximize performance. It has been developed to promote safe installation and to help eliminate the difficult task of sourcing the requisite and right material.
  • Page 5: Recommended Tools

    Recommended tools Hand held crimping tool for terminal lugs * Mandatory Hollow punch or hole saw for metal Drill bit set for metal Screw driver set Open end wrench set Side cutters Power drill CAUTION! Before installation, make sure that the inverter is turned “OFF.” Where to install Your inverter should be installed in a location that meets the following requirements: - Dry:...
  • Page 6: Ground

    Figure 3 : Installation schema Ground The inverter has a lug on the rear panel that must be connected, using a #8 AWG copper cable, to the chassis of your vehicle or to a metallic panel connected to the chassis. This grounding procedure conforms to most electrical codes that require to derived AC sources to ground in case of malfunctioning.
  • Page 7: Preparation Of The Cable Connected To The Negative Side

    Figure 4 : Terminals’ crimping procedure 3.5.1.1 Fuse A main fuse must be installed in the battery casing on the positive cable (+) between the batteries and the inverter, as close as possible to the batteries. In this way (and in the event of cable rupture), the DC current would be cut at the batteries and would not cause a fire.
  • Page 8: Connection Of The Batteries

    If you are unsure about powering any device with a modified sine wave power inverter, contact the manufacturer of the device. None of these potential problems can happen with the Tundra International pure sine wave inverters (HTS series). HD(i)-24V-GD-0111-EN...
  • Page 9: Microwave

    Microwave The power rating used with microwave ovens is the cooking power which refers to the power being delivered to the food being cooked. The actual operating power requirement rating is 40% to 100% higher than the advertised cooking power. The actual power consumption is usually stated on the back of the microwave.
  • Page 10: Troubleshooting Guide

    Troubleshooting guide Problem Possible cause Solution Low output voltage (96 to 105 volts) Using a voltmeter which cannot Use a TRUE RMS reading voltmeter properly read the RMS voltage of a modified sine wave Fault indicator ON Low input voltage Not enough battery capacity Recharge batteries Improper installation.
  • Page 11: Specifications

    8 Limited one-year warranty Tundra International Inc. warrants its power inverters against defects in workmanship and materials for a period of one (1) year from the date of first consumer purchase. This warranty is given only to the first end-use purchaser of the product.
  • Page 12 * PLEASE CONTACT US AT 450-649-2470 OR 1-877-964-2582 FOR A RETURN AUTHORIZATION NUMBER * Customer’s Name: Consumer Purchase Date: Model: Serial Number: DESCRIPTION OF THE PROBLEM: TUNDRA INTERNATIONAL INC. 2041-A, Leonard-de Vinci, Sainte-Julie (Quebec) Canada J3E 1Z2 Tel : 450.649.2470 / 1.877.964.2582 Fax : 1.888.855.9834...
  • Page 13 The above information, along with the proof of the consumer’s purchase date, such as the duplicate of the receipt, must be included with the defective unit. HD(i)-24V-GD-0111-EN...
