12 INCH MITER SAW WITH LASER
CALIFORNIA PROPOSITION 65
WARNING: You can create dust
when you cut, sand, drill or grind
materials such as wood, paint,
metal, concrete, cement, or other
masonry. This dust often
contains chemicals known to
cause cancer, birth defects, or
other reproductive harm. Wear
protective gear.
WARNING: This product or its
power cord may contain
chemicals, including lead,
known to the State of California
to cause cancer and birth
defects or other reproductive
harm. Wash hands after
handling.
CAUTION:
FOR YOUR OWN SAFETY READ
INSTRUCTION MANUAL
COMPLETELY AND CAREFULLY
BEFORE OPERATING THIS
MITER SAW.
WARNING!
Read and understand all
instructions.
Failure to follow all
instructions listed below may result
in electrical shock, fire and/or
serious personal injury.
For Customer Service, please call 1-800-358-5004 or email feedback@natitools.com
SPECIFICATIONS
Motor: 120V/15A
Speed: 4100 RPM
Blade Diameter: 12 inch
Table Tilting Range:
Saw Body Tilting Range:0-45
SAVE THESE
INSTRUCTIONS
SAFETY INFORMATION
Always wear proper safety
protection; safety goggles
should be worn at all times.
Dust mask, non-skid safety
shoes, hardhat, or hearing
protection should also be worn
at appropriate times.
Do not operate in the presence
of explosive materials, such as
flammable liquids, gases, or
dust.
Maintain tools with care. Keep
blades sharp and clean. If the
blade is broken or deformed,
replace immediately.
Be careful not to damage the
output spindle, flanges
(especially the fitting surfaces)
and the bolt. Check whether the
saw blade is in good condition.
Use the special flanges
provided for this tool only.
Secure the saw to a
workbench or table before
°
°
L-45
R-45
use to prevent unexpected
°
saw movement.
Make sure that the work area
is clear of debris before
starting.
Before cutting, make sure
that the work piece is free of
nails, screws, or other foreign
objects.
Make sure that the armature
shaft is free from lock by the
shaft-locking arm before you
turn it on.
Make sure that the saw blade
will not touch the rotary table
when the saw blade is in its
lowest position.
Never operate this tool with
one hand. Secure work piece
with the vise, never secure
the work piece by hand.
Hold the handle firmly.
Never let your hands get
close to the cutting line; do
not touch the saw blade.
Model: 8637
8808637
07/10
