10 INCH COMPOUND MITER SAW
CALIFORNIA PROPOSITION 65
WARNING: You can create dust
when you cut, sand, drill or grind
materials such as wood, paint,
metal, concrete, cement, or other
masonry. This dust often
contains chemicals known to
cause cancer, birth defects, or
other reproductive harm. Wear
protective gear.
WARNING: This product or its
power cord may contain
chemicals, including lead,
known to the State of California
to cause cancer and birth
defects or other reproductive
harm. Wash hands after
handling.
CAUTION:
FOR YOUR OWN SAFETY READ
INSTRUCTION MANUAL
COMPLETELY AND CAREFULLY
BEFORE OPERATING THIS 10
INCH COMPOUND MITER SAW.
SAVE THESE
INSTRUCTIONS FOR
FUTURE REFERENCE.
For Customer Service, please call 1-800-348-5004 or
email feedback@natitools.com
SPECIFICATIONS
Voltage: 120V AC 60Hz
Rated Current: 15A
No-Load Speed: 5000 RPM
Blade Diameter: 10"
Miter Adjusting Range:0-45º
(Left or Right)
Bevel Adjusting Range: 0-45º
(Left)
Max Cut at:
45º(Left): 1-3/4 in. x 2 5/8 in.
0º(Upright): 2-7/8 in. X 4-3/4 in.
Laser Classification: Class II
Max Radiant Power: 1MW
Wavelength: 635-670 NM
INTENDED USE
This product is intended for
consumer use only. This tool is
not designed for commercial
use. The power cord should
only be used in grounded
electrical outlets. Failure to use
the proper power cords and/or
extension cords may result in
fire or possible damage to Miter
Saw.
WARNING: READ
AND UNDERSTAND
ALL INSTRUCTIONS
Model: 8633
Failure to follow all
instructions in this manual
may result in severe personal
injury or death. Keep this
manual and refer to it for
Safety Instructions, Operating
Procedures, and Warranty.
SAFETY
INSTRUCTIONS
WORK AREA
•Keep work area clean and
well lit. Cluttered
workbenches and dark work
areas may cause accidents or
injury.
•Do not operate power tools
in explosive areas, such as in
the presence of flammable
liquids, gases, or dust. Power
tools create sparks, which
may ignite dust or fumes.
•Keep bystanders, children,
and visitors away while
operating a power tool.
Distractions can cause you to
loose control.
•Make your workshop kid
proof with padlocks, master
switches, or by removing
starter keys.
8808633
07/10
Advertisement
Table of Contents
Related Manuals for North American Tool 8633
Summary of Contents for North American Tool 8633
-
Page 1: Safety Instructions
10 INCH COMPOUND MITER SAW Model: 8633 CALIFORNIA PROPOSITION 65 SPECIFICATIONS Failure to follow all instructions in this manual WARNING: You can create dust Voltage: 120V AC 60Hz may result in severe personal when you cut, sand, drill or grind Rated Current: 15A injury or death. -
Page 2: Electrical Safety
ELECTRICAL SAFETY extension cord is heavy enough correct tool for the application. to carry the current needed by •This tool is equipped with an •Do not use tool if the switch does the saw (see ELECTRICAL electric cord having an not turn it ON or OFF. -
Page 3: Extension Cord Usage
shock. This tool is equipped Figure 1. The tool has a motor. Using extension cords with with an electric cord having an grounding plug that looks like the smaller than recommended wire equipment-grounding conductor plug illustrated in Figure 1. A gauge run the risk of getting too and a grounding plug. - Page 4 prong off the power cord. possible severe injury to the into the AC outlet. operator. •Wear proper apparel. Do not •NEVER use a dull blade. wear loose clothing, gloves, •Do not perform any operation •Make sure the blade is properly neckties, rings, bracelets, or freehand.
-
Page 5: Assembling Table Extensions
•Mount the saw to a workbench instructions carefully. from the side using thumbscrews. or table before use to prevent •Use only blades specifically unexpected saw movement. made for cutting non-ferrous •NEVER lubricate the blade metal. while it is in motion. •Non-ferrous metals should be •Before moving the saw, make cut only under the supervision of... -
Page 6: Laser Guide
plywood which can then be resulting from not following these begins to dim, change both clamped to your work support or instructions will be refused. batteries. NEVER mix old moved to other jobsites to re- batteries with new. •Never operate laser if the unit is clamp. -
Page 7: Aligning The Laser
2. Place the work piece on the 4. Move the laser assembly 2. Using a 1/2 inch wrench (not miter table. sideways. provided), loosen the Bevel adjusting jam nut and turn the 3. Turn the laser switch to the 5. Repeat steps 2 and 4 until bolt until red indicator points to 0º... -
Page 8: Making A Miter Cut
•against the fence while cutting. Bevel into position. MAKING A BEVEL CUT Do not remove your hand until 5. Pull the Handle Lock on the CAUTION: Before cutting, after the trigger is released and right side of the Miter Saw to position your body out of the the blade has stopped spinning. -
Page 9: Maintenance And Cleaning
and then use the socket wrench under or around your saw. text to tighten the hex bolt securely •Vacuum or use compressed air counterclockwise while pressing to keep the area clean. the shaft lock. •Empty the sawdust bag 4. Return the Lower Guard and frequently. - Page 10 North American Tool Industries (NATI) makes every effort to ensure that this product meets high quality and durability standards. NATI warrants to the original retail consumer a 1-year limited warranty from the date the product was purchased at retail and each product is free from defects in materials.
- Page 11 10 Inch Compound Miter Saw For Customer Service, please call 1-800-348-5004 or 8808633 07/10 email feedback@natitools.com...
- Page 12 Description Quantity Description Quantity Trigger Switch Lower Guard Laser Switch/Battery Housing Table Extension Rails Main Handle Dust Bag Laser Aperture Wrench Upper Guard Vise Power Cord Miter Table Groove Shaft Lock Motor Brushes Dust Port Table Extension Mounting Thumbscrew Handle Lock Carrying Handle Bevel Adjustment Hex Bolts Bevel Stops...
