Hacousto Holland bv
Industrieweg 87
2651BC Berkel & Rodenrijs
4E-FMTC installation and user guide
SUMMARY
This document includes both installation and user guides of the 4E-FMTC, the dual-mode
(commercial/fireman) microphone station with touchscreen for the Compact 500 Voice Evacuation System.
It explains how the 4E-FMTC should be installed and configured. The installation instructions are addressed
to trained technical personnel, such as installers, service technicians and commissioning engineers. The user
instructions explain how to operate the 4E-FMTC and how to interpret indications by end users as well as
technical personnel, such as service technicians.
Rev.
Date
REVISION AND APPROVAL
01
24-06-2018
02
05-06-2020
Page 1 of 17
Nature of Changes
Original draft
Corrections
Author:
Approved By
DD
TvdH
DD
Advertisement
Table of Contents
Related Manuals for 4EVAC 4E-FMTC
Summary of Contents for 4EVAC 4E-FMTC
- Page 1 It explains how the 4E-FMTC should be installed and configured. The installation instructions are addressed to trained technical personnel, such as installers, service technicians and commissioning engineers. The user instructions explain how to operate the 4E-FMTC and how to interpret indications by end users as well as technical personnel, such as service technicians.
-
Page 2: Table Of Contents
2651BC Berkel & Rodenrijs Author: 4E-FMTC installation and user guide Table of Contents 1. What is the 4E-FMTC? ................................3 2. Where do I start? ..................................3 3. Configuration settings ................................4 4. Hardware installation and settings ............................ 5 L-Net ....................................5 4.1.1. -
Page 3: What Is The 4E-Fmtc
(fireman’s door open), where emergency messages and fireman’s microphone is available. 4E-FMTC is connected to the L-Net interface of the Compact 500 main unit and may be daisy-chained with more L-Net devices. The 4E-FMTC is dedicated for call points where both general purpose paging and emergency evacuation management is necessary. -
Page 4: Configuration Settings
4E-FMTC installation and user guide 3. Configuration settings Settings for the 4E-FMTC are included in the configuration file located onto the micro SD memory card installed in the Compact 500 main unit. The configuration file includes user-defined settings, such as:... -
Page 5: Hardware Installation And Settings
4. Hardware installation and settings L-Net 4E-FMTC is a remote station connected to the L-Net port of the C500 main unit. Multiple 4E-FMTC stations may be used in the same L-Net, with the following limitations: A maximum 8 of stations per L-Net port... -
Page 6: Redundant Link
Industrieweg 87 2651BC Berkel & Rodenrijs Author: 4E-FMTC installation and user guide 4.1.2. Redundant link If you need to make a redundant L-Net connection to the Compact 500 main unit, connect both L-Net ports of the device to two L-Net ports on the C500 main unit. You can choose any L-Net port on the C500 main unit. -
Page 7: Network Cabling
4E-FMTC installation and user guide 4.1.3. Network cabling 4EVAC network features a full duplex RS-422 data link and 24V DC power to remote devices. If you’re building a distributed system using the 4EVAC network, you should make physical links between devices using the right cables. -
Page 8: Device Id
Plug-in the L-Net cable connecting the station with the C500 main unit. Observe the boot sequence and afterwards the unit automatically entering normal operating condition. Assemble the back plate (and optionally the rubber feet). HIGH 4E-FMTC bottom view: Device ID setting Page 8 of 17... -
Page 9: Front Panel
The emergency section is closed behind a transparent door for access level protection. While the door remains closed, the 4E-FMTC remains in general paging mode NOTE: Opening the transparent door on the left enables emergency mode, where evacuation features are available. -
Page 10: Led Indicators
Hacousto Holland bv Industrieweg 87 2651BC Berkel & Rodenrijs Author: 4E-FMTC installation and user guide LED indicators 5.1.1. POWER Indicates operating status of this station. Blink slow Continuous: device is powered and ready Blinking fast: station is booting or not operational... -
Page 11: Paging Mode
Hacousto Holland bv Industrieweg 87 2651BC Berkel & Rodenrijs Author: 4E-FMTC installation and user guide Paging mode 5.2.1. PAGING tab Source Zone selection selection 5.2.1.1. Zone selection In order to start paging / message, first select the zone or group of zones on the left section of the screen. - Page 12 Hacousto Holland bv Industrieweg 87 2651BC Berkel & Rodenrijs Author: 4E-FMTC installation and user guide 5.2.1.3. Start paging STOP SILENCE TALK button button button Use the TALK button to start paging in selected zones. If no zones are selected, pressing the TALK button will start paging in all zones available on this panel (ALL CALL).
-
Page 13: More Tab
Under the “MORE” tab you will find buttons used for starting and stopping user programmable events; for example starting transmission of a pre-defined BGM input to pre-defined group of zones. For more information about programming events, please look in the user manual of the 4EVAC Manager, where all configuration settings are explained. -
Page 14: Emergency Mode
Hacousto Holland bv Industrieweg 87 2651BC Berkel & Rodenrijs Author: 4E-FMTC installation and user guide Emergency mode Fireman PTT button Zone selection System indicators Silence button Emergency messages - Start button Once the fireman’s door is open, access to EVAC functions is enabled. - Page 15 Industrieweg 87 2651BC Berkel & Rodenrijs Author: 4E-FMTC installation and user guide NOTE: In emergency mode you can only use the fireman’s microphone. 5.3.1.3. Emergency paging Take the fireman microphone out and use the PTT button to start paging in selected zones.
-
Page 16: Technical Specifications
Hacousto Holland bv Industrieweg 87 2651BC Berkel & Rodenrijs Author: 4E-FMTC installation and user guide 6. Technical specifications 4E-FMTC Number of zones max. 255 zones (global network access) Controls and indications Mandatory LEDs: power, fault, evac, busy, fireman PTT button;... - Page 17 Hacousto Holland bv Industrieweg 87 2651BC Berkel & Rodenrijs Author: 4E-FMTC installation and user guide M A D E T H E N E T H E R L A N D S 4EVAC is a trade name of: Hacousto Holland bv Industrieweg 87 2651BC Berkel &...
