RP-PAFRM
Powered Awning
Installation Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the RP-PAFRM and is the answer not in the manual?

Questions and answers

Related Manuals for RecPro RP-PAFRM

Summary of Contents for RecPro RP-PAFRM

  • Page 1 RP-PAFRM Powered Awning Installation Manual...
  • Page 2 CONTENTS...
  • Page 3 DESCRIPTION...
  • Page 4 DESCRIPTION Ø6.35x31.75 Hex head lag screw...
  • Page 5 Preparation Open the package and check to make sure that all the parts and accessories are included. Gather needed tools, including a hand drill, tape measure, screwdriver, pencil, and ladders. According to your purchased awning size, mark the 6 fixation points for installation. The six fixation points should be calculated according to the calculation formula below.
  • Page 6 8' 9' 10' 11' 12' 13' 14' 15' 16' 17' 18' 19' 20' 21' 3" 5⅛" " " " Note: A= awning width (left arm center to right arm center) Please check the above measurement sheet carefully and calculate the correct installation position accordingly.
  • Page 7 Note: After completing step 1-3, please be sure the left and right arms are tied back with the Velcro so that the arms are in a secured position. Step 4 Attach the fabric lock rail to the wall of the RV. Optional: after installing, use sealant around the fabric lock rail to protect against water leakage.
  • Page 8 Step 4 Insert fabric into fabric tube. Slide the poly cords on the front of the awning fabric into two of the three grooves on the fabric tube. Step 5 Insert fabric into fabric lock rail. Slide the poly cord into the fabric lock rail on the RV wall.
  • Page 9 Step 8 Install the roller tube on the left and right arms. Make sure the connecting motor part is on the right arm. Step 9 After installing the roller tubes, loosen the Velcro on both arms (arms will open slightly but will not open fully). At this time, wire the motor to the switch and power supply temporarily.

  • Page 10: Wiring Instructions

    Step 11 Open the awning completely and disconnect the temporary wiring. Connect the power cord of the motor from the hole on the right-side arm then connect it with the cable inside of the arm. Then, hide the connection in the protection shell. Step 12 Connect the motor to the RV power cord and hide the connector in the protection shell to prevent element damage.
  • Page 11 Step 14 Motor (DC 12V) limit position adjustment Motor limit position: To control the awning closing or opening maximum position, adjust the winding number of the motor’s positive and negative directions. Max open position adjustment Turn the switch to “open” position. The awning will then open. When the awning cannot be fully opened, insert the adjusting rod into the bottom hole of the motor and adjust it to “+”...

  • Page 12: Adjust Awning Pitch

    How to operate awning Attention: Maintain a horizontal distance of at least 8 feet between the fully open awning and any permanent object. DO NOT face awning toward permanent objects that may interfere with the awning operation. Failure to pay caution may result in injury.
  • Page 13 1. With the awning fully extended, loosen the adjustable knob on the adjustable pitch arm assembly. 2. Keep CLEAR of openings around the adjustable pitch arm assembly while adjusting the awning pitch (slope). The adjustable pitch arm assembly (bottom arm) will telescope. Failure to use caution may lead to injury.

  • Page 14: Close Awning

    Close awning 1. Loosen the adjustable knobs to allow the awning to reset to the original position, then, lightly tighten the knobs on both arm assemblies to help make sure a rattle-free travel. Pull the top arm assembly down to verify the knob is not too tight. Adjustable pitch assembly arm MUST still slide as normal.
  • Page 15 How to clean awning arms Regularly wash out the arm channels with a hose in case of dirt and debris, which can cause the arm channels not to slide as easily. It’s also a good idea to lightly spray the inside of the channel with dry silicone lubricant.

  • Page 16: Warranty Information

    Warranty Information RecPro Awning Assemblies are covered under warranty for a period of 1 year and includes replacement or refunds for shipping or manufacturing errors. Shipping damage is covered for 30 days after receiving the prod- uct. Make sure to inspect the unit when it arrives for shipping damage.
