- Page 1 EVB User Guide TLSR8298DK56D 2022-06-22 Telink Proprietary and Confidential...
-
Page 2: General Introduction
BT 5.1， allowing easy connectivity with Bluetooth Smart Ready mobile phones, tablets and medical equipment.etc。 1.2 Package Material list The order name for the TLSR8298 Universal starter KIT is TLSR8298DK56D-Kit. The materials in the kit are listed here: 1x TLSR8298DK56D 1x Burning EVK for 8298 ONLY，Including the Dupont line 1x USB cable 1x 2.4G rod antenna... - Page 3 Section Header 1. Product Introduction - Continued 1.2 Kit Material List - continued Telink Proprietary and Confidential...
- Page 4 3. • SPI/I2C/UART with hardware flow control and 7816 protocol support 4. • Swire debug Interface 5. • Up to 3 channels of differential PWM: 6. • 14bit 4/1-channel (only GPIO input) SAR ADC 7. • Temperature sensor Telink Proprietary and Confidential...
- Page 5 2. Core Board Introduction - Continued TLSR8298 Crystal 24M Level Shift+I2S in/ TLSR8298 out PORT RESET key LDO module Flash Flash Reset key Download port Power Supply Jumpers Debug IO LDO module Power Supply Jumpers LED light battery1.5V Telink Proprietary and Confidential...
- Page 6 2. Core Board Introduction - Continued 2.1.2 Development board name EVB is sold under the name TLSR8298DK56D. The customer submits an order with this name for purchase. EVB has a serial number on the board for version differentiation. The following figure shows the serial number of V1.2.
- Page 7 The EVB DEBUG interface is on the upper left corner of the development board and on the upper side of the mini USB interface, as shown in the lower left figure. Debug pin, as shown in the lower right figure. VBUS VBUS Telink Proprietary and Confidential...
- Page 8 2. Core Board Introduction - Continued 2.1.3 SWS burnprocess interface SWS burnprocess wiring as shown in the figure。 Telink Proprietary and Confidential...
- Page 9 The development board RF interface is a 3.5mm SMA plug. Therefore, it can be directly connected to the instrument for RF performance testing, and it can also be connected to the whip antenna for radiation testing。 RF SMA Telink Proprietary and Confidential...
- Page 10 2. Core Board Introduction - Continued 2.1.6 Reset button Considering the development of some emergencies, EVB reserved chip reset button. 复位按键 Telink Proprietary and Confidential...
- Page 11 2. Core Board Introduction - Continued 2.1.7 Button EVB has three buttons reserved, and the software can be customized according to the IO port of the buttons, as shown in the following figure. Telink Proprietary and Confidential...
- Page 12 2. Core Board Introduction - Continued 2.1.8 LED light One charging indicator and four configurable LED lights are reserved on the EVB, as shown in the following figure. Telink Proprietary and Confidential...
-
Page 13: Power Supply Mode
EVB has three power supply modes, support button battery 1.5V battery power supply, USB 5V voltage power supply and 1V5EVK power supply。 1.USB power supply only needs to be connected to the USB interface of the EVB through the USB data cable, as shown in the following figure。 The USB input voltage is 5V Telink Proprietary and Confidential... - Page 14 2. Core Board Introduction - Continued 2.1.4 power supply mode 2.USB charging only needs to connect the USB interface of the EVB through the USB data cable to power supply, as shown in the following figure. AG13Button battery power Telink Proprietary and Confidential...
- Page 15 2. Core Board Introduction - Continued 2.1.4 power supply mode 1V5EVK power supply, as shown in the following figure. 1V5EVK power supply Telink Proprietary and Confidential...
- Page 16 FCC Statement FCC standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Device is equipped with External antenna(reversed polarity unique antenna port), Antenna gain 2dBi This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 17 Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
