Proper Hand Position (Fig. G)

WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position as shown.

WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
sudden reaction.
Proper hand position requires one hand on the main
handle 4 .
Variable Speed Trigger Switch (Fig. A)
To turn the tool on, squeeze the trigger switch
tool off, release the trigger switch. Your tool is equipped with
a brake. The anvil will stop when the trigger switch is fully
released. The variable speed switch enables you to select the
best speed for a particular application. The more you squeeze
the trigger, the faster the tool will operate. For maximum tool
life, use variable speed only for starting holes or fasteners.
nOTE: Continuous use in variable speed range is not
recommended. It may damage the switch and should
be avoided.
Forward/Reverse Control Button (Fig. A)
A forward/reverse control button
of the tool and also serves as a lock-off button.
To select forward rotation, release the trigger switch and
depress the forward/reverse control button on the right side
of the tool.
To select reverse, release the trigger switch and depress the
forward/reverse control button on the left side of the tool.
The center position of the control button locks the tool in
the off position. When changing the position of the control
button, be sure the trigger is released.
nOTE: The first time the tool is run after changing the
direction of rotation, you may hear a click on start up. This is
normal and does not indicate a problem.
Worklight (Fig. A, D)
The worklight 7 is activated when the variable
speed trigger 1 is depressed. Pressing the worklight
switch 8 repeatedly will cycle through low illumination,
high illumination, and off.
nOTE: The worklight is for lighting the immediate work
surface and is not intended to be used as a flashlight.
Usage (Fig. A)

CAUTION: Ensure fastener and/or system will
withstand the level of torque generated by the tool.
Excessive torque may cause breakage and possible
personal injury.
1. Place the accessory on the fastener head. Keep the tool
pointed straight at the fastener.
2. Press variable speed trigger switch
Release variable speed trigger switch to stop operation.
Always check torque with a torque wrench, as the
fastening torque is affected by many factors including
the following:
‑ Voltage: Low voltage, due to a nearly discharged
battery, will reduce fastening torque.
1 . To turn the
2 determines the direction
1 to start operation.
Accessory size: Failure to use the correct accessory
‑
size will cause a reduction in fastening torque.
Bolt size: Larger bolt diameters generally
‑
require higher fastening torque. Fastening torque
will also vary according to length, grade, and
torque coefficient.
Bolt: Ensure that all threads are free of rust and other
‑
debris to allow proper fastening torque.
Material: The type of material and surface finish of
‑
the material will affect fastening torque.
Fastening time: Longer fasten ing time results in
‑
increased fastening torque. Using a longer fastening
time than recommended could cause the fasteners
to be overstressed, stripped or damaged.
specifications
Max. fastening torque
Max. breakaway torque
No load speed
Impacts per minute
Length
Weight

MAINTENANCE


WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start‑up can cause injury.
Your D WALT power tool has been designed to operate
e
over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regular cleaning.
Cleaning

WARNING: Blow dirt and dust out of all air vents with
clean, dry air at least once a week. To minimize the risk
of eye injury, always wear ANSI Z87.1 approved eye
protection when performing this procedure.

WARNING: Never use solvents or other harsh
chemicals for cleaning the non‑metallic parts of the
tool. These chemicals may weaken the plastic materials
used in these parts. Use a cloth dampened only with
water and mild soap. Never let any liquid get inside the
tool; never immerse any part of the tool into a liquid.
English
Low mode: 100ft-lbs, 135 Nm
Medium mode: 600 ft-lbs, 800 Nm
High mode: 1030 ft-lbs, 1396 Nm
1400 ft-lbs, 1900 Nm
0–2300 rpm
0–2200 ipm
8.81" (224 mm)
6.4 lbs. (2.9 kg)
