MFJ-917 1:1 SWR Analyzer CURRENT BALUN
INTRODUCTION
The MFJ-917 is a true 1:1 current balun designed for the measurements of balanced lines using
SWR and Antenna analyzers. It is rated from 1.8 to 30 MHz. It has a SO-239 coax connector
with internal insulation for the maximum life of the product.
INSTALLATION
1. The MFJ-917 is intended for applications protected from the elements – out of the
weather.
2. For use as a balun (1:1) connect the balanced feed line to the posts and the SWR/Antenna
Analyzer coaxial cable to the SO-239 coax connector.
SWR/Antenna
Analyzer
1.8-30 MHz
MFJ-
917
Figure 1: MFJ-917 Block Diagram
Balanced
Load
