DUST SHOE MOUNTING GUIDE M4x25 Assemble the PMMA parts with the two M4x20 screws as shown. Place the two M4 locknuts in the triangular holes so that they lock when tightened. Place the M6 rectangular nuts in the provided pin. Tighten the M6x40 screws with the tooth lock washers.
Page 3
DUST SHOE MOUNTING GUIDE Place the plastic adaptator into the clamping ring and tighten it. Assemble the magnets on the last PMMA part as shown with the two M3x10 screws. M3x10 Insert the brush* part in the slot as shown.
Page 4
DUST SHOE MOUNTING GUIDE Place the fixed part of the dust shoe on the spindle and tighten it with the 5mm Allen key.
Page 5
Slightly loosen the locknuts to solve that problem. Repeat the pull down test. USE THE DUST SHOE ONLY IF THE MAGNETS STICK CORRECTLY TO THE WASHERS (if it’s not the case, refer to the note above)
