- Page 1 The kvm-tec connection to virtual machines MANUAL Gateway Part Nr KT - 6851 www.kvm-tec.com Misprints, errors and technical changes reserved...
- Page 2 The gateway has the function of a thin client and in combination with MX Local Extender is the ideal combination with virtual machines in the switching system. With the kvm-tec gateway it is possible to connect to virtual machines or remote PCs outside the switching network.
-
Page 3: Table Of Contents
2.4 Operation for RDP 2.5 Operation for VNC 2.6 Editing a saved connection 2.7 Sorting the saved connections 2.8 Deleting a saved connection 2.9 Quick Favoriting 2.10 Connect 3. Configure the Extender kvm-tec | 3 Misprints, errors and technical changes reserved... - Page 4 4.1 Extender care 4.2. Disposal 5. Warranty 5.1. Standard warranty 5.2 Extended warranty 6. Cable requirements 6.1 Requirements for CAT5e/6/7 cables 7. Requirements network-switch 8. Contacts & phone / emails 9. Notes 4 | kvm-tec Misprints, errors and technical changes reserved...
-
Page 5: Introduction
The gateway is a Linux based device that runs with Debian as operating system and Free RDP as connection client. WARNING The device may only be opened by an authorized technician. Danger of electric shock! 5 | kvm-tec kvm-tec | 5 Misprints, errors and technical changes reserved... -
Page 6: Safety Instructions
Prior to connecting to the mains, make sure your local mains voltage matches the rating indicated on the product. • The product must be connected to a permanent and earthed AC wall socket. 6 | kvm-tec Misprints, errors and technical changes reserved... - Page 7 Wipe the housing with a damp cloth. Electrical/ electronic parts must not be cleaned. • Alterations to the product and technical modifications are not permitted. kvm-tec | 7 Misprints, errors and technical changes reserved...
-
Page 8: Technical Spezifications
80% (non condensing) Housing material: anodized aluminum Dimension: 198 x 40 x 103,5 mm/ 7.79 x 1.57 x 4.03 inch Weight: 604 g/1.33 lb Local/CPU MTBF 82 820 calculated hours / 10 years 8 | kvm-tec Misprints, errors and technical changes reserved... -
Page 9: About The Product - Gateway
LED display RDP/VNC Status connection for 12V/1A power supply connection to LAN reset button for reset kvm-link connection for CAT X cable to KVM network power/status LED display the extender status kvm-tec | 9 Misprints, errors and technical changes reserved... -
Page 10: About The Status Led
Light display Description shining only network connection available fast flashing no active connection shining no video signal shining everything works A detailed error description can be found in chapter First Aid 10 | kvm-tec Misprints, errors and technical changes reserved... -
Page 11: Unpacking And Checking The Contents
To attach the mounting pads or rubber feet: 1. Remove the protection layer from the mounting pads or rubber feet (G). 2. Attach the mounting pads or rubber feet (G) to the bottom the units. kvm-tec | 11 Misprints, errors and technical changes reserved... -
Page 12: Installation Of The Extender
Easy installation - first connect the MX or UVX remote unit, then select the RDP or VNC protocol on the KVM gateway. Then the login data is entered and connected to the desired PC. 12 | kvm-tec Misprints, errors and technical changes reserved... -
Page 13: Quickinstallation Gateway
5. then connect Remote audio/out to speakers or headphones using the audio cable. 6. connect the gateway to the Internet with a network cable via the Lan port. HAVE FUN - your kvm-tec Gateway is now ready for all virtual machines ! kvm-tec | 13... -
Page 14: Operation, Adding General
To establish a new connection to a PC, you must first press the following button on the main page to add a new connection of your choice (RDP/VNC). This button takes you to the Add window. 14 | kvm-tec Misprints, errors and technical changes reserved... -
Page 15: Operation For Rdp
Disable/enable. (Serves, in order to be able to sort on the Mainpage, after sort by favorites. Once all the parameters are in place, you can press the „Finish Adding“ button to save the RDP connection. kvm-tec | 15 Misprints, errors and technical changes reserved... -
Page 16: Operation For Vnc
Favoritise: Disable/enable. Used to be able to sort by favorites on the main page. Once all the parameters are in place, you can press the „Finish Adding“ button to save the VNC connection. 16 | kvm-tec Misprints, errors and technical changes reserved... -
Page 17: Editing A Saved Connection
Selected connections are highlighted in blue, with white text. Once you have selected a connection, click the following button. Now you reach the edit window. The data, which were already stored, are taken over, except for the password! kvm-tec | 17 Misprints, errors and technical changes reserved... - Page 18 Add window. When you are done editing, save your input by clicking the “Finish Editing” button. You will now return to the main page with the updated changes. 18 | kvm-tec Misprints, errors and technical changes reserved...
-
Page 19: Sorting The Saved Connections
In order to be able to sort now, press on the desired head of a column (except Delete), after which should be sorted. If you want to sort e.g. by favorites, click once on „Favorites“. Now the entries are sorted in ascending order. kvm-tec | 19 Misprints, errors and technical changes reserved... -
Page 20: Deleting A Saved Connection
If you click on the “Favorites” header again, the entries will be sorted in descending order. 2.8 DELETING A SAVED CONNECTION To do this, simply press the “trash can” button on the main page, which you will find in the Delete column. 20 | kvm-tec Misprints, errors and technical changes reserved... -
Page 21: Quick Favoriting
2. INSTALLATION OF THE EXTENDER 2.9 QUICK FAVORITING To do this, press the star icon of the desired list item and the star will turn yellow or gray. yellow - Favorited gray - not favorited kvm-tec | 21 Misprints, errors and technical changes reserved... -
Page 22: Connect
Now a check mark should appear, Fullscreen is now activated. If you are satisfied with your selection in the list and the settings, press the „Connect“ button, the virtual connection will start.. 22 | kvm-tec Misprints, errors and technical changes reserved... -
Page 23: Configure The Extender
The gateway has the following features, which can be viewed as a list by pressing the right mouse button: 3.2 APPS KVM-Client: If the KVM client is closed for any reason, you can restart the „KVM Client“ input software. kvm-tec | 23 Misprints, errors and technical changes reserved... -
Page 24: Update
USB save feature on the connected remote unit is deactivated (USB Mass Storage enable). Before the update is carried out, the entry must be confirmed as follows: 24 | kvm-tec Misprints, errors and technical changes reserved... - Page 25 With the Update OS feature, the installed Gateway operating system can be updated to the latest version. Please note that the existing „lan/wan“ RJ45 beech is connected to the Internet. Before the update is carried out, the entry must be confirmed as follows: kvm-tec | 25 Misprints, errors and technical changes reserved...
-
Page 26: Settings
Thus, future extensions can be installed without problems. 3.5 EXIT Reboot: With the selection „Reboot“ the operating system of the gateway is restarted. 26 | kvm-tec Misprints, errors and technical changes reserved... -
Page 27: Close Rdp Connection
To terminate an existing VNC connection proceed as follows: By pressing the key „F8“ a VNC setting selection window appears. With a left mouse click on „Exit viewer“ the existing session is closed. kvm-tec | 27 Misprints, errors and technical changes reserved... -
Page 28: Using The Osd For Gateway Connections
The Switching Manager that runs in the System requires a xml file, with the Connection data of the Virtual Machines. The file should be written manually in the “your-SwitchingManager-folder”/api/virtualMachines.xml. The Data should look like this: Server is for the IP-Adress so replace the x. 28 | kvm-tec Misprints, errors and technical changes reserved... - Page 29 ConnectionType must be RDP or VNC (capital Letters!) • The Credentials should never include the following characters: ‘,’ ‘;’ ‘ ‘ • For VNC leave Username, Password and Domain empty (as shown in the picture) kvm-tec | 29 Misprints, errors and technical changes reserved...
-
Page 30: Maintance & Care
The packaging is made of environmentally friendly materials, which may be disposed through your local recycling facilities. By disposing of the packaging and packaging waste in the proper manner, you help to avoid possible hazards for the environment and public health. 30 | kvm-tec Misprints, errors and technical changes reserved... -
Page 31: Warranty
Please, contact us first before returning the product. 5.2 EXTENDED WARRANTY 2 years standard warranty Art Nr 9003 warranty extension to 5 years per Set Art Nr 9002 warranty extension to 5 years per Unit kvm-tec | 31 Misprints, errors and technical changes reserved... -
Page 32: Cable Requirements
The shield should be contiguous and connected to both ends. A shielded patch cable is allowed for connection to the device. Schema EIA/TIA-568 B Color Orange/White Orange Green/White Blue Blue/White Green Brown/White Brown 32 | kvm-tec Misprints, errors and technical changes reserved... -
Page 33: Requirements Network-Switch
The network switch must meet the following specifications: 1 Gigabit switch, with a port-to-port transfer rate of 1 Gigabit/second. The following switches have all been tested and verified to work with all kvm-tec extenders. Network requirements Matrix System UDP Version... -
Page 34: Contacts & Phone / Emails
8. CONTACTS & PHONE / EMAILS 8. ADDRESS & PHONE/EMAIL If you have any questions about our products, please contact kvm-tec or your dealer. kvm-tec electronic gmbh Gewerbepark Mitterfeld 1A 2523 Tattendorf Austria Phone: 0043 (0) 2253 81 912 Fax: 0043 (0) 2253 81 912 99 Email: support@kvm-tec.com... -
Page 35: Notes
9. NOTES kvm-tec | 35 Misprints, errors and technical changes reserved...
