Next SIMPSON 749477 Assembly Instructions

White metal console table

Advertisement

Quick Links

IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.

Tools Needed

Helpline

If you have any problems with this product or require
any replacement fittings please contact Customer
Services Tel: 0333 777 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is foundto be faulty. Should you
the unassembled product, please repack in the original packaging

IMPORTANT

• We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step instructions.
• Carefully check that you have all parts before beginning assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of 2 persons are required to assemble this product.

PRODUCT INFORMATION

• Made from Glass and metal.
• Made in China.

CARE INSTRUCTIONS

• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Do not use abrasive cleaning products or those containing silicone.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
• Ensure the product is protected with mats and coasters when items are placed on the surfaces, to prevent scratching or damage.
• Do not put hot dishes directly on the surfaces of the item.
• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking, discolouration or warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
• All assembly fixings should always be tightened properly and periodically check all fixings and tighten if necessary.
SIMPSON WHITE METAL CONSOLE TABLE 749477
ASSEMBLY INSTRUCTIONS.
Page 1 of 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIMPSON 749477 and is the answer not in the manual?

Questions and answers

Summary of Contents for Next SIMPSON 749477

  • Page 1 SIMPSON WHITE METAL CONSOLE TABLE 749477 ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement fittings please contact Customer Services Tel: 0333 777 8999 Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is foundto be faulty.
  • Page 2 FITTINGS A.Bolts x 4 B.Bolts x 8 D.washer x 8 C.Spring Washer x 8 M8 x 40mm M6 x 30mm G.Bolt x 2 F.Spring Washer x 6 E.Allen key x 1 M8 x 30mm PARTS (1)Glass top x 1 (2)Left Leg x 1 (3)Right Leg x 1 (5) Connecting rod x 1 (6)Cap x 2...
  • Page 3 STEP ONE (1) Use bolt (G) x 2, spring washer (F) x 2 to fix the Connecting rod (5) onto Left Leg (2) and Right Leg (3) and tighten with Allen Key (E). (2) Use bolt (A) x4, Spring Washer (F)x4 to fix the frame (4) onto Left Leg (2) and Right Leg (3) and tighten with Allen Key (E).
  • Page 4 WARNING: Ensure the area to be drilled is free from hidden electrical wires and water or gas pipes. NOTE: Wall fixings are not included. Source suitable fixings for your wall type, if in doubt consult a qualified tradesperson. Next Retail Ltd, Desford Road, Leicester, LE19 4AT Page 4 of 4...
