- Page 1 INSTRUCTION MANUAL 20V Cordless Hedge Trimmer Model # PS76106A Have product questions or need technical support? Please scan the QR code to enter our official website and contact us! Website: www.powersmartusa.com Toll free: 1-800-791-9458 M-F 9-5 EST Website Email: support@amerisuninc.com...
-
Page 3: Table Of Contents
Assembly ………….……………………………………………………… 13 Operating instruction…………………………………………………..Maintenance.……………………………………………………………… 16 Environmentally safe battery disposal……………………………………. 17 Exploded view & parts list……………………………………………… Warranty statement……………………………………………………… TECHNICAL DATA 20V Cordless hedge trimmer Model # PS76106A Cutting length: 22" Cutting diameter: 3/4" Motor: 20V DC No load speed:... -
Page 4: Introduction
INTRODUCTION ® Thank You for Purchasing a PowerSmart Product. This manual provides information regarding the safe operation and maintenance of this product. Every effort has been made to ensure the accuracy of the ® information in this manual. PowerSmart reserves the right to change this product and specifications at any time without prior notice. -
Page 5: General Safety Rules
GENERAL SAFETY RULES Safety is a combination of common sense, staying alert, and knowing how your hedge trimmer works. SAVE THESE SAFETY INSTRUCTIONS. WARNING: Do not operate this unit until you read this instruction manual for safety, operation and maintenance instructions. Failure to follow all instructions listed below may result in electric shock, fire, and/or serious personal injury. - Page 6 CAUTION: In all cases, make certain the outlet in question is properly grounded. If you are not sure if it is, have a licensed electrician check the outlet. WARNING: Do not expose to rain or use in damp locations. Guidelines for using extension cords Make sure your extension cord is in good condition.
- Page 7 Wear safety glasses with side shields or goggles that are marked to comply with ANSI Z87.1 standard when operating this product. Use face or dust mask if environment is dusty. Do not operate the equipment while barefoot or when wearing sandals or similar lightweight ...
- Page 8 Save these instructions. Refer to them frequently and use them to instruct others who may use this tool. If you lend this tool to someone else, also lend them these instructions. BATTERY TOOL USE AND CARE WARNING: USE ONLY POWERSMART APPROVED REPLACEMENT BATTERIES, OTHER BATTERIES MAY CAUSE INJURY OR DAMAGE TO THE TRIMMER.
- Page 9 Proper care for battery Off-season storage To obtain the longest possible battery life, we suggest the following: Remove the battery pack from the charger once it is fully charged and ready for use. For battery pack storage longer than 30 days: Store the battery pack where the temperature is below 80°F and away from moisture.
-
Page 10: Specific Safety Rules For Hedge Trimmer
SPECIFIC SAFETY RULES FOR HEDGE TRIMMER Use both hands when operating the hedge trimmer. Using one hand could cause loss of control and result in serious personal injury. Keep all parts of the body away from the cutter blade. Do not remove cut material or hold material to be ... -
Page 11: Symbols
SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz Frequency (cycles per second) -
Page 12: Knowing Your Hedge Trimmer
KNOWING YOUR HEDGE TRIMMER Rear Handle Front Handle Safety Guard Scabbard Blade Battery Lock-off Button Trigger Switch Rotating handle button Unpacking Unpack the hedge trimmer and all its parts, and compare against the list below. Do not discard the carton or any packaging materials. -
Page 13: Assembly
ASSEMBLY WARNING: Do not use this product if any parts on the packing list are already assembled to your product when you unpack it. Parts on this list are not assembled to the product by the manufacturer and require customer installation. Use of a product that may have been improperly assembled could result in serious personal injury. -
Page 14: Operating Instruction
OPERATING INSTRUCTIONS WARNING: Read and thoroughly understand all instructions and safety information before operating this hedge trimmer. Failure to do so may cause serious injury or death. Do not allow anyone to operate this hedge trimmer who has not read this manual. A hedge trimmer can be dangerous if assembled or used improperly. - Page 15 CUTTING TIPS WARNING: Never cut near electric cords or lines. If blade jams on any electrical cord or line, DO NOT TOUCH THE BLADE! IT CAN BECOME ELECTRICALLY LIVE AND VERY DANGEROUS. Continue to hold the hedge trimmer by the insulated rear handle or lay it down and away from you in a safe manner.
-
Page 16: Maintenance
MAINTENANCE WARNING: To avoid serious personal injury, always remove the battery pack from the product before inspecting, cleaning or performing any maintenance. WARNING: Always wear eye protection with side shields marked to comply with ANSI Z87.1. If operation is dusty, also wear a dust mask. WARNING: When servicing, use only identical replacement parts. -
Page 17: Environmentally Safe Battery Disposal
Stop the hedge trimmer. Remove the battery pack. Lubricate the hedge trimmer as described above. Reinstall the battery pack and resume use. CLEANING THE HEDGE TRIMMER Remove the battery pack. Slide the scabbard over the blade. ... -
Page 18: Exploded View & Parts List
EXPLODED VIEW & PARTS LIST... - Page 19 Item stock# Description Item stock# Description PS76106A-022 Gasket PS76106A-001 Left handle PS76106A-023 Big gear PS76106A-002 Left housing PS76106A-003 Button PS76106A-024 Eccentric wheel PS76106A-025 Gasket PS76106A-004 Spring PS76106A-005 Left cover PS76106A-026 Blade assemble PS76106A-006 Press plate PS76106A-027 Gasket PS76106A-007 Screw ST3x10...
- Page 20 (2) years from date of purchase. Ninety (90) days for all Power Smart Products, if the tool is used for professional or commercial use. SELLER’S SOLE OBLIGATION AND YOUR EXCLUSIVE REMEDY under this Two (2) Years Limited...
