- Page 1 10 CU. FT. 12V BUILT-IN REFRIGERATOR MODEL: GRF10DBGL, GRF10DBGR LIPPERT NO.: 2022071754, 2022071755 USER MANUAL * Picture shown here is for reference only.
-
Page 2: Table Of Contents
Thank you for purchasing this Girard product. Before operating your new appliance, please read these instructions carefully. This instruction manual contains information for safe use, installation and maintenance of the appliance. Please keep this instruction manual in a safe place for future reference. This will ensure safe use and reduce the risk of injury. Be sure to pass on this manual to new owners of this appliance. -
Page 3: Explanation Of Symbols
Explanation of Symbols This manual has safety information and instructions to help you WARNING eliminate or reduce the risk of accidents and injuries. Always respect all safety warnings identified with these symbols. A signal word will identify Indicates a potentially hazardous situation which, if not avoided, could safety messages and property damage messages, and will indicate the result in death or serious injury. -
Page 4: Parts And Features
Parts and Features Item Part Name Item Part Name Trim Kit Air Vent Freezer Shelf ½ Gallon Door Bin Charcoal filter drawer Gasket Temperature Control Refrigerator Door Refrigerator Top Shelf Common Door Bin Refrigerator Bottom Shelf Freezer Door Drawer CCD-0005837 Rev: 05-10-22 - 3 -... -
Page 5: Installation
● For best and most efficient operation, the refrigerator should operate within 50°F ~ 126°F (10°C ~ 52°C). If installing near large All Girard products referenced in this manual are to be installed in heat sources, such as furnaces, fireplaces, furnaces, etc. Ensure... -
Page 6: Securing The Refrigerator
Drainage Preparation USA: ● NFPA 1192 The cavity condensate drainage is captured in a drain pan integrated ● NFPA 70 with the unit. No external drainage needs to be prepared at this point. ● ANSI/RVIA low Voltage Canada: Securing the Refrigerator ●... -
Page 7: Operation
Operation The appliance has a low-voltage shut-off function, intended to protect Thermostat Fridge Freezer your RV battery's from excessive drain. Setting Temperature Temperature NOTE: This function controls compressor operation only, a small electric 30°F(-1.1°C) -11.2°F(-24°C) current is still used for the LED cavity light and low-voltage monitoring Between Max and Mid 39.2°F(4°C) 1.4°F(-17°C) -
Page 8: Extreme Temperature Usage
Extreme Temperature Usage The normal operating temperature for this appliance is 50°F (10°C) to 109.4°F (43°C). The refrigerator can be used in ambient temperatures between 109.4°F (43°C) and 125.6°F (52°C), but expect reduced cooling performance. If the ambient temperature exceeds 125.6°F (52°C), allow the inside of the coach to cool down before turning on. -
Page 9: Transportation
your destination and remove any remaining food before departing. Lock Bracket ● Never transport with the Storage lock in place. ● Turn refrigerator to "OFF" if climbing/crawling any off-road grades. Compressor oil should resettle within 2 hours. Energy Saving Tips ●... -
Page 10: Circuit Diagram
241/4 x 601/ x 253/4” (616 x 1528 x 655mm) Recessed Dimensions (W x H x D) 231/4 x 52 x 233/4” (592 x 1338 x 604mm) GRF10DBGL Net Weight (lbs/kg) 139lbs / 63kg GRF10DBGR Rated Power Supply Voltage DC 12V (Min. 9.6V to max. 17V) Rated Current 11A @ start-up &... -
Page 11: Troubleshooting
Troubleshooting A qualified professional is required for any servicing of the compressor drive board and the control board, otherwise it will void the product warranty. If you encounter a problem similar to what is mentioned in the following table, try the suggested solution below to see if you can solve the problem before calling service. - Page 12 Girard Products LLC. ● 1361 Calle Avanzado, San Clemente, CA 92673 ● Toll Free: 1-574-537-8900 ● Email: customerservice@lci1.com www.greenrvproducts.com IM-FHA00120 V1.0...
