- Page 1 Antennas for MTC 6 Series, Catalog V1.00...
- Page 2 DLoG GmbH also assumes no liability for damages caused directly or indirectly by the delivery, performance or usage of this material. This catalog is protected by copyright. Duplication, in whole or in part, is not permitted without prior written approval of DLoG GmbH. Catalog title: Antennas for MTC 6 Series Catalog completed on: 07/10/2014 Katalog version: V1.00 ...
- Page 3 Content Antennas for challenging industrial environments ....................4 1.1. Integrated WLAN antenna..............................4 1.2. External WLAN antenna................................ 4 Integrated WLAN antenna with diversity ........................5 External WLAN antenna kit, remote ..........................6 Connecting external antennas via RSMA ........................7...
- Page 4 Especially in challenging industrial environments such as warehouses and production facilities, there are no easy solutions with regard to wave propagation. No off-the-rack solution will work here and this is why Advantech-DLoG offers custom solutions. Our integrated antennas are matched as perfectly as possible to the respective vehicle terminal and achieve an optimal circular radiation characteristic.
- Page 5 Frequency range Band 1: 2400 to 2485 MHz Band 2: 5150 to 5875 MHz Antenna gain Max. 3 dBi (without loss through the cable) Impedance 50 Ω Polarization Vertical Advantech-DLoG Antennas for MTC 6 Series, V1.00 Page 5 of 7...
- Page 6 Ø 86 x 43 mm (Ø 3,39” x 1,69”) Weight 0,3 kg (0,66 lbs) Connector labeling N type or TNC N, jack, female, bottom RSMA plug for RSMA socket on the terminal Advantech-DLoG Antennas for MTC 6 Series, V1.00 Page 6 of 7...
- Page 7 They are connected to the underside of the MTC 6 via antenna cable with RSMA plug. The following connection on the MTC 6 is available for this: RSMA socket for WLAN Advantech-DLoG Antennas for MTC 6 Series, V1.00 Page 7 of 7...
