ClearClick®
HD Capture+Stream™
4K60 HDMI Input & Passthrough
1080P60 Recording & Live Streaming
User's Manual & Quick Start Guide
2-Year Warranty & USA-Based Tech Support
For tech support, email us at:
Extend your warranty to 3 years for free by registering at:
www.clearclicksoftware.com/Register/
support@clearclick.tech
www.ClearClick.tech
Advertisement
Related Manuals for ClearClick HD Capture+Stream
Summary of Contents for ClearClick HD Capture+Stream
- Page 1 ClearClick® HD Capture+Stream™ 4K60 HDMI Input & Passthrough 1080P60 Recording & Live Streaming User’s Manual & Quick Start Guide 2-Year Warranty & USA-Based Tech Support For tech support, email us at: support@clearclick.tech Extend your warranty to 3 years for free by registering at: www.clearclicksoftware.com/Register/...
- Page 2 Extend Your Warranty for FREE! Extend your warranty by one year for free simply by registering your product at: www.ClearClick.tech Browse All Our Products! If you’re looking for fun, unique, and easy-to-use technology, we’ve got it! Please visit our website to browse all of our products: www.ClearClick.tech...
- Page 3 What’s In The Box? ClearClick® HD Capture+Stream™ USB-C Cable (for PC/Mac connection) USB-C Cable (for Power) User’s Manual...
- Page 4 Device Diagram...
- Page 5 Quick Start Guide 1. Power the device. Power the device by plugging in one of the included USB-C cables to the “5V – 2A” port. Plug the other end into a USB power source (such as a USB wall adapter or charging port). 2.
- Page 6 3. Record to USB flash drive. If you’d like, you can record your video source to a USB flash drive (FAT32 or exFAT only). The device will record at up to 1080P60 quality. Plug in a USB flash drive to the “Storage / Phone” port.
- Page 7 A. Make sure you have powered the device by connecting the “5V – 2A” port to a power source. B. Use the included second USB-C cable to connect your PC or Mac to the ClearClick® device’s “UVC / PC” port. Allow your computer to automatically install it.
- Page 8 E. Under Sources, click the “+” button and click “Video Capture Device.” Click “OK.” At the next screen, set the “Device” to “ClearClick” and then click “OK.”...
- Page 10 F. Under Sources, click the “+” button again and click “Audio Input Device.” Click “OK.” At the next screen, set the “Device” to “ClearClick” and then click “OK.”...
- Page 11 G. In the main area of OBS, you can then click “Start Streaming” to start streaming to YouTube/etc. or “Start Recording” to start recording to your local PC or Mac.
- Page 12 H. For more information on how to use OBS, please visit the two links below. OBS Quick Start Guide: https://obsproject.com/wiki/OBS-Studio-Quickstart OBS Overview: https://obsproject.com/wiki/OBS-Studio-Overview...
- Page 13 OBS. Then, using a high-quality USB-C or Lightning cable, connect your smartphone to the “Storage / Phone” port on the ClearClick® device. Next, download the app “Miraplug” from the Google Play or Apple Store. Run the app and configure it, allowing the app permissions, and start live streaming from the app.
-
Page 14: Faqs And Troubleshooting
FAQ’s & Troubleshooting 1. The device’s LED is blinking red, but nothing is recording and/or being live streamed. This indicates a problem with your HDMI signal (either no signal or your HDMI source is copyrighted; the device does not record from HDCP content protected sources), or your USB flash drive is full or incompatible with the device. - Page 15 3. I pressed the “Mode” button, and now the device doesn’t show video in OBS. Pressing the mode button sets the device to only allow recording in OBS with H264 format. You can resolve this by pressing the mode button again and restarting OBS, or change the settings of the video source to “Custom”...
- Page 16 Technical Specifications System Requirements...
- Page 17 www.ClearClick.tech...
