Intermatic PG2000 Installation Instructions page 2

WIRING CONFIGURATIONS
120 VAC Single Phase
Transformer
Load Center
Secondary
or equipment
L1
Black
N
White
G
Green
Use of Circuit Breakers is optional
120/240 VAC Single (Split) Phase
Load Center
or equipment
Transformer
Secondary
L1
Black
L2
Black
White
N
Green
G
Use of Circuit Breakers is optional
120/208 VAC Three Phase WYE
Transformer
Load Center
Secondary
or equipment
L1
Black
L2
Black
L3
Black
White
N
Green
G
Use of Circuit Breakers is optional
120/240 VAC Three Phase Delta High Leg Delta
Load Center
Transformer
or equipment
Secondary
L1
Black
L2
Red
L3
Black
White
N
Green
G
Use of Circuit Breakers is optional
PanelGuard
PanelGuard
PanelGuard
PanelGuard
VOLTAGE CONFIGURATION CONFIRMATION
MODE
Line to Neutral
Line to Ground
VOLTAGE CONFIGURATION CONFIRMATION
MODE
Line to Line
Line to Neutral
Line to Ground
VOLTAGE CONFIGURATION CONFIRMATION
MODE
Line to Line
Line to Neutral
Line to Ground
VOLTAGE CONFIGURATION CONFIRMATION
MODE
Line to Line
Line to Neutral
High Leg to Neutral
Line to Ground
High Leg to Ground
VOLTAGE
120
120
VOLTAGE
240
120
120
VOLTAGE
208
120
120
VOLTAGE
240
120
208
120
208
