- Page 1 IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual Version: V 2.0 2020.04 ZHEJIANG QIYANG INTELLIGENT TECHNOLOGY Co., Ltd Copyright Reserved...
- Page 2 IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual Version Update Version Hardware Description Date Reviser IAC-IMX8MM-MB V1.00 Internal version 2020-02 wangwx IAC-IMX8MM-MB V1.10 Update wireframe pictures 2020-04 IAC-IMX8MM-MB V1.20 Update pictures 2020-06 :supports@qiyangtech.com Page 2 of 32 Any question, please send E-mail :trade@qiyangtech.com sales@qiyangtech.com...
-
Page 3: Table Of Contents
IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual Catalogue Note: This manual mainly introduces the hardware interfaces of the development board.........4 I. Preface ..................................4 1.1 Company Profile: ............................4 1.2、IAC-IMX8MM-KIT Development board ....................5 II.System Composition ...............................6 2.1 Chip Summary ..............................6 2.2、Mainboard resource： ..........................9 2.3、SOM Resource：... -
Page 4: Note: This Manual Mainly Introduces The Hardware Interfaces Of The Development Board
As the core of the company, Qiyang R&D team is composed of more than 30 embedded engineers, who committed to providing users with easy-to-use embedded hardware, software tools and customized product solutions. Our products and solutions have been widely used in industrial control, Internet of Things, new retail, medical, electricity, environmental monitoring, charging piles and other fields. -
Page 5: Iac-Imx8Mm-Kit Development Board
2,000 users to quickly and efficiently bring products to the market. The combination and extension of R&D, production capacity and market has laid a solid foundation for Qiyang to become a professional and global supplier of embedded software and hardware. -
Page 6: Ii.system Composition
2. Please check the packing list and see whether there is a missing file in the CD before using the development board; 3. Please understand the basic structure and composition of IAC-IMX8MM-KIT, including the allocation of hardware resource, the definition of each pin of the core and bottom board, and the definition of extended pins, etc.. - Page 7 IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual advanced quad-core Arm®Cortex®-A53 core, which runs at speeds up to 1.8 GHz. And a general-purpose Cortex®-M4 400 MHz core processor is used for low-power processing. The DRAM controller supports 32-bit/16-bit LPDDR4, DDR4 and DDR3L memories. Besides, a variety of audio interfaces are available, including I2S, AC97, TDM and S/PDIF.
- Page 8 IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual ◆Multi-core Processing： 4 Cortex-A53, running up to 1.8GHz per core, support 32KB L1-I cache/ 32 kB L1-D cache /512 kB L2 cache, MPE with NEON, support advanced single instruction multiple data (SIMP) architecture, support 64 bits ARM8-A architecture, support VFPv4-d16 FPU.
-
Page 9: Mainboard Resource
IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual 2.2、Mainboard Resource： NXP i.MX8M Mini processor,Quad ARM® Cortex™-A53+Cortex-M4, 1.8 GHz of i.MX8M, 400MHz of Cortex®-M4 2GB LPDDR4 Flash 8GB EMMC, ( 16GB EMMC、32GB EMMC Optional) 1-ch AR8035 Internet chip adopts RGMII supporting adaptability l10M/100M/1000M... -
Page 10: Som Resource
IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual Mechanic Carrier Boardd’s Structure & Size al Chart Core Board:55mm*60mm, 8-layer high precision immersion gold process Size Back Board: 200mm*130mm ， 4-layer high precision immersion gold process Power Consumpt ≤5W (Non-loaded consumption) Operation -40℃ ~ +85℃ ( industrial level )，0℃ ~ +85℃ （Consumer Level, Temperatu According to customers’... -
Page 11: Ⅲ.functions On Board
IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual ◆Onboard with NXP I.MX8M Mini Processor; ◆Onboard with 2GB LPDDR4,8GB EMMC (Default Setting) ◆SOM adopts 8-layer high precision gold immersion process technology; ◆SOM Size: 55mm*60mm, suits for various applications. ◆SOM adopts 2X2*50PIN Board To Board connector to draw out the SOM source. -
Page 12: Basic Function Description
IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual Chart 4 3.1. Basic Function Description: Label Function DC 12V Power In 16-ch GPIO USB2.0 USB2.0 MIC Audio Input Audio Output Speaker Output Gigabit Ethernet MINI_PCIE CSI1 Camera (4-Lane CSI) MIPI & I2C JTAG (M4 JTAG) :supports@qiyangtech.com... -
Page 13: Dip Switch Setting
IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual RS232 (I.MX8M Debug UART) UART4 (M4 Debug UART) RS232 (COM3) RS485 (COM1) RS232 (COM2) RS232(COM4) Gigabit Ethernet WIFI-IPEX Antenna SD Card Socket DC12V Power Input USB-OTG ON/OFF Button Reset Button Buzzer Battery for RTC(+3.0V) -
Page 14: Pin Definition
IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual Serial Downloader Internal Boot (Development) Reserved 3.3. Pin Definition: J28-1: (On SOM Pin) Signal Name Pin No. Pin No. Signal Name ECSPI1_SS0 ECSPI1_SCLK DSI_DN0 ECSPI1_MISO DSI_DP0 ECSPI1_MOSI DSI_DN1 ECSPI2_SS0 DSI_DP1 ECSPI2_SCLK ECSPI2_MISO DSI_CKN ECSPI2_MOSI... - Page 15 IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual I2C4_SDA CSI_DN0 UART2_RXD CSI_DP0 UART2_TXD UART4_RXD CSI_DN1 UART4_TXD CSI_DP1 JTAG_TDO CSI_CKN JTAG_TDI CSI_CKP JTAG_TMS JTAG_nTRST CSI_DN2 JTAG_TCK CSI_DP2 SD2_DATA0 CSI_DN3 SD2_DATA1 CSI_DP3 SD2_DATA2 SD2_DATA3 PCIE_RXN SD2_nRST PCIE_RXP SD2_CLK SD2_CMD PCIE_TXN SD2_nCD PCIE_TXP SAI3_MCLK PCIE_CLKN...
- Page 16 IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual SAI3_TXD USB1_VBUS SAI3_RXFS USB1_DN SAI3_RXC USB1_DP SAI3_RXD USB1_ID QSPIA_nSS0 USB2_VBUS QSPIA_SCLK USB2_DN QSPIA_MOSI USB2_DP QSPIA_MISO USB2_ID J28-2: (On SOM Pin) Signal Name Pin No. Pin No. Signal Name VCC_SYS_5V0 VCC_SYS_5V0 VCC_SYS_5V0 VCC_SYS_5V0 VCC_SYS_5V0 VCC_SYS_5V0...
- Page 17 IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual ENET_TXC IO_PWM1_OUT ENET_TD0 POR_B ENET_TD1 SYS_nRST ENET_TD2 ONOFF ENET_TD3 USB_HUB_RST IO_CAN1_nRST ENET_RX_CTL IO_CAN2_nRST ENET_RXC IO_CAN1_nINT IO_CAN2_nINT ENET_RD0 GPIO_ENET1_INT ENET_RD1 GPIO_TP_INT ENET_RD2 GPIO_CSI_PWDN ENET_RD3 GPIO_CSI_RST QSPIA_DATA3 ENET_MDC QSPIA_DATA2 ENET_MDIO SAI2_MCLK SAI2_RXFS SD1_CLK SAI2_RXC SD1_CMD SAI1_RXFS...
- Page 18 IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual WL_WAKE_HOST SAI5_MCLK WL_REG_ON SAI5_RXC IO_CLK_REQ SAI5_RXD0 SAI5_ RXD1 UART1_RXD SAI5_ RXD2 UART1_TXD SAI5_ RXD3 UART1_CTS SPDIF_TX UART1_RTS SPDIF_RX SAI2_RXD SPDIF_EXT_CLK SAI2_TXD BT_REG_ON SAI2_TXC BT_WAKE_DEV SAI2_TXFS BT_WAKE_HOST J4：GPIO Interface Signal Name Pin No. Pin No.
- Page 19 IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual J6: USB Pin No. Signal Name VCC_USB3(5V0) USB_DN3 USB_DP3 J8：MIC Audio Input Pin No. Signal Name MIC- MIC+ J10： Audio Output (Amplifier Output) Pin No. Signal Name SPKPL SPKNL SPKNR SPKPR J12：MINI-PCIE： Signal Name Pin No.
- Page 20 IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual SIM_CLK SIM_RST PCIE_nDISEN PCIE_nRST VCC_PCIE_3V3 PCIE_USB_DN PCIE_USB_DP VCC_PCIE_3V3 VCC_PCIE_3V3 VCC_PCIE_3V3 VCC_PCIE_3V3 J14：CSI(4-Lane CSI): Pin No. Signal Name VCC_DVP_5V0 :supports@qiyangtech.com Page 20 of 32 Any question, please send E-mail :trade@qiyangtech.com sales@qiyangtech.com Sales E-mail :http://www.qiytech.com Website ©2012 Qiyangtech...
- Page 21 IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual VCC_DVP_3V3 VCC_DVP_3V3 CSI1_CKN CSI1_CKP CSI1_DN0 CSI1_DP0 CSI1_DN1 CSI1_DP1 CSI1_DN2 CSI1_DP2 CSI1_DN3 CSI1_DP3 CSI1_I2C_SDA CSI1_I2C_SCL CSI1_PWDN CS1_RST CSI1_PWR_EN :supports@qiyangtech.com Page 21 of 32 Any question, please send E-mail :trade@qiyangtech.com sales@qiyangtech.com Sales E-mail :http://www.qiytech.com Website ©2012 Qiyangtech...
- Page 22 IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual J15：MIPI (4-Lane) & I2C Touch Panel Selectable to connect different converter board, to externally connect HDMI,LVDS,MIPI monitors. Pin No. Signal Name TP_I2C_SDA TP_I2C_SCL TP_RST TP_INT LED_BL_EN VCC_IO_5V0 VCC_IO_5V0 VCC_IO_5V0 VCC_IO_5V0 DSI_I2C_SDA LCD_MIPI_RST DSI_I2C_SCL LCD_MIPI_3N...
- Page 23 IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual LCD_MIPI_CLKP LCD_MIPI_1N LCD_MIPI_1P LCD_MIPI_2N LCD_MIPI_2P PWM1_OUT VCC_EXT_12V0 VCC_EXT_12V0 VCC_EXT_12V0 VCC_EXT_12V0 J17： JTAG Signal Name Pin No. Pin No. Signal Name VCC(3V3) nRST J18：UART2(IMX8M Debug UART) :supports@qiyangtech.com Page 23 of 32 Any question, please send E-mail :trade@qiyangtech.com sales@qiyangtech.com...
- Page 24 IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual PIN No. Signal Name UART2_TXD UART2_RXD J19： UART4(M4 Debug UART) PIN No. Signal Name UART4_TXD UART4_RXD J20：CAN PIN No. Signal Name CAN3H CAN3L J21：CAN PIN No. Signal Name CAN4H CAN4L J22：RS232(COM3) PIN No. Signal Name...
-
Page 25: Ⅳ.structure & Size
IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual J23：RS232 (COM1) PIN No. Signal Name COM1_TXD COM1_RXD J24：RS232 (COM2) PIN No. Signal Name COM2_TXD COM2_RXD J25：RS232(COM4) PIN No. Signal Name COM4_TXD COM4_RXD J30：DC12V Power In PIN No. Signal Name Ⅳ.Structure & Size: Unit of measurement: mm, if needs the receptacle’s size, please email us : supports@qiyangtech.com;... -
Page 26: Som Dimension
IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual 4.1.SOM Dimension Chart 5 Chart 6 :supports@qiyangtech.com Page 26 of 32 Any question, please send E-mail :trade@qiyangtech.com sales@qiyangtech.com Sales E-mail :http://www.qiytech.com Website ©2012 Qiyangtech Copyright... -
Page 27: Carrier Board Dimension
IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual 4.2.Carrier Board Dimension: Chart 7 :supports@qiyangtech.com Page 27 of 32 Any question, please send E-mail :trade@qiyangtech.com sales@qiyangtech.com Sales E-mail :http://www.qiytech.com Website ©2012 Qiyangtech Copyright... - Page 28 IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual Chart 8 :supports@qiyangtech.com Page 28 of 32 Any question, please send E-mail :trade@qiyangtech.com sales@qiyangtech.com Sales E-mail :http://www.qiytech.com Website ©2012 Qiyangtech Copyright...
-
Page 29: Ⅴ.connection Picture
IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual Ⅴ.Connection Picture Take a notice about the location of the SOM Chart 9 :supports@qiyangtech.com Page 29 of 32 Any question, please send E-mail :trade@qiyangtech.com sales@qiyangtech.com Sales E-mail :http://www.qiytech.com Website ©2012 Qiyangtech Copyright... -
Page 30: Ⅵ.electrical Property
IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual Ⅵ.Electrical Property Items Parameters -40℃ ~ +85℃ Operation Temp. -40℃ ~ +85℃ Storage Temp. 5%~95%, non-condensing Humidity 55mm*60mm,8-layer high precision gold immersion process SOM Dimension technology Carrier Board 200mm*130mm,4-layer high precision gold immersion process Dimension technology. -
Page 31: Ⅶ.software Description
Ⅶ.Software Description: IAC-IMX8MM-KIT provides software support, mainly including Linux/Android. IAC-IMX8MM-KIT Linux User Manual introduces how to establish and use the development environment in Linux OS specifically. If you need details, please reference that manual. IAC-IMX8MM-KIT Android User Manual introduces how to establish and use the development environment in Android OS particularly. - Page 32 IAC-IMX8MM-Kit Embedded Development Kit Hardware Manual Zhejiang Qiyang Intelligent Technology Co., Ltd Tel: 86-571-87858811 / 87858822 Fax: 86-571-89935912 Technology Support：86-571-89935913 E-MAIL: supports@qiyangtech.com Website: http://www.qiytech.com Address: 3rd Floor, Building A, WSCG Building, NO.6 Xiyuan 8th Road, Sandun Town, Xihu District, Hangzhou City, Zhejiang ,PRC .310030 Post Code:310030 :supports@qiyangtech.com...
