IAC-A5D3x-Kit Hardware Manual
Version:1.0
2013.12
QIYANG INTELLIGENT TECHNOLOGY Co., Ltd
Copyright Reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IAC-A5D3x-Kit and is the answer not in the manual?

Questions and answers

Related Manuals for Qiyang IAC-A5D3x-Kit

Summary of Contents for Qiyang IAC-A5D3x-Kit

  • Page 1 IAC-A5D3x-Kit Hardware Manual Version:1.0 2013.12 QIYANG INTELLIGENT TECHNOLOGY Co., Ltd Copyright Reserved...
  • Page 2 IAC-A5D3x-Kit Hardware Manual Version Updates Version Hardware Description Date Revisor Platform IAC-A5D3x- Launched 2013-12-20 Any question, please send E-mail :supports@qiyangtech.com Page 2 of 30 :trade@qiyangtech.com sales@qiyangtech.com Sales E-mail :http://www.qiytech.com Website ©2012 Qiyangtech Copyright...

  • Page 3: Table Of Contents

    IAC-A5D3x-Kit Hardware Manual Catalogue Preface ..................................4 1.1.Company Profile:............................4 1.2.Suggestion for using IAC-A5D3x-Kit development board................. 5 Ⅱ.System Composition............................. 6 2.1. ARM Kernel Performance Comparison...................... 6 2.2. SAM5D3 Processor Series Function ......................7 2.3. Onboard Resource ............................ 10 2.4 Core Board Resource..........................11 2.5.Back Plane Resource ..........................

  • Page 4: Preface

    Preface 1.1.Company Profile: Hangzhou Qiyang Technology Co., Ltd. is located at the bank of the beautiful West Lake. It is a high and new technology enterprise which is specializing in R&D, manufacture and sell embedded computer main board with high performance, low power consumption, low cost, small volume, and provides embedded hardware solutions.

  • Page 5: Suggestion For Using Iac-A5D3X-Kit Development Board

    IAC-A5D3x-Kit Hardware Manual 1.2.Suggestion for using IAC-A5D3x-Kit development board. 1. Please read the instructions first, before using the development board; 2. Before using, please check the packing list and see whether there is a missing file in the CD; 3. Please understand the basic structure and composition of the development board, including the hardware resource allocation, each pin definition of core board and back plane etc.;...

  • Page 6: Ⅱ.system Composition

    IAC-A5D3x-Kit Hardware Manual Ⅱ.System Composition 2.1. ARM Kernel Performance Comparison Kernel ARM9 ARM11 Cortex A5 Cortex A8 Cortex A9 Architecture(RISC) ARMv5TE ARMv6 ARMv7 ARMv7 ARMv7 Prediction 200-470 MHz 400-1000 MHz 300-800 MHz 600-1000 MHz 600-1000 MHz DMIPS/MHz 1.25 1.57 The Cortex-A5 processor provides a high-value migration path for existing ARM926EJ-S™...

  • Page 7: Sam5D3 Processor Series Function

    Cortex A5&ARM9/ARM11 2.2. SAM5D3 Processor Series Function IAC-A5D3x-Kit adopts ATMEL SAMA5D3X series chips and Cortex A5 kernel. Standard configuration is SAMA5D34 development board. For batch order users, we can adopt different chips to lower cost. Please see the following detailed version Any question, please send E-mail :supports@qiyangtech.com...
  • Page 8 ● ● ● IAC-A5D3x-Kit is the ARM Cortex-A5 series of ARM v7-A Thumb2 instruction set computing (RISC) microprocessor released by ATMEL. 32 KB data cache, 32 KB instruction cache, the virtual memory system architecture(VMSA), fully integrated MMU and Floating-point Unit(VFPv4), also SAMA5D3X with extremely abundant interface resource.
  • Page 9 IAC-A5D3x-Kit Hardware Manual ARM Cortex-A5,536MHZ; ◆ ◆ 24-bit LCD controller and touch panel controller, resolution up to 2048*2048; ◆ 2-ch USB2.0 OTG integrated PHY; ◆ Support Max. 6-ch UART; ◆ 2-ch industrial Ethernet MAC(10/100MHZ); ◆ 2-ch CAN ports, support CAN2.0 A protocol and B protocol;...

  • Page 10: Onboard Resource

    IAC-A5D3x-Kit Hardware Manual ◆ Common peripheral: Multi-channel SPI、I2C、ISI、JTAG、timer. 2.3. Onboard Resource ATMEL SAMA5D34 CPU，ARM Cortex A5 Kernel,536MHZ DDR2 SDRAM，total 256MB Flash 256MB NandFlash，2MB DataFlash Network DM9162 Network Chip, adopt MII mode,support 10M/100Mperfectly 5-ch RS232 UART, include: 1-ch port is as the debug UART, 2-ch RS232 Multiplex with RS485 3-ch USB2.0, include:1-ch USB2.0 Device,2-ch USB2.0 HOST...

  • Page 11: Core Board Resource

    IAC-A5D3x-Kit Hardware Manual Mechanical Chart Mainboard structure and size chart Core Board: 74mm*53mm;Back Plane:160mm*110mm Size Core Bord:8-layer high precision immersion gold process; Back Layer Plane:4-layer high precision immersion gold process Power Core Board<1W;Whole Board≤2W Consumption Operation -20℃ ~ +70℃ Temperature （Can be customized to the industrial range -40℃...

  • Page 12: Back Plane Resource

    ◆ Provide reset circuit and wake-up function. 2.5.Back Plane Resource Qiyang expands the standard IAC-A5D3x-MB back plane, using high precision 4-layer PCB with the best electric performance and anti-interference ability. Also it fully expands different kinds of interface resources supported by SAMA5D3X, which users can customize it base on your own needs.

  • Page 13: Ⅲ.interface Illustration

    IAC-A5D3x-Kit Hardware Manual Ⅲ.Interface Illustration: 3.1. Block Diagram: 3.2. Basic Interface Function Description: Label Function Debug UART UART 1&RS485_1 Any question, please send E-mail :supports@qiyangtech.com Page 13 of 30 :trade@qiyangtech.com sales@qiyangtech.com Sales E-mail :http://www.qiytech.com Website ©2012 Qiyangtech Copyright...
  • Page 14 IAC-A5D3x-Kit Hardware Manual UART 0&UART 3 UART 2&RS48_2 Ethernet interface 0 Ethernet interface 1 LCD interface I2C capacitive interface LCD power supply selection VGA interface 2-USB Host interface USB Device interfafce Reserved USB WIFI interface multiplexes USB Device Audio output interface...

  • Page 15: Pin Definition

    IAC-A5D3x-Kit Hardware Manual 3.3 Pin Definition: J1： Signal Name Signal Name USB0_DP PIO_D31 USB0_DM PIO_D30 PIO_D29 USB1_DP PIO_D28 USB1_DM JTAG_NTRST JTAG_TCK JTAG_TDI JTAGSEL JTAG_TMS JTAG_TDO CAN0_RX PIO_D16 CAN0_TX PIO_B18 PIO_C29 PIO_B25 PIO_C30 PIO_E16 EBI_A0 PIO_E17 EBI_A1 PIO_E29 I2C1_SDA I2C1_SCL SSC0_TF...
  • Page 16 IAC-A5D3x-Kit Hardware Manual DEBUG_RXD DEBUG_TXD UART0_RXD UART0_TXD UART1_RXD UART1_TXD UART1_CTS UART1_RTS UARD2_RXD UART2_TXD UART2_CTS UART2_RTS UART3_RXD UART3_TXD MCI0_D4 MCI0_D5 PWMH3 PWML3 PIO_E11 PIO_E10 PIO_E13 PIO_E12 PIO_E15 PIO_E14 EBI_IRQ EBI_NCS1 EBI_NCS2 EBI_NRD EBI_NWE EBI_NWAIT EBI_A2 EBI_A3 EBI_A4 EBI_A5 EBI_A6 EBI_A7 EBI_A8...
  • Page 17 IAC-A5D3x-Kit Hardware Manual EBI_D11 EBI_D12 EBI_D13 EBI_D14 EBI_D15 J2： Signal Name Signal Name AVDDT TPRX- TPTX- TPRX+ TPTX+ LED_LNK LED_ACT SPI1_NCS3 SPI1_NCS0 SPI1_SCLK SPI1_MISO SPI1_MOSI MCI1_CMD MCI1_CLK MCI1_D0 MCI1_D1 MCI1_D2 MCI1_D3 SSC0_RD SSC0_RK I2C0_SDA I2C0_SCL MCI0_CMD MCI0_CLK MCI0_D0 MCI0_D1 MCI0_D2...
  • Page 18 IAC-A5D3x-Kit Hardware Manual LCD_D14 LCD_D13 LCD_D12 LCD_D11 LCD_D10 LCD_D9 LCD_D8 LCD_D23 LCD_D22 LCD_D21 LCD_D20 LCD_D19 LCD_D18 LCD_D17 LCD_D16 LCD_DE LCD_PCLK LCD_HS LCD_VS LCD_PWM LCD_DISP ADC_D0 ADC_D2 ADC_D1 ADC_D3 ADC_D4 ADC_D6 ADC_D5 ADC_D7 VDDBU ETXD0 EMDC ETXD1 EMDIO ERXD0 PIO_C10 ERXD1...
  • Page 19 IAC-A5D3x-Kit Hardware Manual SHDN ADTRG +5.0VD +5.0VD +5.0VD +5.0VD J3：Debugging UART Signal Name J_DTXD J_DRXD J4：UART 1&RS485_1 Signal Name Signal Name J_TXD1 J_RXD1 J_CTS1 J_RTS1 J_485A1 J_485B1 J5：UART 3&UART 0 Signal Name Signal Name J_TXD3 J_RXD3 J_TXD0 J_RXD0 Any question, please send E-mail :supports@qiyangtech.com...
  • Page 20 IAC-A5D3x-Kit Hardware Manual J6：UART 2&RS485_2 Signal Name Signal Name J_TXD2 J_RXD2 J_CTS2 J_RTS2 J_485A2 J_485B2 J9：LCD Interface Signal Name Signal Name LCD_PCLK LCD_HS LCD_VS LCD_D12 LCD_D13 LCD_D14 LCD_D15 LCD_D16 LCD_D17 LCD_D6 LCD_D7 LCD_D8 LCD_D9 LCD_D10 LCD_D11 LCD_D0 LCD_D1 LCD_D2 LCD_D3...
  • Page 21 IAC-A5D3x-Kit Hardware Manual LCD_PWM ADC_D0 ADC_D2 ADC_D1 ADC_D3 J10：I2C Capacitive Touch Panel Interface Signal Name PIO_C14 PIO_C15 I2C0_SCL I2C0_SDA +3.3VD J11：LCD Power Supply Jumper Selection Connect PIN1 and PIN 2: 3.3V power supply Connect PIN2 and PIN3:5.0V power supply Select the voltage according to the actual LCD screen or driver board Signal Name +3.3VD...
  • Page 22 IAC-A5D3x-Kit Hardware Manual Signal Name Signal Name GREEN BLUE HSYNC_VGA GND_VGA VSYNC_VGA GND_VGA GND_VGA GND_VGA GND_VGA J15：USB_WIFI Reserved Interface Signal Name +3.3VD/+5.0VD USB0_DM USB0_DP J17：EBI Signal Name Signal Name +3.3VD +3.3VD EBI_IRQ EBI_NCS1 EBI_NCS2 EBI_NRD EBI_NWE EBI_NWAIT EBI_A0 EBI_A1 EBI_A2...
  • Page 23 IAC-A5D3x-Kit Hardware Manual EBI_D2 EBI_D3 EBI_D4 EBI_D5 EBI_D6 EBI_D7 EBI_D8 EBI_D9 EBI_D10 EBI_D11 EBI_D12 EBI_D13 EBI_D14 EBI_D15 J19：Reserved multi voltage source output interface Signal Name +12VD +5.0VD +3.3VD J21:SDIO Interface Signal Name Signal Name +3.3VD SYS_RSTN MCI1_D0 MCI1_D3 MCI1_CMD MCI1_D2...
  • Page 24 IAC-A5D3x-Kit Hardware Manual Signal Name Signal Name +3.3VD I2C1——SCL (ISI_D10) I2C1_SDA (ISI_D11) I2C0_SDA (ISI_VSYNC) I2C0_SCL (ISI_HSYNC) PIO_C30 (ISI_PCK) PIO_D31 (MAIN_CLK) SPI1_NCS3 (ISI_D9) PIO_C29 (ISI_D8) LCD_D23 (ISI_D7) LCD_D22 (ISI_D6) LCD_D21 (ISI_D5) LCD_D20 (ISI_D4) LCD_D19 (ISI_D3) LCD_D18 (ISI_D2) ISI_RST ISI_PWND LCD_D17 (ISI_D1) LCD_D16 (ISI_D0) J23:GPIO&Keyboard Interface...
  • Page 25 IAC-A5D3x-Kit Hardware Manual J24：JTAG Interface Signal Name Signal Name +3.3VD +3.3VD JTAG_NTRST JTAG_TDI JTAG_TMS JTAG_TCK JTAGSEL JTAG_TDO SYS_RSTN J25：AD&I2C Interface Signal Name Signal Name +3.3VD +3.3VD ADTRG ADC_D4 ADC_D5 ADC_D6 ADC_D7 I2C1_SDA I2C1_SCL J26：SPI Interface Signal Name Signal Name +3.3VD +3.3VD...

  • Page 26: Ⅳ. Device Connection Picture

    CANL0 GND_CAN Ⅳ. Device Connection Picture IAC-A5D3X-Kit adopts back-insert form, and core board connects to back board through 2 * 100 pins B to B connector, which constitutes the complete intelligent equipment, the connection mode is as shown: Any question, please send E-mail :supports@qiyangtech.com...
  • Page 27 IAC-A5D3x-Kit Hardware Manual Any question, please send E-mail :supports@qiyangtech.com Page 27 of 30 :trade@qiyangtech.com sales@qiyangtech.com Sales E-mail :http://www.qiytech.com Website ©2012 Qiyangtech Copyright...

  • Page 28: Ⅴ. Development Board Performance Index

    IAC-A5D3x-Kit Hardware Manual Ⅴ. Development Board Performance Index Ⅵ. Size & Structure Any question, please send E-mail :supports@qiyangtech.com Page 28 of 30 :trade@qiyangtech.com sales@qiyangtech.com Sales E-mail :http://www.qiytech.com Website ©2012 Qiyangtech Copyright...

  • Page 29: Ⅶ.software Description

    IAC-A5D3x-Kit Hardware Manual Ⅶ.Software Description IAC-A5D3X-Kit provides the software include Linux. It introduces how to set up and employ the Linux development environment. More detailed information, please refer to the relative documentation in IAC-A5D3X-KIT Linux User Manual. Ⅷ. Remark 1. Before connect to LCD, confirm LCD power specification.
  • Page 30 Shall not distribute them on the Internet. Shall not intercept, modify them to tamper copyright. 7. We accept batch order; we can offer technical support and service. Hangzhou Qiyang Intelligent Technology Co., Ltd Tel: 86-571-87858811 / 87858822 Fax: 86-571-89935912 Technology Support：86-571-89935913...
