Expedition One Universal Tire Mount Installation Manual

Hide thumbs

Advertisement

Table of Contents

I N STA L L AT I O N G U I D E
U N I V E R S A L T I R E M O U N T

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Universal Tire Mount and is the answer not in the manual?

Questions and answers

Related Manuals for Expedition One Universal Tire Mount

Summary of Contents for Expedition One Universal Tire Mount

  • Page 1 I N STA L L AT I O N G U I D E U N I V E R S A L T I R E M O U N T...
  • Page 2 N OT E We highly recommend customers wait until they have the product in hand to schedule installations. All cancellations are required in writing and will incur a 10% re-stock fee and any applicable packaging and shipping fees. Please review terms and conditions for details.
  • Page 3 H A R DWA R E HARDWARE 1/2”-13 X 1 1/4” HEX CAP 1/2”-13 NYLOC NUT 1/2” USS WASHER 3/8”-16 X 1 1/4” HEX CAP TIRE MOUNT 3/8”-16 NYLOC NUT 3/8” USS WASHER VEHICLE DEPENDENT – METRIC 12 OR 14 STUD LUG NUT TEAR DROP SPACER...
  • Page 4 B O LT PAT T E R N NOTE - May NOT work with all patterns, wheels, or lug combinations or some aftermarket wheels...
  • Page 5 P R ES S I N ST U D S NOTE - Studs can be pressed in using a press - Manually by putting the stud through the opening and placing the lug upside down with the large washer over the threaded end. Screw the wheel nut on with an impact, it will suck the stud through The are various forums, websites and how to videos (YouTube) on this.
  • Page 6 I N STA L L AT I O N TIRE CARRIER ASSEMBLY - Assemble the tire mount as shown by sliding the tire carrier over the top of the swing arm mount loosely mount with the 1/2” hardware as shown below. Mount in the desired position on either swing arm using the 3/8”...
  • Page 7 Mounting the tire carrier to high may result in damage and will NOT be warrantied. Mount as low on the arm as possible. It is recommend that if the tire carrier is mounted past the top of arm, that it go no further than the 3 bottom slot locations.
  • Page 8 TIRE CARRIER PLACEMENT - Attach the tire mount in the desired position and mount using the provided 1/2” hardware. NOTE Certain options may not work with all tire and wheel combinations or vary per vehicle DO NOT mount the tire high or past the top of the arm TIGHTEN ALL HARDWARE AFTER EVERYTHING IS INSTALLED ON THE VEHICLE.
