Summary of Contents for Expedition One MULE
- Page 1 INSTALLATION GUIDE LEXUS GX MULE ROOF RACK...
- Page 2 5 STARS EXPERT - Professional installation recommended. DISCLAIMER Expedition One is not responsible for any damages to vehicle or injury. We always recommend professional assistance when installing our vehicle products. Always follow safety procautions including the use safety gear and devices.
- Page 4 HARDWARE HARDWARE ITEM Lexua GX Mule Ultra Roof Rack Front Brace Left Rail Right Rail Rear Brace Front - Cutout or No Cutout Left Side Right Side Rear Front Left Seam Joiner Front Right Seam Joiner Rear Left Seam Joiner...
- Page 5 RACK ASSEMBLY ATTENTION When assembling the Mule Ultra Rack, remember to hand-tighten all bolts relatively loose until the very end of the install. This allows everything to fit into place before everything is tightened down. OEM ROOF RACK REMOVAL Remove the OEM roof rack from the vehicle by undoing the hardware located at each mount.
- Page 6 REAR BRACE AND SIDE FASCIA MOUNTING Attach the rear brace and side fascias shown using 1/4” and 5/16” bolts on both sides as shown below.
- Page 7 SIDE FASCIA CONTINUED REAR FASCIA MOUNTING Attach rear fascia as shown with 5/16” bolts and nuts.
- Page 8 FRONT FASCIA MOUNTING Attach the front fascia using 1/4” bolts. Use the provided round spacers to adjust the front fascia to match the curve of the roof when test fitting the roof rack during mounting. NOTE: IF YOU HAVE A FASCIA WITH A LIGHT BAR CUTOUT, WE RECOMMEND INSTALLING THE LIGHT BAR PRIOR TO MOUNTING THE ROOF RACK.
- Page 9 SEAM JOINERS Mount both front and rear seam joiners with 5/16” hardware as shown top and bottom.
- Page 10 REINFORCEMENT SPACERS Attach reinforcement spacers as shown on all 6 hole locations (3 each side) with the provided hardware.
- Page 11 LOAD BAR ASSEMBLY Assemble the load bars with the provided mounts using 1/4” bolts and nuts. Repeat for all load bars. LOAD BAR INSTALLATION Flip roof rack over and attach load bars as shown. Using provided nuts and bolts, you may begin tightening down each load bar with two bolts and nylocs for each side.
- Page 12 ROOF RACK MOUNTS MOUNTING AREA In preperation for attaching the roof mounts cut a foam strip to lenght of mount area and attach. It is recommended that you place 2 of the large (thicker) spacers over each the mounting location. Extra spac- ers are provided to level and shim the rack mounts as needed.
- Page 13 ROOF MOUNTS CONTINUED DRIVER SIDE PASSENGER SIDE...
- Page 14 ROOF RACK INSTALLATION ROOF RACK MOUNTING Place the roof rack onto vehicle with help of a friend and align with each bracket. Use the provided 5/16” bolts and washers for each mount hole location and tighten down roof rack to each bracket as shown below.
