PRODUCT SPECIFICATIONS

Model Number
Motor:
Drum Capacity
Drum Mouth
Drum Speed
Overall Sizes
Weight

ELECTRICAL CONNECTION

This mixer is double insulated to Class II protection and IP44D rated. The insulation will
only remain effective if the original insulating parts are used for repairs and the spaces
between the original insulation are maintained.
This mixer is double insulated to Class II protection and IP44D rated. Assembly
and disassembly of the enclosure of electric control are critical to keep them remain
effective. Only qualified electrician is allowed to repair the enclosure of electric control.
Double insulation eliminates the need for the three-wire grounded power cord and
grounded power supply system. Double insulated tools can use either a two or three
wire extension cord.
Double insulation eliminates the need for the three-wire grounded power cord and
grounded power supply system. Double insulated tools can use either a two or three wire
extension cord.
Do not connect either core to the earth pin.
1
Length
Width
Height
CEMENT MIXER - OWNER'S MANUAL
HCM400
120V~60Hz, 5A
115 Liters / 25 gallons
385 mm
26.7 / min
1200 mm / 47"
710 mm / 28"
1350 mm / 53"
45 kg / 99 lbs
