EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD6E104 EVDRIVE06 Electronic expansion valves drivers ENGLISH USER MANUAL ver. 1.0 CODE 144EPD6E104 Page 1 of 78...
Page 2
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 Important Important Read this document carefully before installing and using the device and follow all the additional information; keep this document close to the device for future consultations. The following symbols support the reading of the document: it indicates a suggestion it indicates an additional information.
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 Index INTRODUCTION ........................... 5 Introduction ............................5 Summarizing table of the main features and available models ..............6 DESCRIPTION ............................8 Description ............................8 SIZE AND INSTALLATION ........................9 Size ..............................
Page 4
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 Simulation mode ..........................40 List of configuration parameters ......................41 SERIAL COMMUNICATION ........................58 Preliminary information ........................58 CANBUS serial communication ......................58 8.2.1 CAN Master tool ......................... 58 8.2.2...
EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 INTRODUCTION Introduction The drivers of the EVDRIVE06 series are devices studied for the management of bipolar stepper electronic expansion valves. They are available in built-in and blind version (according to the model).
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 Summarizing table of the main features and available models The following table shows the main features of the devices and the available models. The character “ / “ means the feature can be set through a configuration parameter.
Page 7
RS-485 port with MODBUS communication • • protocol USB port • • • • Codes codes EPD4BX6 EPD4BC6 EPD4BF6 EPD4DF6 For further information look at chapter 11 “TECHNICAL DATA”; for further models please contact the EVCO sales network. Page 7 of 78...
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 DESCRIPTION Description The following drawing shows the aspect of EVDRIVE06. The following table shows the meaning of the parts of EVDRIVE06. Part Meaning digital output analog inputs and free of voltage digital inputs...
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 SIZE AND INSTALLATION Size The following drawing shows the size of EVDRIVE06 (4 DIN modules); size in mm (in). Page 9 of 78...
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 Installation On DIN rail 35.0 x 7.5 mm (1.377 x 0.295 in) or 35.0 x 15.0 mm (1.377 x 0.590 in). To install the device operate as shown in the following drawing.
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 ELECTRICAL CONNECTION Meaning of the connectors The following drawing shows the connectors of EVDRIVE06. The following tables show the meaning of the connectors; for further information look at chapter 11 “TECHNICAL DATA”.
Page 12
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 common analog inputs and free of voltage digital inputs analog input 1 (which can be set via configuration parameter for NTC/Pt 1000 probes and for 0-20 mA/4-20 mA/0-5 V ratiometric transducers)
Page 13
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 CAN port line termination (not available in model EPD4BX6) Position microswitch 2 on position on (120 , 0.25 W) to plug in the CAN port line termination (plug in the termination of the first and of the last element of the network).
Page 14
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 Power supply Terminal Meaning power supply device (not isolated; 24 VAC +10% -15%, 50/60 Hz ±3 Hz, 40 VA max. or V+ 24... 37 VDC, 22 W max.) power supply device (not isolated; 24 VAC +10% -15%, 50/60 Hz ±3 Hz, 40 VA max. or V-...
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 Example of electrical connection The following drawing shows an example of electrical connection of EVDRIVE06. Please note the power supply of EVDRIVE06 and that of EPS4B are not isolated one another: it is important to wire correctly the devices as indicated in the drawing.
11 “TECHNICAL DATA” disconnect the power supply of the device before servicing it do not use the device as safety device for the repairs and for information about the device please contact the EVCO sales network. Page 16 of 78...
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 USER INTERFACE Preliminary information EVDRIVE06 is available in built-in and blind version (according to the model). The built-in versions can be programmed through the user interface, the blind ones must be used with a remote user interface (for example EPJgraph): both the versions can be programmed through the set-up software system Parameters Manager;...
Page 18
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 LED auxiliary if parameter Ph80 = 0, LED status if it is lit, the device will be working in superheating algorithm modality if it flashes slowly, the device will be working in manual or in debugger modality...
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 OPERATION Switch on and resynchronization At switch-on and after a resynchronization, the fundamental parameters for moving the motor are acquired. The parameters of pressure and temperature units of measure are loaded at switch-on, and, if necessary, is performed the conversion of all the parameters of pressure and temperature.
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 6.1.2 Valve selection To select the desired valve, it is necessary to set the correct value in Valve selection (parameter Pi07). Setting this parameter to a value of 0 (generic valve) means setting the parameters Pr50 to Pr55 is required, with which it is possible to specify the value of each valve parameter.
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 It means if the nominal step rate of the valve is higher than 625 steps/s, 8 microsteps/s will be used; while if the nominal step rate is lower than 625 steps/s, 16 microsteps/s will be used.
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 Operating mode 6.2.1 Preliminary information EVDRIVE06 implements a stepper motor control according to the state machine presented in the table here below (hereinafter the document will make reference to these status).
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 Stand-by and operation mode selection At the end of the resynchronization operations the machine will enter the stand-by state, during which the installer parameters are loaded and configurations are checked.
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 Analog inputs The configuration of each analog inputs is achieved by setting the related parameter: Aix probe type (Piax) determines the kind of probe connected to the analog input and Aix probe usage (Piux) determines the use of the analog input, where "x"...
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 In this example, the following values have been applied to the AI4 probe: PH60 = 0 (pressure measurement unit = Bar) P4Xty = 1 (0÷20 mA) PxYty = 1 (BarA)
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 Algorithm start-up To enter algorithm mode, from the Stand-by off (10), set the Main control type parameter Pr01 = 6 to perform Superheat (SH) control or Pr01 = 8 to perform hot gas bypass control. If all the configuration is correct enter in Stand-by on (11) and then in the Stabilization (40), in which is performed a positioning to Stabilization position (parameter Pr09) and await Stabilization delay (parameter Pr08).
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 Debugging mode The debugger feature is enabled when Pr02 = 2: the valve will move from a Debug minimum position (parameter Prd1) to a Debug maximum position (parameter Prd2) with the step rate defined by Debug step rate (parameter Prd0).
Page 28
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 SH parameters set selection (SetP) supports switching from one control parameter set to another simply and quickly. It is possible to change the regulation parameter sets directly by modifying SH parameters set selection (Pr04), if a serial interface is present, or via correctly configured digital inputs on the standalone version.
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 6.10.2 Hot gas bypass algorithm The purpose of this control is to maintain the temperature at its set-point value. After selecting the control algorithm, it is necessary to set the various regulation parameters: ...
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 6.11 Alarm relay The alarm relay is managed directly by the application. It is possible to set the Relay function (parameter Ph01) and Relay logic (parameter Ph02). The alarm relay can be operate if there is an alarm situation depending of the choose (Ph01 = 1÷5): any alarm, only probe alarm, only LoSH alarm, only for MOP alarm, only for valve alarm.
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 CONFIGURATION Unit of measurements Units of measurement used in the internal algorithm are Celsius (ºC) and Kelvin (K) degrees in tenths for temperatures, and barG in hundreds for pressure.
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 7.2.1 User menu Make sure the power supply is switched on. Move among the pages using the buttons as shown in the example here below, using the buttons to scroll through the menu pages: Page User.1...
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 The first pages are dedicated to the end user and permit display of major features of the EVDRIVE06, any alarm messages, or whether it is necessary to resynchronise or reset the machine after changing parameters. In the PageUser2 , the fourth line is visible and blinking only if there is a request for resynchronization;...
Page 34
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 Page Manufacturer 1 Page Manufacturer 1.a Page Manufacturer 1.a.1 Page Manufacturer 1.c Page Manufacturer 1.d Page Manufacturer 1.e Page Manufacturer 1.f Page Manufacturer 1.f The backup and restore functionalities are active only in Stand-by off (10). They are protected by the Level 5 password and permit to download a copy of the EVDRIVE06 application's parameters and/or the driver's parameters (communication settings, etc.) in the memory or in the parameters key.
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 Configuring a blind version The following procedures show an example of configuration of a blind version through an user interface (in the example EPJgraph) and through its user interface.
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 Main menu The following procedures show how to gain access to the main menu. The main menu provides information on the project, on the status of the inputs, allows to set the level’s passwords, etc.
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 CAN network configuration and status pages Modbus on RS485 configuration page USB status page Password setting page Diagnostic page Internal status RS485 status Connecting the device through the set-up software system Parameters Manager The following procedure shows how to connect the device to the set-up software system Parameters Manager.
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 Switch on the power supply of the device. Operate as related in the User manual of Parameters Manager. Backup and restore If the EVDRIVE06 driver version is displayed (using the built-in display or another display connected via the CAN port) you can view the backup / restore pages which permit to save a copy of the memory areas of the parameters.
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 Reprogramming It is possible to reprogram the device using a USB flash drive in which the work.ucjb and work.ucje files have been copied. Once the USB flash drive is inserted, the files are copied in the device, which restarts: if the downloaded program is suitable, the device is reprogrammed with the new version.
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 Simulation mode EVDRIVE06 can be used in input simulation mode by setting the following parameters. The value of Probe 1/2/3/4 Simulation value (Si5/6/7/8) is in accordance with its configuration:...
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 List of configuration parameters The following is a complete list of parameters managed by the application, each with a short code, the ModBus address (Adr), brief description, default values and limits, measurement units (U), the menu in which they are accessed (M) and the notes.
Page 42
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 = from CAN bus = reserved = from serial Modbus RS-485 = from serial Modbus USB = from CAN bus + DI1/2 in communication error = reserved = from serial Modbus RS-485 + DI1/2 in comm.
Page 43
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 Par. Add. Acc. Min. Mas. Unità Default Menu Valve and driver: debug Prd0 1616 1000 step/s User debug step rate Prd1 1617 0.00 Prd2 0.00 User debug minimum position...
Page 45
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 Valve driver: refrigerant Par. Add. Acc. Min. Mas. Unità Default Menu equipment type of refrigerant = R-22 = R-134A = R-402A = R-404A = R-407A = R-407C = R-410A...
Page 46
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 = Sporlan SER 1.5-20 = Sporlan SEI 0.5-11 = Sporlan SEI 30 = Sporlan SEI 50 = Sporlan SEH 100 = Sporlan SEHI 175/400 10 = Sporlan SDR-3 11 = Sporlan SDR-4...
Page 47
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 free of voltage digital input DI1 function = none = enable/disable valve Ph11 1623 - - - - Manufact. = change parameters set = resynchronization request = backup battery status...
Page 48
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 probe = suction pressure backup probe analog input AI1 probe type (used if Piu1 = 1 or 2) = NTC probe = Pt 1000 probe 10 = 4÷20 transducer (0÷10...
Page 49
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 P1YM 1652 P1Ym 300.00 barG/barA 1.00 Manufact. Y max value P1Ym 1653 P1YM barG/barA 0.00 Manufact. Y min value 300.00 Probe settings: analog input AI2 Par. Add. Acc. Min.
Page 50
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 1:20.00 2:5.00 0:0.00 P2Xm 1658 1:4.00 P2XM - - - - 0.00 Manufact. X min value 2:0.00 Y type P2Yty 1659 - - - - Manufact. = barG = barA...
Page 51
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 = 4-20 mA = 0-5 V = 0-10 V 0:20.00 1:20.00 P4XM 1673 P4Xm - - - - 5.00 Manufact. X max value 2:5.00 3:10.00 0:0.00 1:4.00 P4Xm 1674...
Page 52
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 = 50K = 125K = 500K CANt 1741 User CAN timeout Par. Add. Acc. Min. Mas. Unità Default Menu Simulation Enable simulation mode Ps01 1700 User 0: normal mode...
The EVDRIVE06 behaves as an expansion to read the analog inputs AI1 and AI2, read digital inputs and write the relay. (Note that driving the relay by the controller completely bypasses its function set by parameter.) CANBUS serial communication The EVCO controllers primarily use a protocol based on CANbus for communication with controllable systems. 8.2.1 CAN Master tool The exchange of data is based on a list of variables or parameters that the controller may send to the driver, and a list of variables the driver sends to the controller to provide its state data, using the CAN Master tool.
Page 59
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD4I114 Target position (Psp) FW project Current valve position % (PAtt) FW variation Communication alarm enable status(Pa01) FW version Communication alarm delay (Pa02) FW revision 8.2.1.2 Control variables AI1 type (AI1T used if Piu1 = 0)
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD6E104 8.2.2 Commands For the variables that need an immediate refresh, commands are implemented. The CommandOut allows to write commands on the device. The device performs the new values as soon as possible.
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD6E104 ALARMS AND ERRORS Alarms and errors The system supports a series of alarms related to both the system (memory, probes, communication, configuration, etc.), and the regulation algorithm (LoSH, HiSH, LOP, MOP, Low Pressure).
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD6E104 Invalid value for parameter PIA3 Invalid value for parameter PIA4 PIu1 configured as another Piux Parameters Piu1, Piu2, Piu3 and Piu4 must each PIu2 configured as another PIux have different values, or null.
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD6E104 The significance of bit 3 and 2 of Alarm status (AlSt) are shown in the following table: bit3 bit2 Significance No communication alarm Warning Communication alarm in standalone mode...
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD6E104 Power failure and backup battery error The EVDRIVE06 supports connection to a backup battery in order to allow a complete closure of the valve in the case of power supply failure.
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD6E104 Superheat algorithm protection functions 9.8.1 LoSH When enabled (Pa10), this alarm is triggered when the SH drops below the low heating threshold (Pc02, Pp02, Pd02). The condition is signalled in the Algorithm status (AlgS) and, when the timeout (Pa12) expires, an alarm is set.
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD6E104 Parameters error Bit 12 of Alarm status (AlSt) indicates that there was a problem during the automatic conversion of the parameters of temperature and/or pressure and it is possible that not all parameters have been successfully converted.
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD6E104 ACCESSORIES 10.1 optoisolated RS-485/USB serial interface EVIF20SUXI 10.1.1 Introduction EVIF20SUXI is a non optoisolated RS-485/USB serial interface. Through the interface it is possible to connect the driver to the set-up software system Parameters Manager.
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD6E104 10.1.3 Size Size is in mm (in). 10.1.4 Connection to the Personal Computer Operate as follows: Connect the RS-485 port on screw terminal block of the interface to the RS-485 port of the device using three...
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD6E104 10.2 Backup module EPS4B 10.2.1 Introduction EPS4B is a backup module. Through the module it is possible to close the valve in case of lack of power supply of the driver.
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD6E104 10.2.3 Size Size is in mm (in). 10.2.4 Connection to the device Look at chapter 4 “ELECTRICAL CONNECTION”Operate as follows: Please note the power supply of EVDRIVE06 and that of EPS4B are not isolated: it is important to wire correctly the devices as indicated in chapter 4.
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD6E104 TECHNICAL DATA 11.1 Technical data Purpose of the device: electronic expansion valves driver. Box: self-extinguishing grey. 71.0 x 128.0 x 60.0 mm (2.795 x 5.039 x 2.362 in; W x H x D);...
Page 72
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD6E104 The maximum lengths of the connecting cables are the following: power supply device: 30 m (98 ft) analog inputs: 100 m (328 ft) power supply 0-20 mA/4-20 mA/0-5 V ratiometric/0-10 V...
Page 73
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD6E104 4 inputs of which 2 inputs (non optoisolated, which can be set via configuration parameter for NTC/Pt 1000 probes and for 0-20 mA/4-20 mA/0-5 V ratiometric transducers) which can be set via...
Page 74
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD6E104 0-5 V ratiometric analog inputs Input resistance: ≥ to 10K Ω. Accuracy: ±1% of the full scale. Resolution: 0.01 V. Conversion time: 100 ms. Protection: against the reversal of polarity.
Page 75
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD6E104 128 x 64 pixel single colour (black with rearlighting through white signalling LEDs. LEDs) graphic display, signalling LEDs. 1 SPST 5 res. A @ 250 VAC (5 res. A @ 30 VDC) output (electromechanical relay) which can be set via configuration parameter as alarm output/solenoid valve/resynchronization valve.
Page 76
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD6E104 1 non optoisolated CAN port optoisolated with CANBUS communication CAN port with protocol, optoisolated 1 USB port. CANBUS RS-485 port with MODBUS communication communication protocol and 1 protocol and 1 USB port.
Page 77
This document is exclusive property of EVCO; reproduction and disclosure are prohibited without express authorisation from EVCO. EVCO is not liable for any features, technical data and possible errors stated in this document or deriving from use of the same.
Page 78
EVCO S.p.A. EVDRIVE06 | User manual ver. 1.0 | Code 144EPD6E104 EVCO S.p.A. Via Feltre 81, 32036 Sedico (BL) ITALY phone +39 0437 8422 | fax +39 0437 83648 email info@evco.it | web www.evco.it page 78 of 78...
