- Page 1 MILL ONE Assembly Manual Manual Illustrated by Gontarz Design Studio...
- Page 2 Cutting bits used for the Mill One should be used at the discretion of the user. Bits are sharp and can crack and break without notice so appropriate care should be taken by the user while manipulating and installing them.
-
Page 3: List Of Parts
LIST OF PARTS M3-N M3-8 M3-15 M5-N M5-NE M5-W M5-25 1 2 x 10 x M8-N M8-15 M8-25 P-NH 1 2x 2 6x 1 2x P-FB P-AM P-RM P-EH E-ARD E-CNC E-HJ E-SDH E-SDC P-PH AR-400 AR-200 LS-400 LS-200 F-AC Tools: Phillips 10mm... - Page 4 STEP 1 Lead Screw Nut Holding Assembly P-NH M3-15 M3-N Allen Take note that one of the three plastic nut holders (P-NH) is a different colour and is not the same as the one depicted. It’s still assembled the same way but is specially used for Step 2.
- Page 5 STEP 2 XZ Gantry Assembly G-XZ M5-25 M5-N Allen This is the mirrored lead screw nut assembly. Check that the M5 nuts are properly fitting into the nut traps.
- Page 6 STEP 3 Y Gantry Assembly M5-25 M5-N Allen...
- Page 7 STEP 4 XZ Gantry Assembly M5-25 M5-W M5-N M5-NE 10mm Allen Wrench Match the eccentric nuts (M5-NE) to the larger holes, and the regular nuts (M5-N) to the smaller holes...
- Page 8 STEP 5 XZ Gantry Assembly M5-25 M5-W M5-N M5-NE 10mm Allen Wrench Match the eccentric nuts (M5-NE) to the larger holes, and the regular nuts (M5-N) to the smaller holes...
- Page 9 STEP 6 Y Gantry Assembly M5-25 M5-W M5-N M5-NE 10mm Allen Wrench Match the eccentric nuts (M5-NE) to the larger holes, and the regular nuts (M5-N) to the smaller holes...
- Page 10 STEP 7 Mounting the Motors to the Rails P-AM M3-8 Allen 1 2x Make sure that the motor connector is facing downwards...
- Page 11 STEP 8 Mounting the Motors to the Rails AR-400 AR-200 M8-15 Allen...
- Page 12 STEP 9 Attaching X-Lead Screw to XZ Gantry LS-400 Allen Make sure to push coupler all the way onto lead screw before tightening...
- Page 13 STEP 10 Attaching the X-Rail to the XZ Gantry 10mm Allen Wrench Rotate the eccentric nuts (M5-NE) until gantry slides onto the rail easily Make sure to push coupler all the way onto motor shaft before tightening...
- Page 14 STEP 11 Attaching the X-Rail to the XZ Gantry P-AM M8-15 10mm Allen Wrench Rotate the eccentric nuts (M5-NE) to tighten the grip of the wheels on the rail. Tighten until you can no longer rotate the V Groove bearings (VB) with your fingers.
- Page 15 STEP 12 Attaching Z-Lead Screw to XZ Gantry LS-200 Allen Make sure to push coupler all the way onto lead screw before tightening...
- Page 16 STEP 13 Attaching the Z-Rail to the XZ Gantry 10mm Allen Wrench Rotate the eccentric nuts (M5-NE) until gantry slides onto the rail easily Make sure to push coupler all the way onto motor shaft before tightening...
- Page 17 STEP 14 Calibrating the V Groove Bearings on 10mm the XZ Gantry Wrench Rotate the eccentric nuts (M5-NE) to tighten the grip of the wheels on the rail. Tighten until you can no longer rotate the V Groove bearings (VB) with your fingers.
- Page 18 STEP 15 Attaching Lead Screw to Y Gantry LS-400 Allen Make sure to push coupler all the way onto lead screw before tightening...
- Page 19 STEP 16 Attaching the Y-Rail to the Y Gantry 10mm Allen Wrench Rotate the eccentric nuts (M5-NE) until gantry slides onto the rail easily Make sure to push coupler all the way onto motor shaft before tightening...
- Page 20 STEP 17 Attaching the Y-Rail to the Y Gantry P-AM M8-15 10mm Allen Wrench Rotate the eccentric nuts (M5-NE) to tighten the grip of the wheels on the rail. Tighten until you can no longer rotate the V Groove bearings (VB) with your fingers.
- Page 21 STEP 18 Attaching the Router Mount P-RM M8-15 M8-25 M8-N Allen The bottom of the mount (P-RM) should be the side that is more flush with the bottom of the aluminum rail (AR-200)
- Page 22 STEP 19 Attaching Y Gantry to Frame M8-25 M8-N Allen...
- Page 23 STEP 20 Attaching XZ Gantry to Frame M8-25 M8-N Allen...
- Page 24 STEP 21 Attaching the Assemblies...
- Page 25 STEP 22 Attaching Frame Brackets and Acrylic F-AC P-FB M8-25 M8-N Shield Allen 16 x Twist on nuts and bolts on all corners loosely, then tighten on a flat surface...
- Page 26 STEP 23 Combining the Arduino and CNC Shield E-ARD E-CNC...
- Page 27 STEP 24 Attaching the Header Jumpers E-HJ...
- Page 28 STEP 25 Attaching Motor Cables Make sure the black wire is oriented as depicted...
- Page 29 STEP 26 Attaching Stepper Driver Chips E-SDH E-SDC...
- Page 30 flat 90° edge on the dial faces to the left; this gives the stepper motors on the Mill One the right amount of power to run effectively. If further tuning is required, turning the flat either counterclockwise or clockwise will increase or decrease the motor power respectively.
- Page 31 STEP 28 Attaching Wires to the DC Power Phillips Socket Ensure polarity is correct to avoid damage to electronics...
- Page 32 STEP 29 Placing Boards into Electronics Holder P-EH...
- Page 33 STEP 30 Feeding Wires Through Slots + Attaching DC Phillips Jack Ensure polarity is correct to avoid damage to electronics...
- Page 34 STEP 31 Securing the DC Jack P-PH Some machines may not need this step as the DC Jack (E-J) should fit snugly...
- Page 35 STEP 32 Attaching Electronics to Motors...
- Page 36 STEP 33 Assembled Mill One Your Mill One is now fully assembled. Don’t plug in your power brick yet, simply connect the USB cable to your computer and continue onto the next steps.
-
Page 37: Installing Firmware
INSTALLING FIRMWARE Open your favourite web browser and navigate to the Resources tab of our website. On the Resources page, under the Software heading, you should notice a link to the Firmware. - Page 38 If you’re using an apple product, your first step will be to download the driver linked on the page. This will ensure that plugging in your Arduino doesn’t cause any issues.
- Page 39 Once you run the package in the downloaded folder, the driver will install. You will be prompted to restart your computer, once the restart has completed, you should return to the Firmware page of our website...
- Page 40 Back on the Firmware page, you’ll want to click to download the “Grbl 1.1v with default settings for the Sienci Mill One” firmware. You’ll also want to download the latest Arduino IDE onto your computer; select your operating system to download the appropriate package.
- Page 41 Open the Arduino IDE once it’s installed Once open, navigate to File-> Open...
- Page 42 You should find a folder for the GRBL download in your downloads folder. Navigate through the folders until you find grblUpload.ino, double-click it to open it. This is the code that needs to be uploaded to the Arduino.
- Page 43 The last step to prepare for uploading the code is to include the Grbl library. Go to Sketch-> Install Library-> Add .zip Library then navigate back to your downloads folder. Once again, open the Grbl folder then navigate through and double-click on the grbl.zip file.
- Page 44 The Arduino IDE should confirm that the Library was added and you will now be able to upload the code to the Arduino. Check in the Tools tab that you’ve selected your board to be the Arduino Uno.
- Page 45 Also check that the proper port is selected. Then click Upload on the IDE to upload the code.
- Page 46 The IDE should confirm that the code is done uploading. To confirm that the code was implemented correctly, go to Tools then open up the Serial Monitor.
- Page 47 firmware has been uploaded correctly. Congratulations! Your Mill One should now be ready to go. In order to start using your machine you should start becoming comfortable with a CAM software as well as find a program which will send the g-code to your machine.
