AQUAVIVO PLANTGLO 100 Operating Instructions

AQUAVIVO
PLANTGLO..

Parts at a glance

1x LED Aquarium Light 1x Power Cable
4x Struts 1x Allen Key
2x Hanging Kits 4x Thumb Screws

Warnings

Before using the AQUAVIVO LED Aquarium Light please read the operating
instructions carefully and follow these safety directions:
1. Retain manual in a safe place for future reference.
2. Remove plastic and packaging material protecting the fixture before use.
3. For indoor use only. Use the specific attachments, mounting frames,
hanging kit and accessories provided by AQUAVIVO to avoid damage.
4. To avoid eye damage, never look directly at the light when switched on.
5. To avoid electric shock, do not touch the unit with wet hands.
6. Position electrical cables carefully to minimise tripping hazards.

Maintenance

1. Follow operating instructions when using the AQUAVIVO LED Aquarium
Light.
2. Keep the unit away from direct heat, including direct sunlight, fire or
radiators.
3. To reduce the risk of fire and electric shock, do not expose the light, plug
or cables to rain, moisture, dripping or splashing.
4. The unit should be positioned in a well-ventilated area.
5. The unit should be situated away from equipment or devices that generate
strong magnetic fields.
6. Clean unit with power off and using a dry cloth only.

Installation

1x Power Adapter
Figure 1.1
Insert struts into the base and
①
tighten screws to assemble
expandable brackets (figure 1.1).
2x Base
Figure 1.3
Screw the four thumb screws into the
③
4x Screws
holes on top of the light unit to keep the
expandable brackets in place (figure
1.3).

Hanging Installation

Screw the ends of the hanging kits into the light unit (figure 2.1) and use
suspension cables to hang light.
Figure 2.1
Struts
Base
Screw
Figure 1.2
Insert expandable brackets into
②
light unit (figure 1.2).
Figure 1.4
Position the unit on top of aquarium
④
and change length of expandable
brackets to fit the aquarium (figure
1.4). Tighten the thumb screws.
Ensure a tight fit.
Operating Instructions
6H 9H 12H
/
Memory Function:
If the unit is shutdown or loses power, the program settings will remain the same
when the unit is powered on again, however the time that the unit comes on will
need to be reset.
ON/OFF：
Press and hold the Power Button for 2 seconds. This will turn the light on or off.
Switch Mode：
Press and immediately release the Power Button to change between modes.
There are three modes:
① All LEDs (White + Red + Green + Blue + Purple)
② 2 Outer rows of LEDs (White + Red + Green)
③ Inner row of LEDs (White + Red + Blue + Purple)
Brightness Adjustment：
Press and immediately release the Brightness Button to change the brightness.
100%→75%→50%→25%;
Lightning Mode
Press and hold the Brightness Button for 2 seconds. The lightning mode will now
be on. In lightning mode, LEDs flash for 5 seconds.
Timing Mode：
Press and immediately release the Timing Button
6H→9H→12H→Timing OFF
E.g. 6H mode: Light turns on for 6 hours from when set, then off for 18 hours.
