AQUAVIVO PLANTPRO 60 Quick Start Manual

AQUAVIVO
PLANTPRO..
Parts at a glance
1x LED Aquarium Light 1x Power Cable
4x Struts 1x Allen Key
2x Hanging Kits 4x Thumb Screws
Warnings
Before using the AQUAVIVO LED Aquarium Light please read the operating
instructions carefully and follow these safety directions:
1. Retain manual in a safe place for future reference.
2. Remove plastic and packaging material protecting the fixture before use.
3. For indoor use only. Use the specific attachments, mounting frame,
hanging kit and accessories provided by AQUAVIVO to avoid damage.
4. To avoid eye damage, never look directly at the light when switched on.
5. To avoid electric shock, do not touch the unit with wet hands.
6. Position electrical cables carefully to minimise tripping hazards.
Maintenance
1. Follow operating instructions when using the AQUAVIVO LED Aquarium
Light.
2. Keep the unit away from direct heat, including direct sunlight, fire or
radiators.
3. To reduce the risk of fire and electric shock, do not expose the light, plug
or cables to rain, moisture, dripping or splashing.
4. The unit should be positioned in a well-ventilated area.
5. The unit should be situated away from equipment or devices that generate
strong magnetic fields.
6. Clean unit with power off and using a dry cloth only.
Installation
1x Power Adapter
Figure 1.1
Insert struts into base and tighten
①
screws to assemble expandable
brackets (figure 1.1).
2x Base
Figure 1.3
Screw the four thumb screws into the
③
4x Screws
holes on top of the light unit to keep the
expandable brackets in place (figure
1.3).
Hanging Installation
Screw the ends of the hanging kits into the light unit (figure 2.1) and use
suspension cables to hang light.
Figure 2.1
Struts
Base
Screw
Figure 1.2
Insert expandable brackets into
②
light unit (figure 1.2).
Figure 1.4
Position the unit on top of aquarium
④
and change length of expandable
brackets to fit the aquarium (figure
1.4). Tighten the thumb screws.
Ensure a tight fit.
Operating Instructions
ON/OFF Button and Mode switch and LCD display screen are located at the
opposite end of the light from the power cord.
LCD display screen
ON/OFF Button and Mode switch
ON/OFF Button and Mode switch action
②
Press down
① ③
Slide to the left Slide to the right
Turn ON:
Connect power supply to the unit. Press and hold down the button for at least 2
seconds, until the mode interface appears on the LCD display screen (figure 3.1).
Figure 3.1
M
AQUAVIVO
A:100％
Turn OFF:
Press and hold down the button for at least 5 seconds.
The display screen will display "OFF" (figure 3.2).
OFF
Figure 3.2
Mode switch
Once the unit has been turned on, press and hold down the button for at least 2
seconds to change between modes. There are three operation modes as shown
below.
B:100％
