LIFOS GO 200Ah User Manual

Disposal

Disposal of a used or damaged Lifos Go 200Ah battery must be done at a certified recycling
location. There are many of these nationwide – please see www.lifos.co.uk for details.

Warranty

A Lifos Go 200Ah battery is supplied with a 5-year warranty from the date of purchase (please keep
your proof of purchase) or 2750 battery cycles, whichever comes first. Note a full battery cycle is
determined by a fully discharged Lifos Go 200Ah (down to 10% of its gross capacity) and charged to
100%. The 5 year warranty period assumes no more than one full cycle per 24hr period. In the event
of a valid warranty claim the manufacturer will, at its discretion, supply a new or re-conditioned Lifos
Go 200Ah battery dependent on how many years have passed since the date of purchase or how
many cycles the battery has undertaken. This warranty is not transferable.

Conditions

a. Any warranty claim can only be validated by a proof of purchase.
b. The warranty is invalid if the battery has been subject to misuse, abuse or physical damage.
c. This Lifos Go 200Ah battery must be of the correct size, design and capacity for the intended
application.
d. The warranty is invalid if the correct size fuse is not fitted to all cables connecting to the
+ terminals on Lifos Go 200Ah.
e. The battery should be installed and operated at a temperature not exceeding the batteries
design limits as noted on the previous page and on the battery itself.
f. The warranty shall be voided if the battery becomes unserviceable due to: fire, freezing, abuse,
alteration, modification or it suffers from an over discharged state.
g. Installation of the battery must be performed by a responsible adult.

Warranty claims

1. Contact the original point of purchase for instructions.
2. The battery must only be returned in compliance with the transport and packaging regulations
ruling at the date of return. Failure to do this may result in the carrier refusing to ship the battery.
Lifos Go 200Ah safety and product limitations
•
Keep out of the reach of children
•
Do not under any circumstances disassemble this battery
•
Do not immerse the battery in liquid
•
Do not use the battery with damaged cables or terminals
•
This battery is not designed for cranking and starter Applications
•
Do not expose the battery to fire or crush or puncture its casing
•
Do not mix Lifos Go 200Ah batteries with other brands of batteries, whether in series or parallel
•
Do not short circuit battery positive (+) and negative (-), which can cause spark, fire, or even explosion.

Limited liability

The manufacturer nor any of its employees, agents,
distributors or resellers are liable for any third-party
damage howsoever caused. The extent to which the
manufacturer is liable to a customer is limited to the
purchase price paid by the customer for the Lifos battery.
We want your photos and videos! Here is your chance for you and your Lifos battery to be a star!
Just send in pics or videos of you and your Lifos in a great location and if selected we will not only give you
everlasting recognition on our online favourite users wall of fame but we will send you send you an Official Lifos Mains
Charger worth £20 completely free! Please send to hello@lifos.co.uk including your address details and best of luck!
Note – we cannot guarantee to publish every entry and only those selected by our marketing department for publication
will be awarded an Official Lifos Mains Charger. By providing your images you automatically grant us the right to use these
images/videos howsoever we see fit.
BACK
www.lifos.co.uk
200Ah
Lithium Iron
Phosphate Battery
(LiFePO 4 )
Lifos Go 200Ah quick user guide
This guide should be read in conjunction with the main instructions included overleaf,
but the following points will enable speedy deployment of your Lifos Go 200Ah battery.
1. Your Lifos Go 200Ah will be supplied partially charged. This is because transportation regulations
prohibit shipping a fully charged lithium battery. Please ensure the battery is fully charged before
first use.
2. Please ensure you depress the On/Off button before its first charge. It will be clear the battery
is active because the indicator will glow green. If you intend to deactivate the battery or leave
it for long periods without using it, please press the button again to turn it off. This process helps
prevent natural power loss and will keep your battery in top condition. Note, if the power button is
in the On position but has not had any charge or discharge for a period of 12hrs the indicator light
will turn off. This confirms the battery is in a dormant state to conserve energy but will instantly
switch back on again once a load or charge is recognised.
3. Lifos Go 200Ah can be charged by a solar panel (via a suitable charge controller), vehicle
alternator (via a suitable DC to DC converter) and any lead acid or lithium iron phosphate battery
charger. In general, any charger with a voltage range of 11.2v to 14.7v will charge Lifos, however, be
aware that some chargers that do not reach 14.7v may not 100% fully charge your Lifos battery.
Do not use chargers with an upper cut-off voltage higher than 14.7V i.e. those for designed for
NMC / LCO lithium chemistry. If in doubt, please contact hello@lifos.co.uk
4. The Battery Management System (BMS) within each Lifos Go 200Ah battery may give inaccurate
data via the Bluetooth App until ten charge and discharge cycles have taken place. This is
because during these ten cycles the BMS is balancing and calibrating the four lithium cells within
Lifos Go 200Ah.
5. If more than one Lifos Go 200Ah has been purchased and you wish to connect them in series,
parallel or both please see page 1 of this manual for detailed instructions.
6. Always use an appropriate sized cable and fuse based upon the expected current of your load .
This ensures the electrical circuits within the load and the battery are protected at all times. Fit
the fuse/s as close to the Lifos Go + terminal as possible. If in doubt consult a qualified electrician
or contact Lifos – hello@lifos.co.uk (or its retailers / agents) for advice .
Data sheets, MSDS, other documents and FAQ's can be accessed from www.lifos.co.uk
Important: please read before first use.
FRONT FRONT
User manual
Technical helpline 01684 774 000
